1 2 3 4 5 6

¥Ê - ɯ Temp. °C ~ Select the temperature (¥Ê = cold)

- - - - - ³¯¯* rpm  Select the spin speed (* depending on the model) or

- - - - (Rinse stop (Spülstop) = no final spin, laundry soaks in

the last rinsing water, display panel - - - -)

³¤ - ¤ Ready in Programme end after

Status indicators Programme status indicators:

1üü2üücü§Ê Wash, rinse, spin, programme duration or end

'

Childproof lock a page 5

Programme selector for switching

the machine on and off and for

selecting the programme. Can be

turned in either direction.

Programme selectorDisplay panel

Function/option buttons

Start/

Pause

Individual settings

ʑ

Signal

1. Activate the setting mode for the signal volume

2. a) Set the volume for button signals( depending on model)

2. b) Set the volume for information signals

Information on the display panel depending on model

§: ³Å Turn the (cold water) tap on fully;

supply hose kinked/trapped;

water pressure too low; service, clean the filter a page 10,

§: ³µ Detergent solution pump blocked; service, clean the detergent solution pump

a page 10.

Drainage hose/waste pipe blocked; service, clean the drainage hose at the siphon

a page 10.

§: ´ Water in the base tub, appliance leaking. Turn off the tap. Call the after-sales service.

' Childproof lock active; Deactivating a page 5.

Other

displays

Switch off the appliance, wait for 5 seconds and switch it back on again. If the display

appears again, call the after-sales service.

rpm 

+

To activate the

setting mode

set to Â

press and

hold

turn one

position to

the right

press and hold for a

further 5 secs until the

display elements light up;

setting mode is activated

rpm 

set to  to exit the setting

mode for the signal

volume

press repeatedly until

the desired volume is

reached

or

rpm 

turn one

position to

the right

press repeatedly until the

desired volume is

reached

set to  to exit the

setting mode for the

signal volume

rpm 

Sorting and loading laundry

Follow the manufacturer's care information.

According to the information on the care labels.

According to type, colour, soiling and temperature.

Do not exceed the maximum load a page 7.

Observe the important information a page 9.

Load items of laundry of varying sizes.

Close the washing machine door. Take care not to trap items of laundry

between the washing machine door and the rubber seal.

Adding detergent and care products

Measure accordingly:

Amount of laundry, level of soiling, water hardness (ask your water

supply company) and manufacturer's instructions.

Models without insert for liquid detergent:

Pour liquid detergent into the appropriate dispenser and place in

the drum.

During operation: Open the detergent drawer with care.

Insert for liquid detergent (depending on model), page 10.

Your washing machine Intended use

Contents Page

ʋ Intended use ...................................................................................... 1

ʋ Programmes ...................................................................................... 1

ʋ Setting and adjusting the programme .......................................... 3

ʋ Washing .......................................................................................... 3/4

ʋ After washing ..................................................................................... 4

ʋ Individual settings ......................................................................... 5/6

ʋ Information on the display panel ................................................... 6

ʋ Programme overview ....................................................................... 7

ʋ Safety instructions ............................................................................. 8

ʋ Consumption values ......................................................................... 8

ʋ Important information ...................................................................... 9

ʋ Insert for liquid detergent ................................................................ 9

ʋ Cleaning and care ......................................................................9/10

ʋ Maintenance .....................................................................................10

ʋ What to do if ... ................................................................................11

Environmental protection/Conservation tips

– Always fill the washing machine with a maximum amount of laundry for

the particular programme.

– Wash normally soiled laundry without a prewash.

– The selectable temperatures apply to the care labels on the textiles.

The temperatures in the machine may deviate from this so that you get

the optimum mix of energy-saving and washing results.

– Measure the detergent according to the manufacturer's instructions

and water hardness.

– If the laundry is subsequently dried in a tumble drier, select the spin

speed according to the tumble drier manufacturer's instructions.

Preparation

Before washing for the first time

Run a wash cycle without any laundry a page 9

Setting** and adjusting programmes

1

2

Washing

Compartment ~: fabric softener, starch

Compartment I: detergent for prewash

ʋ For use in the household only

ʋ For machine-washable fabrics and hand-washable wool

in detergent solution,

ʋ To be operated with cold drinking water and commercially

available detergents and care products which are suitable

for use in washing machines

ʋ The washing machine may be used by children over the

age of 8 years old and by persons with reduced physical,

sensory or mental capacity or by persons with a lack of

experience or knowledge if they are supervised or have

been instructed by a responsible person.

– Observe the safety instructions on page 8.

– Do not leave children unattended near the washing

machine.

– The washing machine is not to be used by children

or persons not familiar with the operating

instructions.

– Keep pets away from the washing machine.

Read these instructions and the separate installation

instructions before operating the washing machine.

Dilute thick fabric softener and conditioner with water.

This prevents blockages.

Detergent drawer

with compartments I, II, ~

Control panel

Service flap

Washing machine door

Correct installation according to the

separate installation instructions.

Checking the machine

– Never use a damaged machine.

– Inform the after-sales service.

Connecting the mains

plug

– Make sure your hands are dry.

– Take hold of the plug only.

Turning the tap on

Washing

End of programme when...

... §Ê appears on the display panel.

Interrupting the programme

Programmes at high temperatures:

– To cool the laundry: Select Rinse.

– Press Start/Pause.

Programmes at lower temperatures:

– Select Spin or Drain (if only emptying: set  (spin

speed) to - - - -).

– Press Start/Pause.

