005 TDA56..GB ECO/09/12

Customer Service

Great Britain

Bosch Customer Service

Grand Union House

Old Wolverton Road

Milton Keynes

MK12 5PT

UK +44 (0)844 892 8923

IRL +353 (0)1450 2655

www.bosch-home.co.uk

Operating instructions

Solving Minor Problems Yourself

Thank you for buying the TDA56 eco steam iron from Bosch.

These instructions contain valuable information about the unique

features of this iron and some hints to make ironing easier for you.

Please visit www.bosch-home.co.uk for more product

information or to register your product, just follow the

link to the Online guarantee registration.

Important

This appliance has been designed exclusively for domestic

use and must not be used for industrial purposes.

Carefully read through the operating instructions for the

appliance and safeguard them for future reference.

General safety instructions

• The iron must not be left unattended while it is

connected to the supply mains.

• Remove the plug from the socket before filling the

appliance with water or before pouring out the

remaining water after use.

• The appliance must be used and placed on a stable

surface.

• When placed on its stand, make sure that the surface

on which the stand is placed is stable.

• The iron should not be used if it has been dropped,

if there are visible signs of damage or if it is leaking

water. It must be checked by an authorized Technical

Service Centre before it can be used again.

• With the aim of avoiding dangerous situations, any

work or repair that the appliance may need, e.g.

replacing a faulty mains cable, must only be carried

out by qualified personnel from an Authorised

Technical Service Centre.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

• Keep the iron and its cord out of reach of children less

than 8 years of age when it is energized or cooling

down.

•

CAUTION. Hot surface.

Surface is liable to get hot during use.

Environmental Care

This iron has been redesigned according to ecological criteria,

related to the sustainable development, analyzing its whole

lifecycle - from material selection to its later reusing or recycling

- evaluating the improvement possibilities, from a technical,

economical and environmental point of view.

Green Technology inside:

Energy saving “e” setting:

24 % energy saving*

100% recycled material was used for user manual and cardboard

100% of packaging, filling cup and user manual can be recycled

80% of the appliance can be recycled

*in comparison to the maximum steam setting of a regular 2400

Watt max Bosch iron

Before throwing a used appliance away, you should make it

noticeably inoperable e.g. cut off the mains lead and be certain

to dispose of it in accordance with current laws and regulations.

Your retailer, town council or local council can give you detailed

information about these.

This appliance is labelled in accordance with

European Directive 2012/19/EU concerning used

electrical and electronic appliances (waste

electrical and electronic equipment - WEEE).

The guideline determines the framework for the

return and re cycling of used appliances as applicable

throughout the EU.

Before using the Iron for the first time

Please carry out the following steps:

1. Remove the protective cover from the soleplate before using

the iron.

2. While the iron is unplugged, fill the water tank (D) with tap water

3. Plug the appliance into the mains and set the temperature

control (H) to the “•••” position by lining it up with the pointer

(G) on the iron.

4. When the iron has reached the correct temperature (the pilot

lamp “I” will go out), set the steam regulator (A) to the maximum

position .

5. Hold the iron horizontally and repeatedly press the shot of steam

button (L). Any residue should come out of the soleplate (E).

It may smoke and smell – this is normal and will cease after a

short while.

6. If necessary, carefully clean the soleplate down with a dry,

folded cloth

TDA56..

sensixx B4 eco

• This appliance is to be connected and used in accordance with

the information stated on its characteristics plate.

• This appliance must be connected to an earthed socket. If it is

absolutely necessary to use an extension cable, make sure that

it is suitable for 16A and has a socket with an earth connection.

• If the safety fuse fitted in the appliance blows, the appliance

will be rendered inoperative. To restore normal operation the

appliance will have to be taken to an authorised Technical

Service Centre.

• In order to avoid that, under unfavourable mains conditions,

phenomena like transient voltage drops or lighting fluctuations

can happen, it is recommended that the iron is connected to a

power supply system with a maximum impedance of 0.27Ω . If

necessary, the user can ask the public power supply company

for the system impedance at the interface point.

• The appliance must never be placed directly under the tap to

fill the water tank.

• Unplug the appliance from the mains supply after each use, or

if a fault is suspected.

• The electrical plug must not be removed from the socket by

pulling the cable.

• Never immerse the iron in water or any other fluid.

• Do not leave the appliance exposed to weather conditions (rain,

sun, frost, etc.).

Tips to help you save energy

Steam production consumes the most energy. To help minimise

the energy used, follow the advice below:

• Start by ironing the fabrics that require the lowest ironing

temperature.

• Regulate the steam according to the selected ironing

temperature.

• Only use steam if necessary. If possible, use the spray function

instead.

• Try to Iron the fabrics while they are still damp and reduce the

steam setting. Steam will be generated from the fabrics rather

than the iron. If you tumble dry your fabrics before ironing them,

set the tumble drier to the ‘iron dry’ programme.

• If the fabrics are damp enough, turn off the steam regulator

completely.

• Stand the iron upright during pauses. Resting it horizontally

with the steam regulator on generates wasted steam.

GUARANTEE TERMS

The terms of the guarantee for this appliance are in accordance

with that stated by our representative for the country in which

it is sold. Details of those conditions can be obtained from the

retailer from whom the appliance was purchased. The SALES

RECEIPT must be presented when making any claims against the

terms of this guarantee. We reserve the right to make technical

modifications.

You can download this manual from the local homepages of Bosch

max.

Problem Possible Causes Solution

Iron does not

work or is not

heating up

Temperature control (H) set to

minimum

Turn the temperature

control to the desired

position

Connection problems Check that the plug is

inserted into the mains

socket correctly

The automatic shut-off system

has been activated (*)

Move the iron gently from

side to side to re-start it

Iron is not

steaming

There is no water in the tank (D) Fill the water tank

The steam regulator (A) is in

the

position

Set the steam regulator to

the relevant position

Water is dripping

from the holes in

the soleplate

Temperature control (H)

setting is too low.

Set the temperature control

within the steam area

(between the “••” and

“max”) or turn the steam

regulator (A) to

Steam regulator (A) is set too

high in conjunction with a low

temperature.

Turn the steam regulator to

a lower setting.

You have pressed the shot of

steam button (L) repeatedly

without waiting for 5 seconds

between each press

Wait 5 seconds between

each press of the jet of

steam button

Water has been left in the tank

(D) when the sole plate was

cold, with the steam regulator

(A) set at

or

Always empty the tank

after ironing and set the

steam regulator to

after

ironing and when filling the

tank

Distilled water has not been

used (see “Filling the water

tank” section) or other

products such as fragrant

water have been added to

the tank

Mix distilled water with

tap water as directed in

the “Filling the water tank”

section and never add any

other products to the water

tank

Spray does

not work.

No water in the tank. Add water to the water

tank.

Obstructed mechanism. Contact an Authorised

Technical Service Centre.

The iron

begins to

smoke when

switched on.

During first use: Certain

components on the appliance

have been lightly greased at

the factory and may produce

a little smoke when initially

heated.

This is completely normal

and will stop after a short

while.

Deposits

come out

through the

holes in the

soleplate

Traces of lime scale are

coming out of the steam

chamber

Carry out a cleaning cycle

(see “self cleaning” section)

Flashing lamp

on top of

handle

Auto-shut off has been

activated.

Move the iron gently

fromside to side to re-start

it. The lamp will then flash

once before it re-heats
