Handleiding Black and Decker WM1404S Wafelijzer

Handleiding

FLIP WAFFLE MAKER

MODEL

❍ WM1404S

Customer Care Line:

USA 1-800-231-9786

Accessories/Parts (USA)

1-800-738-0245

For online customer service

and to register your product, go to

www.prodprotect.com/applica

3

2

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

❍

Read all instructions.

❍

Do not touch hot surfaces. Use handles or knobs.

❍

To protect against electric shock do not immerse cord, plugs or appliance

in water or other liquid.

❍

Close supervision is necessary when any appliance is used by or near

children.

❍

Unplug from outlet when not in use and before cleaning. Allow to cool

before putting on or taking off parts, and before cleaning the appliance.

❍

Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions or has been damaged in any manner. Return

appliance to the nearest authorized service facility for examination, repair

or adjustment. Or, call the appropriate toll-free number on the cover of

this manual.

❍

The use of accessory attachments not recommended by the appliance

manufacturer may cause injuries.

❍

Do not use outdoors.

❍

Do not let cord hang over edge of table or counter, or touch hot surfaces.

❍

Do not place on or near a hot gas or electric burner, or in a heated oven.

❍

Extreme caution must be used when moving an appliance containing hot oil

or other hot liquids.

❍

Always attach plug to appliance first, then plug cord into the wall outlet.

To disconnect, turn any control to OFF, then remove plug from wall outlet.

❍

Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To reduce

the risk of electric shock, this plug is intended to fit into a polarized outlet only one

way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw

to prevent removal of the outer cover. To reduce the risk of fire or

electric shock, do not attempt to remove the outer cover. There are

no user-serviceable parts inside. Repair should be done only by

authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to

be provided to reduce the risk resulting from becoming entangled

in or tripping over a longer cord.

b) Longer detachable power-supply cords or extension cords are

available and may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply

cord or extension cord should be at least as great as the

electrical rating of the appliance,

2) If the appliance is of the grounded type, the extension cord

should be a grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over

the countertop or tabletop where it can be pulled on by children

or tripped over.

Note: If the power supply cord is damaged, it should be replaced by

qualified personnel; in Latin America, by an authorized service center.

This symbol is placed near information that

requires your special attention.

ENGLISH

5

4

Product may vary slightly from what is illustrated.

1. Cool-touch handle

2. Handle lock

3. Rotate & cook system

4. Nonstick waffle plates (inside unit)

5. Power indicator light

6. Temperature ready indicator light

7. Waffle ready indicator light (on flip side)

† 8. Drip tray (Part # 1404S-01)

9. Unit base

Note: † indicates consumer replaceable/removable parts

ENGLISH

How to Use

This product is for household use only.

GETTING STARTED

• Remove all packing material and any stickers.

• Remove and save literature

• Please go to www.prodprotect.com/applica to register your

warranty.

• Open the waffle maker by lifting the cool-touch handle (A).

• This appliance has no removable parts. Wipe the waffle

plates and the outside with a damp cloth or sponge to remove

any dust. Wipe dry with a soft cloth or paper towels.

• Select a location where this appliance is to be used and allow

enough space between the back of the appliance and the

wall. This allows heat to flow without damage to cabinets and

walls.

PREHEATING THE WAFFLE MAKER

1. Before first use, condition the nonstick waffle plates by brushing or wiping a light

coating of cooking oil (vegetable, canola or corn oil) onto the entire cooking surface.

Wipe off excess oil with a paper towel.

Important: Do not use aerosol cooking spray because the chemicals that allow the spray

to come out of the can will build up on the surface of the waffle plates and reduce their

effectiveness.

2. Close the waffle maker by using the cool-touch handle.

3. Remove tie, unwind the cord and plug it into a standard

electrical outlet.

4. The red power indicator light comes on and the waffle maker

begins to preheat (B). This light remains illuminated until the

waffle maker is unplugged.

Important: This waffle maker gets hot. When in use or until it has cooled

completely do not touch any of the metal surfaces. Use the cool-touch handle to

open and close the waffle maker.

5. Allow the appliance to preheat. The green temperature ready indicator light illuminates

when the waffle maker is ready for use.

Note: During the initial preheating, you may notice smoke and a slight odor. This is normal

and should cause no concern.

Important: The green temperature ready indicator light next to the power indicator light,

only lets you know when the waffle maker has reached the cooking temperature. It cycles

on and off during cooking. It is not an indication that the waffle has finished cooking.

