Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5

ʋImportant Information . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection / Transport. . . . . . . . . . . 8

ʋCleaning and care . . . . . . . . . . . . . . . . . . 9

ʋTechnical data . . . . . . . . . . . . . . . . . . . 10

ʋOptional accessories . . . . . . . . . . . . . . . 10

ʋNormal noises . . . . . . . . . . . . . . . . . . . . 11

ʋWhat to do if... / After-sales service . . . . 12

ʋSafety instructions . . . . . . . . . . . . . . . . 13

... and adapt to individual requirements

Never operate the dryer if it is damaged.

Inform your after-sales service.

Inspecting the

dryer

Sorting and loading laundry

Remove all objects from pockets.

Pay particular attention to cigarette lighters.

The drum must be empty before filling.

See programme overview on page 7.

See also separate instructions for “basket for woollens”

(depending on the model)

Your new dryer

Intended use

Preparing for

installation, see Page 8

Selecting and adjusting the programme

Select the drying programme ...

Press the Inicio/Stop

(Start/Stop) button

Only if your hands are dry.

Only hold the plug by the plug

casing.

Connecting the

mains plug

All buttons are sensitive and only need to

be touched lightly.

ʋonly for domestic use.

ʋonly to be used for drying fabrics that have been

washed with water.

.

Do not leave children

unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

3

2

1

Drying

Drying

Condensation container with filter

Control panel

Air inlet

Two-part

fluff filter

Drum

Only use the dryer with the fluff filter

inserted!

Congratulations! - You have chosen a modern, high-quality domestic

appliance from Bosch.

The condensation dryer with heat pump and automatic cleaning of the

heat exchanger is outstanding in terms of efficient energy

consumption and low maintenance requirements aPage 6.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased

to help.

Environmentally responsible disposal

Dispose of packaging in an environmentally-responsible manner.

This appliance is designated according to European directive

2002/96/EC which governs waste electrical and electronic

equipment (WEEE).

The directive provides an EU-wide framework for the return and

recycling of used appliances.

For further information about our products, accessories, spare parts

and services, please visit: www.bosch-home.com

Do not pull out/empty

the condensation container when drying is in progress

Drum interior

light

The programme has ended when \ lights up in the display panel.

Interrupt programme removing or adding laundry.

The drying cycle can be interrupted for a brief period so that laundry may be added or removed.

The selected programme must then be continued until it is finished.

Never switch the dryer off before the drying process has ended.

1. Open the door. The drying cycle is interrupted.

2. Remove or add laundry and close the door.

3. If required, select a new programme and additional functions.

4. Press the Inicio/Stop (Start/Stop) button. The remaining time is updated after a few minutes

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

(cDrying at normal temperature.

'cDrying at low temperature a also select Delicado (Low Heat).

)cDo not machine dry.

Always observe the safety instructions on page 13!

Do not tumble-dry the following fabrics for example:

– Airtight fabrics (e.g. rubber-coated fabrics).

– Delicate materials (silk, curtains made from synthetic material) a they may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with

large items of laundry (e.g. hand towels).

– Close zips, hooks and eyes, and do up any buttons.

Tie belts, apron strings etc. together.

– Do not overdry easy-care laundry a risk of creasing

Allow laundry to finish drying in the air.

– Do not dry woollens in the dryer. They may, however, be refreshed aPage 7

Woollens Finish programme (depending on the model).

– Do not iron laundry immediately after drying, fold items up and leave for a while a

the remaining moisture will then be distributed evenly.

– The drying result depends on the type of water used during washing. aFine adjustment

of the drying result aPage 1/2.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not select the Extra seco para guardar (Extra Dry) programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating

that adversely affects the drying operation.

– When washing laundry that is to be tumble-dried afterwards, use the correct amount

of fabric softener according to the manufacturer's instructions.

– Use the Zeitprogramm (Timed programme) for small loads a this improves the drying

result.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine a the higher the spin

speed, the shorter the drying time will be, thus consuming less energy. Also spin easy-care

laundry.

– Use the maximum recommended capacity, but do not exceed it

a “Programme overview” aPage 7.

– Ensure the room is well ventilated during drying.

– Do not cover or seal the air inlet.

Emptying condensation

Empty the container after each drying cycle, not during drying!

1. Remove the condensation container and hold it level.

2. Pour out the condensation.

3. Always push the container fully back in until it locks in place.

If the ācContainer indicator lamp is flashing a page 9.

Cleaning the fluff filter

The fluff filter consists of two parts.

Clean the inner fluff filter after every drying cycle:

1. Open the door. Remove any fluff from the door/around the door.

2. Pull out the inner fluff filter and fold it open.

3. Remove any fluff (rub your hand over the fluff filter).

If the fluff filter is very dirty or clogged, rinse it under running

water and dry thoroughly.

Clean the outer fluff filter after every 5th drying cycle:

4. Remove the outer fluff filter.

5. Open it and remove any fluff.

Rinse under running water and dry thoroughly.

6. Fold the fluff filters closed, put them back together and reinsert into

the appliance.

Switching off the dryer

Turn the programme selector to Stop.

Do not leave laundry in the dryer.

Removing the laundry

Your dryer is equipped with an automatic anti-crease function. The drum is moved at specific time intervals

for 30 minutes once the programme has ended. The laundry stays loose and fluffy (60 or 120 minutes if

the additional cFácilc(Reduced Ironing) function is selected).

ʜMenu

For selecting the settings.

