Handleiding

220-

240V

110-

127V

VOLTAGE

SELECTOR

Specifications

• Frequency range

FM:

Saudi Arabia 87.6–107 MHz

Other countries 87.6–108 MHz

MW: 530–1,605 kHz

SW1: 2.3–7 MHz

SW2: 7–22 MHz

• Aerials

FM/SW: Telescopic aerial

MW: Built-in ferrite bar

• Recording system

2–track, 4–channel stereo

• Frequency response

70–10,000 Hz

• Speakers

Full range: 10 cm (4 inches) dia.,

2.8 ohms cone type x 2

• Output

Headphones jack (stereo minijack),

for 16–68 ohms impedance

headphones

• Maximum Power output

2.5 W+2.5 W

• Battery life

FM Recording: Sony R20P:

Approx. 16 hours/Sony LR20

alkaline: Approx. 36 hours

Playback: Sony R20P: Approx.

8 hours/Sony LR20 alkaline:

Approx. 21 hours

• Power requirements

110–127 V/220–240 V AC

selectable, 50/60 Hz

9V DC, six R20 (size D) batteries

• Power consumption

AC 14W

• Dimensions

Approx. 500 x 155 x 164 mm

(w/h/d) ( 19

/4 x 6

/8 x 6

inches) incl. projecting parts and

controls, not incl. handle

• Mass

Approx. 2.7 kg (5 lb 15 oz) not

incl. batteries

• Supplied accessory

Mains lead (1)

Design and specifications are

subject to change without notice.

Printed in Japan

3-865-191-53(1)

Operating Instructions

WARNING

Radio

Cassette-

Corder

Choosing Power Sources

To use the player on AC power source (mains)

Connect the supplied mains lead to the AC IN jack.

To prevent fire or shock hazard,

do not expose the player to rain

or moisture.

To avoid electrical shock, do not

open the cabinet. Refer servicing

to qualified personnel only.

Do not install the appliance in a

confined space, such as a

bookcase or built-in cabinet.

To prevent fire or shock hazard,

do not place objects filled with

liquids, such as vases, on the

appliance.

The FUNCTION selector is

located at the top panel.

When you turn on the player, the

OPR/BATT indicator lights up.

Precautions

On safety/power sources

• Should any solid object or liquid

fall into the player, unplug the

player and have it checked by

qualified personnel before

operating it any further.

• For AC operation, check that the

player’s operating voltage is

identical with your local power

supply (see “Specifications”) and

use the supplied mains lead; do

not use any other type. The voltage

selector is located at the rear of the

player.

• The player is not disconnected

from the AC power source (mains)

as long as it is connected to the

mains, even if the player itself has

been turned off.

• For battery operation, use six R20

(size D) batteries.

• When the batteries are not to be

used, remove them to avoid

damage that can be caused by

battery leakage or corrosion.

• The nameplate indicating

operating voltage, power

consumption, etc., is located on the

bottom.

Troubleshooting

There is no audio.

• Connect the mains lead

securely.

• Insert the batteries properly.

• Replace all the batteries if they

are weak.

• Unplug the headphones.

• Adjust the volume.

• Set FUNCTION to the position

you want to operate.

Cassette cannot be

inserted.

• Insert the cassette properly.

• Press p6 STOP/EJECT to

release.

The r REC button does

not function.

• No cassette in the tape

compartment.

• Make sure the safety tab on the

cassette is in place.

Poor playback,

recording or erasing

quality.

• Dirty heads. Clean the unit (as

shown) with a cotton swab

slightly moistened with

cleaning fluid or alcohol.

• Demagnetize the heads and all

metal parts in the tape path

with a commercially available

head demagnetizer.

Tip

For customers supplied with an AC plug adaptor, use it if the plug

of the mains lead does not match your mains.

Notes

• To use the player on batteries, disconnect the mains lead from

the player.

• Replace the batteries when the OPR/BATT indicator dims or

when the player stops operating. Replace all the batteries with

new ones.

To use the player on batteries

Insert six R20 (size D) batteries (not supplied) into the battery

compartment.

To adjust the voltage

Be sure to set the VOLTAGE

SELECTOR (at the rear) to your local

power supply.

1 to AC IN

CFS-B7SJMK2

2 to the mains

On placement/operation

• Do not leave the player in a

location near heat sources, or in

a place subject to direct sunlight,

excessive dust or mechanical

shock.

• Do not place anything within 10

mm of the side of the cabinet. The

ventilation holes must be

unobstructed for the player to

operate properly and to prolong

the life of its components.

• Since a strong magnet is used for

the speakers, keep personal credit

cards using magnetic coding or

spring-wound watches away from

the player to prevent possible

damage from the magnet.

• If the player has not been used for

a long time, set it in the playback

mode to warm it up for a few

minutes before inserting a

cassette.

If you have any questions or

problems concerning your player,

please consult your nearest Sony

dealer.

Pinch roller

Cotton swab

Record/

playback head

Capstan

Erase head
