Size: 110mm(W) x 220mm(H) 304A Ver 4

• The configuration of your unit may differ somewhat from that

shown in the illustration.

• Please refer to the engraved battery marks at the battery

compartment for the correct battery type.

Start

ResetºC/ºF

304A

INSTRUCTION MANUAL MODEL DT-12 POCKET THERMOMETER

BEFORE FIRST USE

• Insert or Replace Battery: Use a coin to turn the battery cover on back side

counter-clockwise to open. Insert LR44 battery (included) with + side up. Replace

battery cover and turn clockwise.

• Clean stainless tip: wash tip with warm soapy sponge or cloth, then rinse and dry.

• Do not immerse product body in water.

• READ ALL INSTRUCTIONS, PLEASE

The DT-12 thermometer is now ready to use.

REMOVING PROBE FROM HANDLE

Using two hands, gently rock the probe from side to

side in the handle until it pops free. See (Picture 1).

Do not pull probe straight out from handle. Gently

rock works best.

TO CHOOSE °C/°F

Press the °C/°F button to select the temperature unit.

TO MEASURE FOOD TEMPERATURE

RediChek DT-12 has two ways to get an accurate temperature reading: FAST CALC

and NORMAL. The DT-12 automatically selects the best method.

The FAST CALC system speeds up the reading by using sequential mathematic

calculations based on rate of temperature rise, to project an estimated final reading

before it is actually reached. This system is accurate to +/-2F in the center of its

operating range.

The NORMAL system displays the actual tip temperature as it rises, which takes

more time depending on temperature differential. To measure food temperatures

with the DT-12:

1. Turn unit ON by pressing Start button.

2. Insert tip of probe into food being cooked. The thermometer will start processing.

a. When the tip is cold and is inserted into food and begins a rapid rise in

temperature (due to a large difference between the cold tip, and the hot food

temperature) the unit automatically chooses FAST CALC processor mode. It

will BEEP as it starts Fast Calc.

b. When the tip is already hot, or detects a smaller difference in temperature, the

unit stays in NORMAL mode.

3. Wait for temperature reading to stabilize on display.

a. In FAST CALC mode, the temperature will "Lock" after about 6-8 seconds and

hold the locked reading on the display. FAST CALC has a maximum reading of

212°F, above will read HI.

b. In NORMAL mode, the temperature reading will rise gradually and continue to

change up or down slightly once final temperature reached. NORMAL has a

maximum reading of 428°F.

4. If in FAST CALC lock mode, press Start again to unlock the display and change to

NORMAL mode.

5. To start another measurement, repeat 1 to 4 again.

When in FAST CALC mode, the unit will Beep as inserted into food, then flash “ - - -

“ for 2-3 seconds, then flash approximate temperature readings for approx. 3-5

seconds, then Lock onto calculated actual temperature. You can change to

NORMAL mode at any time during Lock phase.

OPERATING RANGE

In NORMAL mode, the unit's temperature range is 32°F to 428°F. If the temperature

is below 32°F or above 428°F, LO or HI will show on the display.

HELPFUL HINTS

• When measuring multiple or different foods and meats, it may be desirable to cool

the probe by rinsing the tip with cold water between readings.

• It is recommended that you wipe the probe tip clean between readings. This is

especially important when taking readings form different foods and meats.

• When the tip is cold you can “force” the processor into FAST CALC mode by

pressing Start a second time. You will hear a Beep.

• Pressing Start button when unit is in Lock phase will change to NORMAL mode,

but unit will not change back to FAST CALC until fully cooled and auto-shutoff

has occurred.

• The DT-12 will not Auto-Shutoff when display is in Lock phase (after a FAST

CALC reading). Press Start to return to NORMAL mode.

• The DT-12 is designed for temporary, hand held use. Do not use in an oven. Do

not leave inserted in extremely foods or liquids (anything over 200°F) for more

than 1 minute.

• Always take your reading in the thickest available portion of meat. Thin portions of

meat are difficult to measure since they tend to cook through fast. Avoid touching

bone. If the tip touches the bone or heavy fat area of the meat, or if the tip is not

deep enough, take a second reading to ensure accuracy.

CARE OF YOUR THERMOMETER

• Do not touch the stainless portion of the thermometer during or right after

measuring temperatures since it will be hot.

• Do not place the unit in dishwasher or immerse in any liquid. To clean, wipe the

probe tip with a damp soapy cloth or sponge and then dry.

• Do not leave exposed to extreme high or low temperatures since this will damage

electronic parts and plastics.

• Do not leave the thermometer inserted in food during cooking.

• Remove battery if stored for more than four months.

AUTO SHUTOFF

This thermometer will automatically turn off if no buttons are pushed in 2 minutes.

Pressing Start button will turn on the unit again.

RESETTING THE UNIT

Reset the unit by pressing the RESET button if the unit does not work properly.

MAVERICK LIMITED ONE YEAR WARRANTY

Maverick Industries Inc. warrants this product to be free of defects in parts, materials

and workmanship for a period of one year, from date of purchase. Should any

repairs or servicing under this warranty be required, contact Maverick Customer

Service by mail or phone for instructions on how to pack and ship the product to

Maverick's National Service Center located as follows:

MAVERICK CUSTOMER SERVICE

94 Mayfield Ave.

Edison NJ 08837

Telephone: (732) 417-9666

Hours: Weekdays 8:30 AM- 4:30 PM

Do not send any parts or product to Maverick without calling and obtaining a Return

Authorization Number and instructions.

This warranty is VOID if instructions for use are not followed; for accidental damage; for

commercial use; for damage incurred while in transit; or if the product has been tampered with.

This warranty gives you specific legal rights and you may also have other rights which vary from

state to state.

www.maverickhousewares.com

bend slightly from side

(Picture 1.)