ʜ-/+ (Change)

To change all settings in the display panel.

Electronic start

timer

End of the programme following... (depending on the programme selected,

e.g. duration 1:54h a 2h; the nearest whole hour is always selected).

1 -24 hrs

3Signal

Signal volume selectable in four stages: 0 (off), 1 (quiet), 2 (normal), 3 (loud), 4 (very loud). 0, 1, 2, 3, 4

#

Appliance lock

Protection against accidental adjustment of functions that have been set (hold menu button down for

5 seconds).

On-Off

9Fine adjustment

of the drying result

The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for the

Algodón/Algodão (Cottons/Coloureds), Sintéticos (Synthetics), Mix and Extra rápido 40 min.

(Rapid 40) programmes apresetting = 0. After one of these programmes has been finely adjusted,

the setting is retained for the others.

0, 1, 2, 3



Spin speed

Speed at which the washing machine was spun;

only used if the anticipated drying time needs to be displayed more accurately.

600-1800

Additional

functions

Display panel

Programme selector

Reduces creasing and extends the anti-creasing phase once the

program has ended; two settings available.

ˎFácilcc

(Reduced Ironing)

Reduced temperature for delicate fabrics ' that require a longer drying

time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎDelicado÷

(Low Heat)

Programme sequence displays:

drying, iron dry, cupboard dry, slackening/ready.

Status indicators

Ic+c\

Rinse the fluff filter under running water aPage 4.

Empty the condensation container.

If necessary, clean the filter in the condensation tank aPage 9.

Service displays

4cFluff filter

ācContainer

Display of max.

loading capacity for

programme selected

Read these instructions and the separate

Energy-saving mode instructions before operating the dryer.

Observe the safety instructions on page 13.

Important Information

Your dryer is designed to be particularly energy-saving and its technical features include

a refrigeration circuit that uses energy efficiently, in a similar way to a refrigerator.

The dryer's heat exchanger is cleaned automatically during drying.

The fluff filters and filter in the condensation tank must be cleaned regularly.

Never operate the dryer without the fluff filter and condensation tank!

ʑ

Fluff filter

During drying, fluff and hairs from the laundry are trapped in the fluff filter. A blocked fluff filter

may impair the heat exchange process.

The fluff filter should therefore be cleaned after every drying cycle.

Rinse the filter regularly under running water aPage 4.

ʑ

Filter in the condensation tank

The filter in the condensation tank cleans the condensation. This condensation is required

for the automatic cleaning process. The filter must be cleaned regularly under running water.

Empty the condensation tank before cleaning the filter aPage 9.

ʑ

Fabrics

Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:

e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent. etc.

Empty all pockets.

Do not dry airtight fabrics.

Avoid drying fabrics that produce a lot of fluff.

Woollens should be refreshed only using the woollens programme.

7

Programme overview see also page 5

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying...

ciron laundry lightly iron laundry @cdo not iron laundry cmangle laundry

PROGRAMMES TEXTILE TYPE AND INFORMATION

**Algodón/Algodão

(Cottons / Coloureds)

max. 7 kg

Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.

**Sintéticos

(Synthetics)

max. 3.5 kg

Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.

** Mix

max. 3 kg

Mixed items of laundry madeof cotton and synthetics (Mix).

Seco  (Iron Dry)c

c÷@c

Fabrics suitable for ironing (iron fabrics in order to avoid creasing).

Seco para guardar

(Cupboard Dry)

@

Single-layer fabrics.

*Seco plus

(Cupboard Dry Plus)

@

Fabrics made of thick, multilayered items of clothing.

*Extra seco para guardar

(Extra Dry)

@

Fabrics made of very thick, multi-layered items of clothing which need to be dried longer.

Alisar (Shirts/Blouses)

max. 3 kg

For cotton or linen fabrics that are still damp and easy-care fabrics. Creasing in fabrics is reduced. Fabrics are not dried

completely. Laundry ready for ironing and/or hanging up!

Sport $

max. 1.5 kg

Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with

removable internal lining separately).

Secar c/cesto (Drying Basket)

max. 1.5 kg

Use with separate basket only. See description of “Woolens basket.“

Extra rápido 40 min. (Rapid 40)

max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may

differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the

fabric and loading capacity.

Caliente/quente

(Timed program warm)

max. 3 kg

Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.

Also for subsequent drying.

Frio (Timed program cold)

max. 3 kg

All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

*for Cottons/Coloureds and Synthetics programmes only

**Dryness levels can be selected individually a Extra Dry, Cupboard Dry Plus, Cupboard Dry and Iron Dry (depending on the model).

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

9306 / 9000815445

*815445*

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

D-81739 München/Deutschland

WTW86590EE

Beoordeling

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WTW86590EE Wasdroger. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WTW86590EE Wasdroger in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasdrogers
Meer handleidingen voor Wasdrogers

Veelgestelde vragen over Bosch WTW86590EE Wasdroger

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Gerelateerde producten

Handleiding

Bosch WQG233CPSN Wasdroger

Handleiding

Bosch WQG245A0ES Wasdroger

Handleiding

Bosch WQG242ABSN Wasdroger

Handleiding

Bosch WTG864B8DN Wasdroger

Handleiding

Bosch WQG231M0FG Wasdroger

Handleiding

Bosch WQG245AASN Wasdroger

Handleiding

Bosch WTX87P90IL Wasdroger

Handleiding

Bosch WQG231P0FG Wasdroger

Gerelateerde categorieën
