User Manual

Viso60 –DCF

(Mainland Europe – Not UK)

!!! PLEASE REFER TO OUR WEBSITE: WWW.GEEMARC.COM FOR AN

UP TO DATE USER GUIDE, AS THERE MAY BE IMPORTANT UPDATES

AND CHANGES YOU NEED TO BE AWARE OF!!!

1. Features

- Easy to Read and Understand Time display

- Perpetual Calendar Up to Year 2099

- 14 languages user selectable at the starting

- Hour, Day of the week, month and stage of the day modes

2. Unit Appearance

Part A - LCD

Part B - Rear part

A1: Day of Week or Month

A2: Stage of the day

A3: Analog Time

A4: Radio Control Icon

B1: “SET” Button

B2: “▲” Button

B3: “▼” Button

B4: “RESET”

Part C - Structure

Part D – Analog Setting

C1: Hanging Hole

C2: Battery Door

D1: REC button

D2: Transportation pin

D3: M Set button

D4: Reset button

D5: Battery compartment

3. ANALOGUE CLOCK(A3)

3.1 GETTING STARTED/POWER SUPPLY

(1) Remove the transportation pin (D2) from the clock movement. The

clock can be operated only after the pin has been removed.

(2) Insert one battery (1.5V, AA/LR6) into battery compartment

(D5). Make sure to place the battery strictly according to the

right polarities (+/-) as shown in the battery compartment.

3.2 TIME SETTING

After the clock has received the DCF time signal the time will be set

according to the Central European time(CET). Summer and winter

time change (and reverse) is also set automatically. Other deviating

times can be set manually only.

3.3 Automatic time setting via DCF time signal

After inserting the battery, the time will be set automatically via DCF

signal. This process may take a few minutes (about 5-7 minutes).

During this process, the clock hands will turn several times and may

pause until they display the right time.

3.4 Initiate to receive the DCF time signal manually

Use this function when automatic summer/winter time change does

not work or the wall clock temporarily receives no time signal.

(1) Press and hold the REC button (D1) for 3 seconds to start manual

search for the DCF signal.

(2) The clock hands will move to their start position (12:00 a.m.)

and the wall clock then tries to receive the signal.

Wait approx. 2-5 minutes until the current time will be displayed.

3.5 Manual time setting

It is necessary to set the time manually in places where no radio signal

is received.

(1) Press and hold the M.SET(D3) button for approx. 3 seconds.

(2) When the minute’s hand starts moving you can set the time manually:

- Press the M.SET(D3) button to set the time in minutes.

- Press and hold the M.SET(D3) button to set the time continuously.

(3) Release M.SET(D3) button to stop manual setting and save the time

automatically. Exit the manual time setting mode.

3.6 Reset

If there is no response from the 2

nd

hand on the wall clock or if any

other malfunction occurs perform the following steps.

With this procedure all received data will be deleted.

(1) Press RESET(D4) button with a pointed instrument (e.g. pen).

(2) The clock hand will move to the start position (12:00 a.m.) and the

wall clock will try to receive the signal.

Wait approx. 2-5 minutes until the current time will be displayed.

4. DIGITAL CLOCK

4.1 Getting started:

⚫ Open battery Cover (C2).

⚫ Insert 2 x AA size batteries observing polarity (+ and –). You will hear

a “click” sound which will confirm the batteries have been inserted

correctly.

⚫ Replace battery compartment cover (C2).

4.2 To begin

You have 1 minute to arrange the first setting. The clock displays

English, press “▲” (B2) or” ▼” (B3) to select your language and

press “SET” (B1) to validate, Press” ▲”(B2) or ” ▼”(B3) to choose

the type of display set and press “SET”(B1) to validate (see below the

different display methods).

If you don’t press any keys, after 1 minute the Viso60 will launch the

automatic clock setting.

Note: Place the Viso60 near a window for

the clock to automatically set.

-DP-1 displays the day of the week and the

2

nd

line the part of the day.

-DP-2 displays the Month and the 2

nd

line

the date and the year. -DP3 will display

the first 2 display types one after the other

for XX seconds (see section 4.4.C to set the

time).

4.3 Radio Controlled Time:

⚫ The clock automatically starts to scan the DCF time signal in the first

10 minutes. (Radio Control Icon “ ” (A4) flashes on LCD).

(A4) flashing

Indicates the DCF signal is being

received

(A4) Continuous

Indicates signal received successfully

(A4) Icon disappears

Indicates signal reception failed

C1

B3

B1

B2

B4

C2

A1

A2

A4

A3
