– Used for designating the decimal point position (+ 0 2 3 4 6 F)
for calculated results.
+ (Add-Mode) – Addition and subtraction functions are performed
with an automatic 2-digit decimal. It is convenient for currency
calculations.
F (Floating Decimal Point) – All effective numbers up to 12 digits
are printed or displayed.
COMO CAMBIAR LA CINTA
PRINTED IN CHINA
INSTRUCTIONS
INSTRUCCIONES
INSTALLING PRINTING PAPER
REPLACING BACKUP BATTERY
Memory backup battery retains the tax rate, calendar and clock setting, when the
power is off or even when the AC cord is disconnected.
Battery : 1 Lithium battery (Type : CR2032)
Battery life : Backup time 2000 hours
Replace back-up battery
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instruction.
ESPAÑOLA
REPLACING THE INK RIBBON
ESPECIFICACIONES
ANTES DE EMPEZAR
INSTALANDO PAPEL DE IMPRESIÓN
DECIMAL POINT SELECTOR SWITCH
INTERRUPTOR SELECTOR DE PUNTO DECIMAL
ROUNDING SWITCH
CONMUTADOR DE REDONDEO
GRAND TOTAL / RATE SET SWITCH
TECLA DE GRAN TOTAL / RATE SET
IMPRESIÓN / RECUENTO ITEM
Note: Turn the power off.
1) Remove the cover and lift up the paper arm.
2) Lift ribbon spools off the shafts. Discard the old ribbon and spools.
3) Place the ribbon spool on the left spool pin and push it down until it clicks.
4) Thread the ribbon along the outer edge of the side guide, making sure
that the black half of the ribbon is still on the top.
5) Place the ribbon between the printing ring and printing roller. Thread the
ribbon along the outer edge of the left side guide.
6) Place the other ribbon spool on another spool pin.
7) Push the spool down until it clicks.
8) Take up any ribbon slack by rotating the left spool counterclockwise.
9) Replace the printer cover.
IMPORTANT: Use only the same type of ribbon spools.
BEFORE STARTING
ENGLISH
– Used for round-up [ ] , round-off [5/4], or round-down [ ]to the
pre-selected decimal digits in the result.
Print Off – Entries and results will appear on the display, but will
not be printed out.
Print On – Entries and results will appear on the display and will be
printed out.
Item – Set switch to "ITEM" to count the number of times the
, , and keys have been pressed. The item count will
be printed on the left hand side of the paper roll (up to 999 times)
when the , , or keys are pressed.
– When the calculations are performed with the GT switch set to
"ON", the total(s) are accumulated in the grand total memory.
Each time is pressed, the subtotal number is printed with the
symbols G+. When is pressed, the intermediate grand total is
printed with the symbols G . Press successively to get the
grand total followed by the symbols G .
– Set switch to "TAX RATE SET" for setting or recalling the TAX rate.
GRAND TOTAL
TAX RATE SET
PRINT / ITEM COUNT SWITCH
In the following cases, when "E" is displayed, "ERR" is printed, the keyboard is
electronically locked, and further operation is impossible.
Press to clear the overflow. The overflow occurs when:
1. The result or the memory content exceeds 12 digits to the left of the decimal
point.
2. Dividing by "0".
3. The sequential operation speed is faster than the calculation processing speed.
(Buffer Register Overflow)
Electromagnetic interference or electrostatic discharge may cause the display
to malfunction or the memory, currency rate and tax rate to be lost or altered.
Should this occur, use the tip of a ballpoint pen
(or similar sharp object) to press the [RESET] button on
the back of the calculator. After resetting be sure to set
the calendar, clock and tax rate again.
Power Source: AC120V, 60Hz
Operation Temperature: 0°C to 40°C (32°F to 104°F)
Calculating Capacity: 12 digits maximum
Dimension: 320mm (L) x 193 mm (W) x 71mm (H) /
12-39/64" (L) x 7-39/64" (W) x 2-51/64" (H)
Weight: 1,532 g (3.37 lbs)
(Subject to change without notice)
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
For CA, USA Only
Included battery contains perchlorate material - special handling may apply.
See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ for detail.
The top case, bottom case, printer cover and battery cover in this
product are made from recycled Canon copier plastic.
OVERFLOW
SPECIFICATION
REEMPLAZO DE LA BATERÍA DE RESPALDO
FUNCIÓN DE REBOSE
“ERR”
La toma de corriente debe instalarse cerca del equipo y debe ser
fácilmente accesible.
Para el Ca, los E.E.U.U. Solamente
La batería incluida contiene el material del perclorato - El manejo especial debe
ser aplicado.Para el detalle, por favor ver
http://www.dtsc.ca.gov/hazardouswaste/perchlorate
AC120V, 60Hz
Peso: 1,532 g (3.37 lbs)
320mm (An) x 193 mm (Pr) x 71mm (Al) /
12-39/64" (An) x 7-39/64" (Pr) x 2-51/64" (Al)
E-IM-2471
1) Remove the insulation tape at the back of calculator. (Figure )
2) Remove the tape on the ink ribbon of calculator. (Figure , )
3) Plug in AC power cord. (Figure )
4) Turn the power switch on. (Figure )
5) Press [RESET] key before use. (Figure )
a
b
c
d
e
f
e
f
b ca
d
Note : Turn the power off
1) Remove the printer cover (Figure ) and lift up the paper arm (Figure ).
2) Replace the printer cover (Figure ).
• When inserting the paper, cut the edge of the paper as shown (Figure ).
3) Place the new paper roll on the arm. The edge of the paper should be positioned
as shown (Figure ).
• Suitable paper roll -- Width : 57mm (2-1/4”) / Diameter: 86mm (3-3/8”)
4) Insert the paper into the slit located of the machine as indicated (Figure ).
5) Turn the power switch on (Figure ). Press the paper feed key to advance
the paper (Figure ).
e
f
b ca
d
