1 2 3 4 5 6

Select $

Start/Pause

:c– 90 °C Temp. (°C) Select the temperature (: = cold)

c– 1400 * rpm ()c Select the spin speed (* depending on model) or  (rinse stop =

without final spin, the washing remains in the water after the last

rinse cycle).

1 – 24 h Ready in () Programme ends in ...

Status displays Programme progress displays:

1üüüücü- ¯- Washing, Rinse, Spin, programme duration or end (- ¯-)

Programme selectorDisplay panel/

Option buttons

Start/

Pause

Additional functions

Sorting and inserting the washing

Follow manufacturer’s care information!

According to the information on the care labels.

According to type; colour; soiling and temperature.

Do not exceed maximum load. a Page 7

Follow important instructions. a Page 6

Insert large and small items of washing!

Close the washing machine door.

Do not jam items of washing between the washing machine door and rubber seal.

Add detergent and care product

Dose according to:

amount of washing, soiling, water hardness (available from your water utility company) and

manufacturer’s instructions.

For models without insert for liquid detergent:

Pour liquid detergent into corresponding dispenser and place in drum.

Caution when opening the detergent drawer while the appliance is running!

Important information

Before using your washing machine for the first time

Do not put any washing in the washing machine! Turn the tap on. Pour into dispenser II:

– Approx. 1 litre water.

– Detergent (dosage according to manufacturer’s instructions for light soiling and according to degree of water

hardness).

– Set programme selector to

IEasy-Care 60 °C and select $ Start/Pause.

At the end of the programme set the programme selector to Off.

Protecting the washing and the machine

– When dosing all detergents, cleaning aids and cleaning agents, always follow the manufacturer's instructions.

– Empty pockets.

– Remove metal parts (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

Insert laundry

Insert large and small items of washing!

Do not jam items of washing between the washing machine door and rubber seal.

Washing with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select Eco

+

additional function.

Heavy

Load less washing. Select programme with

Prewash.

If required, pretreat stains. Select Eco

+

additional function.

Soaking Load washing of the same colour.

Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions. Set programme selector to

LcCottons 30 °C and select $ Start/Pause. After approx. 10 minutes select $ Start/Pause to stop the programme.

After the required soaking time reselect $ Start/Pause if the programme is to be continued or change the programme.

Starching Washing should not be treated with fabric softener.

Liquid starch can be used in all wash programmes. Pour starch into the fabric softener dispenser ~ according

to manufacturer’s specifications (if required clean beforehand).

Dyeing/Bleaching

Dye in household quantities only. Salt may attack stainless steel! Observe specifications of the dye manufacturer!

Do not bleach washing in the washing machine!

Emergency release e.g. if power failure occurs

The programme continues running when the power supply is restored.

If the washing is still to be removed, the door can be opened as described below:

Risk of scalding!

Detergent solution and washing may be hot. If required, leave to cool down.

Do not reach into the drum in case it is still rotating.

Do not open the door if you can still see water through the glass.

1. Set programme selector to Off, pull out the mains plug.

2. Removing base strip a see separate installation instructions.

3. Drain the water. aPage 10

4. Pull down emergency release with a tool and release.

Door can then be opened.

5. Attaching base strip a see separate installation instructions.

Insert for liquid detergent (depending on model) a Page 9

Dispenser II: Detergent for main wash,

water softener, bleach, stain remover

Your washing machine

Intended use

Contents Page

ʔ Intended use........................................................................................................................... 1

ʔ Programmes........................................................................................................................... 1

ʔ Selecting and adjusting a programme............................................................................. 3

ʔ Washing...............................................................................................................................3/4

ʔ After washing ......................................................................................................................... 4

ʔ Individual settings.................................................................................................................. 5

ʋ Important information ..........................................................................................................6

ʔ Emergency lock release ...................................................................................................... 6

ʔ Overview of programmes .................................................................................................... 7

ʔ Safety instructions................................................................................................................. 8

ʔ Consumption values ............................................................................................................. 8

ʔ Insert for liquid detergent.................................................................................................... 9

ʔ Care .......................................................................................................................................... 9

ʔ Information on the display panel ....................................................................................... 9

ʔ Information on blockage................................................................................................... 10

ʔ What to do if …..................................................................................................................... 11

Protection of the environment/Conservation tips

– Utilise the maximum amount of washing for the particular programme.

– Wash normally soiled washing without prewash.

Comparable cleaning result with significantly lower energy consumption.

– The selectable temperatures apply to the care labels on the textiles. The

temperatures in the machine may deviate from this so that you get the optimum mix

of energy-saving and washing results.

– Measure detergent according to the manufacturer’s instructions and water

hardness.

– If the washing is then dried in the tumble dryer, select spin speed according to the

instructions of the dryer manufacturer.

Preparation

Before using your washing machine for the first time

wash once without any washing. a Page 6

Setting programmes

1

2

Washing

Dispenser ~: Fabric softener, starch

Dispenser I: Detergent for prewash

ʔ for use in the household only,

ʔ for washing machine-washable textiles and hand-washable wool in

wash liquor,

ʔ to be operated with cold drinking water and commercially available

detergents and care products which are suitable for use in washing

machines.

– Do not leave children unattended near the washing machine!

– Children and uninstructed persons must not use the washing

machine!

– Keep pets away from the washing machine!

– Switch on washing machine only with base strip attached

Dilute viscous fabric softener and fabric conditioner with water.

Prevents blockage of the overflow.

