Handleiding Axiom 5.0 Fietscomputer

Handleiding

Wireless

Cyclocomputer

Initial Set Up

Your Axiom 5.0W will compute distance and speed functions in either miles or kilometers. After installing the

battery the kilometer (km/h) and mile (m/h) symbols will alternately be displayed. When the desired measur-

ing units are displayed (i.e. km/h or m/h), press the gray button. The wheel circumference value of 2124

(or your latest wheel circumference setting) will then be displayed.

If you already know your wheel circumference, go to - Programming Wheel Circumference, otherwise go to -

Determining Wheel Circumference.

Programming Wheel Circumference and Odometer

When you know your wheel circumference, you are ready to program your wheel circumference into your

computer.

If the computer is in the wheel circumference setup mode go to The wheel circumference value…

(fourth paragraph down).

If you are not in wheel circumference setup mode, press the gray button until the ODO, odometer, is dis-

played on the screen. Press the gray button for two seconds, the kilometers (km/h) and mile (m/h) symbols

will alternately be displayed. When the desired measuring unit is displayed (i.e. km/h or m/h), press the

gray button.

The wheel circumference value of 2124 (or your latest wheel circumference setting) will be displayed.

If the wheel circumference value shown is correct, press the gray button within 2 seconds to complete

setup mode.

If you must change the wheel circumference value, wait two seconds and the right digit will begin to

increase. When the correct digit is displayed press the gray button, the next digit will automatically begin

changing. Repeat this process until all four digits display the correct wheel circumference. In the miles

mode, once completed you will be out of setup mode.

If you are using kilometer mode, the odometer, ODO, may be programmed. Once the wheel circumference is

programmed, the odometer will be shown. Program the ODO in the same manner as the wheel circumference

or, if the ODO reading is correct, press the gray button six times to exit set up mode.

Note 1: You cannot program the odometer, ODO, in miles mode.

Note 2: Your Axiom computer has the ability to easily convert miles into kilometers and vice versa. After

you configure your initial settings, you may switch measuring units at any time. Press the gray button until

you get to ODO. Press and hold for two seconds the gray button. After choosing the desired unit of measure,

press the gray button twice and you will have converted units in your computer.

Wired

Cyclocomputer

Initial Set Up

Your Axiom 5.0 will compute distance and speed functions in either miles or kilometers. After installing the

battery the kilometer (km/h) and mile (m/h) symbols will alternately be displayed. When the desired measur-

ing unit is displayed (i.e. km/h or m/h), press the gray button. The wheel circumference value of 2124 (or

your latest wheel circumference setting) will then be displayed.

If you already know your wheel circumference go to - Programming Wheel Circumference, otherwise go to -

Determining Wheel Circumference

Programming Wheel Circumference and Odometer

When you know your wheel circumference, you are ready to program your wheel circumference into your

computer.

If the computer is in the wheel circumference setup mode go to The wheel circumference value … (forth

paragraph down).

If you are not in wheel circumference setup mode, press the gray button until the ODO, odometer, is dis-

played on the screen. Press the gray button for two seconds, the kilometer (km/h) and mile (m/h) symbols

will alternately be displayed. When the desired measuring units are displayed (i.e. km/h or m/h), click the

gray button.

The wheel circumference value of 2124 (or your latest wheel circumference setting) will be displayed.

If the wheel circumference value shown is correct, press the gray button within 2 seconds to complete

setup mode.

If you must change the wheel circumference value, wait two seconds and the right digit will begin to

increase. When the correct digit is displayed press the gray button, the next digit will automatically begin

changing. Repeat this process until all four digits display the correct wheel circumference. In the miles

mode, once completed you will be out of setup mode.

If you are using kilometer mode, the odometer, ODO, may be programmed. Once the wheel circumference is

programmed, the odometer will be shown. Program the ODO in the same manner as the wheel circumference

or, if the ODO reading is correct, press the gray button six times to exit set up mode.

Note 1: You cannot program the odometer, ODO, in miles mode.

Note 2: Your Axiom computer has the ability to easily convert miles into kilometers and vice versa. After

you configure your initial settings, you may switch measuring units at any time. Press the gray button until

press the gray button twice and you will have converted units in your computer.

Battery Installation and Replacement

Using a coin or screwdriver, open the battery cover by twisting counterclockwise.

Place the battery into the compartment with the positive side (+) facing up. Replace

the battery cover. When no battery is in the unit, stored information will be preserved

for approximately 15 seconds.

For 5.0: Use a screwdriver to remove the battery cover.

Use battery type 2032 (or equivalent) as replacement for the computer.

The 5.0 uses a A76 (or equivalent) battery.

Resetting the Computer

If the display shows irregular numbers, press the AC (Auto Clear) button on the back of the unit.

To clear the display on the 5.0, remove and reinstall the battery.

Note: This deletes all stored information.

Owner’s Manual

Cyclocomputers

Trouble Shooting

If the speed display does not appear :

Be sure the magnet and transmitter are properly aligned, and the distance between them is correct.

Cadence model only: If the cadence (

C)does not appear, check that alignment of the cadence magnet and

sensor is correct.

