Handleiding Ariston N11HPLWAUS Wasdroger

Handleiding

You can download the Safety Instructions, User Manual by:

• Visiting our website - www.aristonbrand.com

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product’s identi cation plate.

THANK YOU FOR BUYING A ARISTON PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.aristonbrand.com

EN

Quick guide

Before using the appliance carefully read the Safety Instructions.

xxxxxxxxxxxx

xxxx

PROGRAMMES

1.Mixed kg 4

This programme is ideal for drying cotton and synthetic fabrics

together.

2.Eco cotton kg Max*

Standard cotton programme, suitable to dry normally wet

cotton laundry. Most ecient programme in terms of energy

consumption for drying cotton laundry. The values on the Energy

Label are based on this programme.

3.Synthetics kg 4

This programme is suitable for synthetic garments or cotton

blends/synthetic.

4.Wool kg 1

Programme for drying wool clothing. It is advisable to turn the

garments inside out before drying. Leave to dry naturally the heaviest

edges that are still damp.

5.Silk kg 0,5

Gentle drying of silk garments.

6.Anti Allergy kg Max*

This cycle has the “Allergy UK” approval of “The British Allergy

Foundation” attesting the eective reduction and elimination of

allergens. It can be used both with damp load (drying and treatment)

and dry load (half load only).

7.Daily kg 2

Ideal for drying garments of cotton blends or synthetics spun at

high speed in the washing machine.

8.Cuddly Toys Kg 2,5

The cycle preserves the original appearance and brilliance of the cuddly

toys at best. Remove all accessories before proceeding with drying.

Every single piece must not exceed 600 gr.

FIRST TIME USE

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dyrer is properly xed,

either to the dryers's water tank or to the domestic sewage

system.

The dryer should be installed in environment in a room

temperature range of 20°to 23°C for optimum performance. But

will function if the room is between 14 and 30°C. Before you use

your dryer ensure that it has been in a upright position for at

least 6 hours.

Should you wish to change the opening side of the door, please

contact our After-sales Service. (See phone number in the

warranty booklet).

DAILY USE

Doing this will keep your machine working at its BEST!

Remember to empty your water tank after each drying cycle.

Remember to clean your lters after each drying cycle. (Refer to

section Care & Maintanence).

1. Open the door and load garments. Always refer to instructions

on clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter.

2. Close the door.

3. Press the button On/O.

4. Select the programme according to the laundry type.

5. Select the options, if necessary.

6. To start the cycle, press the Start/Pause button.

7. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry.

8. Turn the machine o by pressing the button On/O, open the

door and pull clothing out. If the machine is not switched o

manually, after about a quarter of an hour from the cycle end, the

appliance turns o automatically to save energy.

If this last stage is not carried out immediately, some machines

and/or some programmes/options are equipped with Crease Care

system. For some hours, after the end of drying, the drum rotates

at regular intervals to prevent the formation of creases.

In case of power failure, it is necessary to press the button Start/

Pause to restart the cycle.

OPENING OF THE DOOR DURING THE CYCLE

During operation, it is possible to open the door. After having

closed it, press the button Start/Pause again to restart the dryer.

*MAX LOAD 8 Kg (Dry load)

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

CONTROL PANEL

1 ON/OFF Button (Reset if long pressed)

2 Programme Selection Knob

3 Start/Pause Button

Options Buttons*

4 Active Care

5 Dryness Level

6 Start Delay

7 Timed Drying

8 Cycle End

9 Gentle (Key lock if long pressed)

10 Crease Care (Mute if long pressed)

*Note: some models may have the wording in full instead of the icons

INDICATORS

Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry

Cycle Phase: Drying - Cool Down - END End of Cycle -

Empty water tank - Clean door lter - Clean bottom lter -

Refer to troubleshooting section: Failure: Call after sales service.

DEMO

Demo Mode.

3 “

3 “

END

1

3

2

4

10

8

9

5 67

DEMO

h