Detergent drawers

with dispensers I, II, ~

Fascia

Door handle

Emergency lock release

Door

Correct installation according to separate

installation instructions.

Checking the machine

– Never switch on a damaged machine!

– Inform your customer service!

Insert mains plug

– With dry hands only!

– Take hold of the plug only!

Turn on the tap

Additional functions and option buttons

aIndividual settings, Page 5

Washing

End of programme when ...

... - ¯- is indicated on the display panel.

Terminating the programme

For programmes at high temperature:

– Cool washing: select 2 Rinse.

– Select $ Start/Pause.

For programmes at low temperature:

– Select  Spin or > Drain.

– Select $ Start/Pause.

Change programme if ...

... you have mistakenly selected a wrong programme:

– Reselect programme.

– Select $ Start/Pause.

The new programme starts from the beginning.

Cancel Programme

– Select $ Start/Pause.

– If required, top up washing (do not leave door open for a long time –

water from the washing could run out of the open door).

– Select $ Start/Pause.

Individual settings

ʑ

Option buttons

You can change the spin speed and temperature beforehand and while the selected programme is running.

Effects dependent on the programme progress.

ʑ

Temp.°C

You can change the indicated washing temperature. The maximum washing temperature which can be selected

depends on the set programme.

ʑ

 (rpm=Spin speed, revolutions per minute)/ (Rinse stop = without final

spin)

You can change the indicated spin speed or select  (rinse stop = without final spin cycle, washing remains in the

water after the last rinse cycle).

The selectable maximum spin speed depends on the model and the selected programme.

ʑ

 Ready in

The respective programme duration is displayed by selecting the programme. The programme start can be delayed

before the programme begins. The  (Ready in) time can be set in hour steps up to maximum 24h.

Keep pressing the  (Ready in) button until the required number of hours is indicated (h=hour). Select $ Start/

Pause. Settings cannot be made when the programme has started.

ʑ

Additional functions a Overview of programmes, Page 7

Eco

+

Energy-optimised washing by reducing the temperature while achieving a consistent

washing result.

The washing temperature is lower than the selected temperature. For special hygiene

requirements, the ā Allergy+ programme is recommended.

Prewash 7 For heavily soiled washing. Prewash at 30 °C.

Reduced Ironing  Special spin sequence with subsequent fluffing. Gentle final spin at reduced spin speed.

Residual moisture of the washing slightly increased.

Aqua Plus = Increased water level. Additional rinse cycle. Longer programme duration.

For areas with very soft water or for further improvement of the rinsing result.

ʑ

$Start/Pause

For starting or interrupting the programme.

ʑ

Signal

2. Set volume for ...

set to Â

1 step to right select and

hold

+

1 step to right

set to Â

direct

... Button signals

... Information

set volume * 1 step to right set volume *

* If required,

select repeatedly

1. Activate setting mode

for signal volume

release

If the Option buttons are touched for

longer, the selected options will run

automatically!

3

Programmes

For detailled overview of programmes a Page 7.

Temperature and spin speed can be selected individually irrespective of the

selected programme and programme progress.

LcCottons hard-wearing textiles

Cottons Eco hard-wearing textiles

IEasy-Care for easy-care textiles

/ Mixed Load different types of washing

 Delicates/Silk for easy-care, washable textiles

O Wool hand/machinewashable textiles

2 Rinse with subsequent spin cycle

 Spin extra spin with variable spin speed

>Drain the rinsing water when  is activated

(rinse stop = without final spin)

 Gentle Spin washing washed by hand;

gentler spin cycle

@ Super Quick extra short programme

?cPower Wash hard-wearing textiles

ā÷Allergy+ Hard-wearing fabrics;

longer washing and rinsing at a higher water level

for particularly sensitive skin

Z Sportswear textiles made of microfibres

cDark Wash dark textiles

Switching off

Turn the programme selector to Off.

Turn off tap

Not required for Aqua-Stop models.

a Information, Installation Instructions

Remove the washing

Open washing machine door and remove washing.

If  (rinse stop = without final spin) active: Set programme selector

to > Drain or  Spin. Select $ Start/Pause.

– Remove any foreign objects – risk of rusting.

– Leave detergent drawer and door open so that residual

water can evaporate.

Congratulations – You have opted for a modern, high-quality domestic appliance

manufactured by Bosch. The washing machine is distinguished by its economical

consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly to ensure that

it functions properly and is in perfect condition.

Further information on our products, accessories, spare parts and services can be found

at: www.bosch-home.com or contact our customer service centres.

Programme selector for switching

the machine on and off and for

selecting the programme.

Can be rotated in either direction.

Detergent-solution pump

Drainage hose

Beoordeling

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WIS28440GB Wasmachine. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WIS28440GB Wasmachine in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasmachines
Meer handleidingen voor Wasmachines

Veelgestelde vragen over Bosch WIS28440GB Wasmachine

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Gerelateerde producten

Handleiding

Bosch WAJ2407EPL Wasmachine

Handleiding

Bosch WGA14400IN Wasmachine

Handleiding

Bosch WAN28250NLB Wasmachine

Handleiding

Bosch WIW24307ES Wasmachine

Handleiding

Bosch WGA1320SIN Wasmachine

Handleiding

Bosch WGG244MPFGB Wasmachine

Handleiding

Bosch WIW24306ES Wasmachine

Handleiding

Bosch WAJ28080NLB Wasmachine

Gerelateerde categorieën
