1 2 3 4 5 6

Programme selector/OffDisplay panel/buttons

Empty the condensate container

Empty the container after each drying cycle.

1. Remove the container, holding it level.

2. Pour out the condensate.

3. Push the container back in until it clicks

into place.

If Í (Condensate container) flashes in the

display panel aWhat to do if..., page 11.

Clean fluff filter

Do not operate the dryer without a fluff filter or with

a defective fluff filter. A clean fluff filter minimises

energy consumption.

Clean the fluff filter after each drying cycle.

1. Open the door. Remove any fluff from

the door/around the door and pull out

the fluff filter.

2. Remove the fluff from the shaft of the

fluff filter.

3. Open the fluff filter and remove the fluff

(sweep your hand over the fluff filter). If

the fluff filter is very dirty or blocked,

rinse with warm water and dry

thoroughly.

4. Close and reinsert the fluff filter.

7

6

Programmes/fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, page 7.

Observe the care instructions on the care label.

Algodón (Cottons) Hard-wearing fabrics.

Sintéticos (Synthetics) Fabrics made from synthetic or

blended fabrics.

Dryness levels to select with the Cottons and Synthetics

programmes:

Extra seco para

guardar (Cupboard Dry

Extra)

Thick and multi-layered fabrics.

Seco para guardar

(Cupboard Dry)

Single-layered laundry.

|Seco (Iron Dry) Laundry suitable for ironing after

drying.

Sport Functional clothing made of

microfibre.

ā Antialergias

(Anti-allergy)

Cotton fabrics for drying in higher

temperatures.

Mix A mixed load of fabrics made of

cotton and synthetic fabrics.

Caliente (Warm)

All types of fabric; time

programme.

Frío (Cold)

Camisas 15 min

(Shirts 15’)

Cotton or linen fabrics that are still

damp and easy-care fabrics.

Rápido 40 min

(Super 40’)

Synthetics, cotton or blended

fabrics.

WPlumas (Downs) Fabrics with down filling.

Acabado lana

(Wool finish)

Woollen fabrics that are suitable for

use in washers.

Your new dryer

Congratulations - You have chosen a modern, high-quality Bosch

domestic appliance.

The condensation dryer is distinguished by its economical energy

consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be

pleased to help.

Disposal in an environmentally-responsible manner



This appliance is labelled in accordance with European Directive 

2012/19/EU concerning used electrical and electronic appliances

(waste electrical and electronic equipment - WEEE). The guideline

determines the framework for the return and recycling of used

appliances as applicable throughout the EU.

For further information about our products, accessories,

spare parts and services, please visit: www.bosch-home.com

Intended use

Preparation

Set and adjust the

programme individually

1

2

Drying

ʋ exclusively for domestic use,

ʋ only for drying fabrics which have been washed using

water.

This appliance is intended for use up to a maximum

height of 4000 metres above sea level.

Keep children younger than 3 years old away from

the dryer.

Do not let children make the cleaning and

maintenance work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

Drying

Display panel and settings

ʑ

Display panel (status indicators)

p

(Fluff filter/

Heat exchanger)

Clean the fluff filter a page 4/11

or clean the heat exchanger a page 8.

Í÷

(Condensate

container)

Empty the condensate container a page 4/11.

H|]+

- Æ-§Ê

(Programme

sequence)

These indicators show the programme progress in the next steps of the drying cycle:

H Drying;

|] Iron Dry;

+Cupboard Dry;

- Æ- Programme pause a if required;

§ÊProgramme end.

(

(Childproof lock)

You can lock the dryer to prevent the functions you have set from being changed inadvertently.

To activate/deactivate ( (Childproof lock) start the programme and then press and hold

the Inicio/Stop (Start/Pause) button for 5 seconds until a long acoustic signal is heard.

The option activated/deactivated a( (Childproof lock) indicator light on/off.

[h:min]

(Remaining time)

When a programme is selected, the anticipated drying time (remaining time) for

the recommended load is displayed. While drying, the moisture sensors detect the actual load

and correct the programme length. This is shown by jumps in the remaining time in the display

panel.

ʑ

Settings (indicators lights and buttons)

Selected option activated/deactivated a indicator light on/off.

See the separate Energy-saving mode instructions.