BAKING WAFFLES

1. Preheat waffle maker as described above.

2. Open the waffle maker by lifting the cool-touch handle, and pour about ¾ cup

(177 ml) into the center of the lower waffle plate.

Note: To avoid batter running over the edges do not overfill.

3. Close the waffle maker by using the cool-touch handle, but do not force it shut.

A

B



















7

6

Important: This waffle maker gets hot. When in use or until it has cooled

completely, do not touch any of the metal surfaces. Use the cool-touch handle to

open and close the waffle maker.

4. Wait 10 seconds. Turn the cool-touch handle to the right

(clockwise) until the waffle maker is upside down (C).

Note: There may be some condensation that will be visible on the

outside of the waffle maker, this is normal.

5. Allow the waffle to cook until steaming subsides and the green

waffle ready indicator light illuminates (about 3 to 4 minutes).

For a crisper waffle cook the waffle a little longer.

Note: Avoid opening the waffle maker while waffle is cooking.

This may cause the waffle to stick or cook poorly.

6. When cooking is finished, turn the cool-touch handle to the left (counterclockwise).

7. Open the waffle maker and remove the waffle using a heat resistant nonstick spatula or

tongs.

Note: Do not use metal utensils to remove waffles. They may damage the nonstick surface.

Important: Do not open the waffle maker before the waffle ready indicator light

is illuminated. If waffle is not fully cooked, it may split and be difficult to remove.

8. Close the waffle maker and allow it to reheat before cooking another waffle. The green

temperature ready indicator light illuminates when the waffle maker is ready for use.

Note: If you have conditioned the waffle maker you may want to discard the first waffle as it may

be too oily. (See step 1 in PREHEATING THE WAFFLE MAKER.)

9. When finished, unplug the waffle maker. Allow it to cool completely.

Important: This waffle maker gets hot. When in use or until it has cooled

completely, do not touch any of the metal surfaces. Use the cool-touch handle to

open and close the waffle maker.

10. Use a brush to remove any crumbs from the waffle maker.

USEFUL TIPS

• Fully cooked waffles freeze well. When cooled to room temperature, simply wrap individually

in plastic wrap or place in freezer bag and close airtight. They can be kept frozen for several

months.

• Packaged pancake mix, including the whole wheat variety make delicious waffles. Follow the

package directions for waffles.

• Don’t use water to clean the nonstick waffle plates, simply allow it to cool and brush off any

crumbs that may be left in the grids. Cotton swabs are handy for cleaning between the ridges.

• For lighter waffles, separate the eggs and beat the egg whites to soft peaks and fold in just

before cooking the waffles.

• For extra crispy waffles, add 2 to 3 tbsp of melted butter or oil to the batter.

• Waffles can be kept warm by placing them on a rack or a cookie sheet in a preheated oven set

to 300ºF.

• Never stack cooked waffles; this makes them soggy.

• To reheat waffles, use your preheated toaster oven and set it to 350º F, for about 5 minutes.

• Using a waffle mix? Add some excitement! Just before cooking, stir in:

o Mashed banana

o Chopped walnuts, macadamia nuts, toasted almonds or pecans

o Diced fruit, such as, apples, peaches, plums or berries

ENGLISH

o Well drained crushed pineapple

o Chopped cooked bacon, ham or crumbled sausage

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service

personnel.

CLEANING

1. Before cleaning, make sure the unit is unplugged and the waffle maker has cooled

completely.

Important: This waffle maker gets hot. When in use or until it has cooled

completely, do not touch any of the metal surfaces. Use the cool-touch

handle to open and close the waffle maker.

2. Wipe the cooking surfaces with a damp sponge or cloth.

Important: Never immerse the waffle maker in water or other liquids or

place in a dishwasher. Do not run water directly onto the nonstick waffle

plates.

3. To remove cooked on food, use a plastic bristle brush or nylon mesh pad. Make sure

to clean the handles after each use.

Important: Do not use steel wool or other abrasive cleaners on the cooking surfaces,

as they may damage the non-stick coating.

4. Clean the outside surfaces by wiping with a damp or soapy sponge or cloth.

Dry

thoroughly with a soft cloth.

Important: Do not use harsh or abrasive cleaners that may scratch or mar

the exterior surfaces. Never spray or apply cleaners directly to the waffle

maker; instead, apply the cleaner to a cloth and rub on.

STORAGE

To save space on storage, the cool-touch handle bends

inward to the right (D).

C

D