Changing the programme, if...

... a wrong programme has been selected by mistake:

– Reselect the programme.

– Press Start/Pause. The new programme starts from the

beginning.

Pausing/continuing the

programme...

... e.g. for soaking a page 9.

Press Start/Pause. - Æ- appears on the display panel;

washing machine door cannot be opened. To continue

the programme, press Start/Pause.

Individual settings

ʑ

Function buttons

The spin speed and temperature can be changed before and during the selected

programme. The effects depend on the programme progress.

Temp.°C

You can change the displayed washing temperature. The maximum washing

temperature that can be selected depends on the programme that has been set.

rpm  (spin speed // ; (Rinse stop = no final spin))

You can change the spin speed shown or select ; (Rinse stop (Spülstop) = no final

spin, laundry remains in the water after the last rinse, display panel - - - -). The

maximum selectable spin speed depends on the model and on which programme is

currently selected.

Ready in

When you select the programme, the relevant programme duration is displayed. You

can delay the start of the programme before it begins. The "Finished in" time can be

set in increments of one hour up to a maximum of 24 hours. Press the Ready in button

repeatedly until the required number of hours is displayed (h = hour).

Press Start/Pause.

ʑ

Option buttons a Programme overview, page 7

 Speed

perfect

For washing in a shorter time with a washing result comparable to that

of the standard programme. Maximum load

a Programme overview, page 7.

= Rinse Plus Additional rinse cycle. For areas with very soft water or for further

enhancing the spin result.

ć Eco

Perfect 

For saving energy with a comparable washing effect to the standard

programme.

ʑ

Childproof lock

'

on the display

panel

You can lock the washing machine to prevent the functions you have

set from being changed inadvertently.

ON/OFF: after the start/end of the programme, press and hold the

Start/Pause button for approx. 5 seconds.

Note: The childproof lock can remain activated until you wish to start

the next programme, even after switching off the machine.

Then you can deactivate the childproof lock before starting the

programme and activate it again as necessary once the programme

has started.

ʑ

Start/ Pause

To start, pause and continue the programme and to activate/deactivate the childproof

lock.

3

Switching off

Turn the programme selector to Off.

Turning the tap off

Not required for Aqua-Stop models

a Installation instructions, page 7.

Removing the laundry

Open the washing machine door and remove the laundry.

If - - - - (Rinse stop = no final spin) is active: Turn the

programme selector to Drain or select a spin speed.

Press Start/Pause.

– Remove any foreign objects - risk of rusting.

– Leave the washing machine door and detergent

drawer open so that any residual water can

evaporate.

Congratulations – You have opted for a modern, high-quality

domestic appliance manufactured by Bosch. The washing machine

is distinguished by its economical consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly

to ensure that it functions properly and is in perfect condition.

For further information and a selection of our products go to our web

site: www.bosch-home.com

You can find the contact details for your nearest after-sales service

here or in the after-sales service directory (depending on model), see

also Installation Instructions, page 7.

– GB 0844 8928979 Calls from a BT landline will be charged at up

to 3 pence per minute. A call set-up fee of up to 6 pence may apply.

– IE 01450 2655

(0.03 € per minute at peak. Off peak 0.0088 € per

minute).

Environmentally friendly waste disposal 

All packaging must be disposed of in accordance with environmental

guidelines.

This appliance is certified in accordance with European Directive

2012/19/EU on waste electrical and electronic equipment (WEEE).

This directive provides the framework for the EU-wide collection and

reuse of used appliances.

Compartment II: detergent for main wash,

water softener, bleach, stain remover

Programmes

Detailed programme overview a page 7.

Temperature and spin speed can be selected individually, depending on the

selected programme and programme progress.

Cottons Hard-wearing fabrics

+ Prewash Hard-wearing fabrics, prewash at 30 °C

Easy-Care Easy-care fabrics

+ Prewash Easy-care fabrics, prewash at 30 °C

Mixed Load Different types of laundry

Delicate/Silk Delicate washable fabrics

ÿ Wool Hand/machine-washable wool

Rinse Extra rinse with spin

pin Extra spin with selectable speed

Drain rinsing water for - - - -c(Rinse stop = no final spin);

for this, set  (spin speed) to - - - -

Super

Quick 15’/30’

Short programmes

Allergy + Hard-wearing fabrics

Sportswear Fabrics made from microfibre

Shirts/Blouses Non-iron shirts

Easy-Care Dark Dark-coloured fabrics

Select Start/Pause

If the function buttons are held for

longer, the appliance automatically

runs through the display options.

**If the ' symbol flashes on the

display panel, the childproof lock

is active a Deactivating, page 5.

Function and option buttons a

Individual settings, page 5.

Washing machine

door handle

Beoordeling

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WAB28261GB Wasmachine. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WAB28261GB Wasmachine in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasmachines
Meer handleidingen voor Wasmachines

Veelgestelde vragen over Bosch WAB28261GB Wasmachine

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Gerelateerde producten

Handleiding

Bosch WAV28M90IL Wasmachine

Handleiding

Bosch WAU28PH0IN Wasmachine

Handleiding

Bosch WGG454A0ID Wasmachine

Handleiding

Bosch WGA24400IN Wasmachine

Handleiding

Bosch WUU28T8XES Wasmachine

Handleiding

Bosch WGA13400IN Wasmachine

Handleiding

Bosch WAJ28080NLB Wasmachine

Handleiding

Bosch WAJ2446DIN Wasmachine

Gerelateerde categorieën