Duración/Duração

(Drying Time)

Drying time, available only for timed programmes, can be selected from min. 0:20 h to max.

3:00 h, in 10-minute steps.

y

Ajuste secado

(Fine adjust)

The dryness levels (e.g. Cupboard Dry) can be increased in three levels. The laundry is made

drier. Default = 0. Selectable values: 0, 1, 2, 3. After setting the level of the fine adjustment for a

programme, it is also retained for other programmes, until y

Ajuste secado (Fine adjust) is

changed again.

³¤- ¤

Terminado en/em

(Finished in)

The time when the programme has to end can be set by selecting the Terminado en/em

(Finished in) time. The Terminado en/em (Finished in) time can be selected in one-hour steps,

up to a maximum of 24 hours. Select the Terminado en/em (Finished in) button repeatedly until

the required number of hours is displayed. Then press the Inicio/Stop (Start/Pause) button to

activate the Terminado en/em (Finished in) option. The programme ends after the selected

number of hours. Several minutes after activating Terminado en/em (Finished in) option

the display switches off to save energy. To switch it on select any button, close/open the door or

turn the programme selector.

Delicado (Low Heat) Reduced temperature for delicate fabrics, e.g. polyacrylic, polyamide or elastane, with a longer

drying time.

Menos S

(Wrinkle Guard Plus)

After the programme finishes, the drum moves at regular intervals to prevent creases.

Laundry remains loose and fluffy. The standard setting for each programme is 60 min.

Automatic anti-crease function can be extended by up to 60 min.

&ü(Signal) For switching the buzzer on and off. & (Signal) indicates program end if it is activated.

Other sounds are not influenced by this option.

Close the door

3

Contents Page

ʋ Preparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋ Control panel . . . . . . . . . . . . . . . . . . . . . 2

ʋ Drying . . . . . . . . . . . . . . . . . . . . . . . . .3/4

ʋ Display panel and settings . . . . . . . . . . . 5

ʋ Notes on laundry . . . . . . . . . . . . . . . . . . 6

ʋ Overview of programmes . . . . . . . . . . . . 7

ʋ Care and cleaning . . . . . . . . . . . . . . . . . 8

ʋ Installation . . . . . . . . . . . . . . . . . . . . . . . 9

ʋ Frost protection/Transport . . . . . . . . . . . 9

ʋ Optional accessories . . . . . . . . . . . . . . 10

ʋ Technical data . . . . . . . . . . . . . . . . . . . 10

ʋ Consumption rates . . . . . . . . . . . . . . . . 10

ʋ After-sales service . . . . . . . . . . . . . . . 11

ʋ What to do if ... . . . . . . . . . . . . . . . . 11/12

ʋ Safety instructions. . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged!

Inform your after-sales service!

Inspect the dryer

Sort the laundry

Remove all items from pockets,

especially cigarette lighters.

The drum must be empty prior to loading.

See also separate instructions for “Woollens basket”

(depending on model).

Make sure your hands are dry.

Only grasp the plug by the plug

body.

Connect the

mains plug

End of the programme...

Interrupt the programme

1. Open the door or press the Inicio/Stop (Start/Pause)ü

button; the drying cycle is interrupted.

2. Add or remove laundry and close the door.

3. If required, select a new programme and additional

functions. Select the Inicio/Stop (Start/Pause) button.

The remaining time is updated after a few minutes.

The drum and door may be hot!

Notes on laundry ...

Labelling of fabrics

Follow the manufacturer's care instructions.

hcSuitable for tumble drying.

(cDry at normal temperature.

'cDry at low temperature a in addition, select Delicado (Low Heat).

)cDo not tumble dry.

Do not tumble dry the following fabrics:

– Non-breathable fabrics (e.g. rubber-coated).

– Delicate materials (silk, curtains made from synthetic material) a these may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. towels).

– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc.

together or use a laundry bag.

– Do not over-dry easy-care laundry a risk of creasing. Allow laundry to finish drying in

the air.

– Do not dry woollens in the dryer. They may, however, be refreshed in the dryer a page 7,

Acabado lana (Wool finish) programme (depending on model).

– Do not iron laundry immediately after drying; fold items up and leave for a while a residual

moisture will then be distributed evenly.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not use the Extra seco para guardar (Cupboard Dry Extra) programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

reduces the drying effect.