If the display fades :

Check the battery contacts. Replace the battery if necessary.

Replacing the Transmitter Battery On Wireless Models

Using a coin, open the transmitter battery cover by twisting counterclockwise. Place the

battery into the compartment with the positive side (+) facing up/outward. Replace the bat-

tery cover.

Use only an alkaline 23A, 12V battery as replacement.

Use battery type MN21 (23A, 12V) as replacement for the transmitter.

Waterproof

Your computer was designed to be waterproof. But if you do use the computer in the rain, it is

recommended to dry it thoroughly with a dry cloth, making sure to remove the computer from

the handlebar mount and drying between the computer and handlebar mount.

+

Determining Wheel Circumference

In order for the Axiom Cyclocomputer to accurately compute distance and speed, you must enter your actu-

al wheel circumference. There are two methods of determining your wheel circumference: 1) the Tire Size

Chart Method or 2) the Roll Out Method (the Roll Out Method gives you a higher degree of accuracy).

Method 1 - Tire Size Chart Method

Using the chart below, locate the size of tire that you will be using on your front wheel. The wheel circum-

ference (in mm) is shown to the right of the tire size.

Example: for a tire size of 700x25, the corresponding wheel circumference is 2086 mm - 2086 is the number

you need to program into your computer.

20 x 1.75

24 x 1

24 x (Tubular)

26 x (Tubular)

26 x 1

26 x 1.25

26 x 1.5

26 x 1.9

26 x 2.2

26 x 1

3

⁄8

27 x

5

⁄8

27 x 1

27 x 1

1

⁄8

27 x 1

1

⁄4

700C (Tubular)

700 x 20

700 x 25

700 x 28

700 x 32

700 x 35

1528

1753

1759

1929

1913

1967

1974

2048

2074

2068

2077

2105

2123

2142

2083

2058

2086

2096

2114

2139

Tire Size Wheel Circumference (mm)

Wheel Circumference (mm)

Tire Size

Method 2 - Roll Out Method

Stand your bicycle upright. With your tire inflated to its proper pressure, rotate your wheel so that the valve

is located at the bottom. Make a mark of the valve’s location on the floor. Roll the bicycle one complete

wheel revolution, in a straight line, until the valve is again at the bottom. Mark this new location of the

valve on the corresponding point on the floor. Measure the distance between the marks, in millimeters (mm).

This is the value of the wheel circumference that you need to program in to your computer. (Note: inches multi-

plied by 25.4 converts inches into mm; i.e. 1 inch = 25.4 mm).

Distance (in mm)Valve Valve

Wired

Cyclocomputer

Initial Set Up

Your Axiom 8.0 will compute distance and speed functions in either miles or kilometers. Press the MODE button

until ODO, odometer, is displayed. Press both buttons at once for two seconds, the kilometer (km/h) or the mile

(m/h) symbols will be displayed. Press the MODE button to toggle between the measuring units (i.e. km/h

or m/h). Once the desired measuring unit is displayed, press the RED button to exit set up mode.

If you already know your wheel circumference go to - Programming Wheel Circumference, otherwise go to -

Determining Wheel Circumference.

Programming Wheel Circumference and Odometer

When you know your wheel circumference, you are ready to program your wheel circumference into your

computer.

If the computer is in the wheel circumference setup mode go to If you must change the Odometer value

(below).

If you are not in wheel circumference setup mode, press the MODE button until the ODO, odometer, is

displayed on the screen. Press the RED button for two seconds, until the wheel circumference value of 2124

(or your latest wheel circumference setting) is displayed and blinking.

If the wheel circumference value shown is correct, press the RED button five times; you will then be in the

odometer set up mode (fourth paragraph down).

If you must change the wheel circumference value, press the MODE button to change the blinking digit.

When the correct number is displayed press the RED button, the next digit will automatically begin blinking.

Repeat this process until all four digits display the correct wheel circumference. Once the last digit is correct,

press the RED button twice and you will be in odometer set up mode.

If you must change the odometer value, press the MODE button to change the blinking digit. When the correct

number is displayed press the RED button, the next digit will automatically begin blinking. Repeat this process

until all five digits display the desired odometer value. Once the last digit is correct, press the red button

and you will exit set up mode.

Note: Your Axiom computer has the ability to easily convert miles into kilometers and vice versa. After you

configure your initial settings, you may switch measuring units at any time. Press the MODE button until you

get to ODO. Press and hold both buttons for two seconds. Using the MODE button select the desired unit of

measure, press the RED button and you will have converted units in your computer.

Your computer can switch between two wheel settings. The top left corner of the display indicates which

wheel setting you computer is set to, either wheel setting ((1)) or ((2)).

To program a second wheel circumference size, press the MODE button until the ODO, odometer, is displayed on

the screen. Press the RED button for two seconds, until the wheel circumference value of 2124 (or your latest

wheel circumference setting) is displayed and blinking. Press the RED button again for two seconds to tog-

gle between wheel setting ((1)) and ((2)). See section above on how to program the wheel circumference.

Axiom Series Owner's Manual 3/30/99 11:56 AM Page 1 (1,1)