– When washing laundry that is to be tumble dried afterwards, use the correct amount of

fabric softener as specified in the manufacturer's instructions.

– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the timed

programme. Also suitable for subsequent drying.

Environmental protection/energy-saving tips

– Before drying, spin the laundry in the washing machine a higher spin speeds minimise

the drying time and reduce energy consumption.

– Use the maximum recommended capacity, but do not exceed it a Programme overview,

page 7.

– Make sure the room is well ventilated during drying.

– Clean the fluff filter after every drying cycle a Clean the fluff filter, page 4/11.

– Do not cover or seal the air inlet on the dryer.

Remove the laundry and switch off

the dryer

5

4

Control panel

Fluff filter

Select

Inicio/Stop

(Start/Pause)

Door

Installation a page 9.

Observe the safety instructions on page 13.

Read these instructions and the separate

Energy-saving mode instructions

before operating the dryer.

Condensate

container

Air inlet

Programme sequence H|]+  Duración/Duração (Drying

Time)

Setting the drying time available only for timed programmes.

- Æ-§Ê y Ajuste secado (Fine adjust) Fine adjustment of dryness level.

Childproof lock ( ³¤- ¤ Terminado en/em (Finished in) Setting the programme end.

Condensate container Í Delicado (Low Heat) Low-heat drying - reduced temperature.

Fluff filter/Heat exchanger p Menos S(Wrinkle Guard Plus) Extends the anti-crease function.

&(Signal) Buzzer on/off.

Inicio/Stop (Start/Pause) Starts, pauses and continues the programme; activates or

deactivates ( (Childproof lock).

Programme selector for setting

the programme and switching the appliance

on/off. Can be turned in both directions.

Maintenance flap

Further information

can be found on

Page 5

`

7

Programme overview see also page 6.

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying, laundry is to be ...

cironed  lightly ironed @cnot ironed cmangled

PROGRAMMES TEXTILE TYPE AND INFORMATION

*Algodón (Cottons)

max. 7 kg

Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.

*Sintéticos (Synthetics)

max. 3.5 kg

Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.

Seco |(Iron Dry) c÷@c

The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).

Seco para guardar

(Cupboard Dry)

@

Single-layered laundry.

Extra seco para guardar

(Cupboard Dry Extra)

@

Laundry with thick, multi-layered parts.

Sport

max. 1.5 kg

Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with removable inter-

nal lining separately).

ā Antialergias (Anti-allergy)

max. 6 kg

Cotton fabrics for drying in higher temperatures to keep them more hygienic .

Mix

max. 3 kg

Mixed items of laundry made of cotton and synthetics (Mix).

Caliente (Warm)

max. 3 kg

Suitable for pre-dried or slightly damp laundry and for drying off multi-layered, thick laundry.

Only dry wool, sports shoes and soft toys with the basket for woollens a Optional Accessories, page 10.

In the time programme, the laundry's residual moisture is not automatically detected. If the laundry is still too damp after the drying

programme, repeat the programme and, if required, extend the programme length.

Frío (Cold)

max. 3 kg

All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

Camisas 15 min (Shirts 15’)

max. 1 kg

For optimal drying result dry a maximum of 5 business shirts together. After drying, iron clothes or hang them out and leave for a

while. The remaining moisture will be distributed evenly.

Rápido 40 min (Super 40’)

max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from

the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capa-

city.

WPlumas (Downs)

max. 1.5 kg

Garments with down feather fillings, pillows and blankets. By non quilt loads - please add just 1 piece per drying.

Acabado lana (Wool finish)

max. 3 kg

Woollen fabrics suitable for washers. Fabrics become fluffier but not dry. Remove fabrics once the programme has ended and allow

to dry.

*Dryness levels can be selected individually a Cupboard Dry Extra, Cupboard Dry and Iron Dry | (depending on the model). Degree of dryness can be finely adjusted; multi-

layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

9603 / 9001181470

*1181470*

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Germany

WTB86238EE

Beoordeling

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WTB86238EE Wasdroger. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WTB86238EE Wasdroger in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasdrogers
Meer handleidingen voor Wasdrogers

Veelgestelde vragen over Bosch WTB86238EE Wasdroger

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.
