1 2 3 4 5 6

Programme selector / OffDisplay panel / Buttons

Empty the condensate container

Empty the container after each drying cycle.

1. Remove the container, holding it level.

2. Pour out the condensate.

3. Push the container back in until it clicks

into place.

If Í(Condensate container) flashes in the

display panel aWhat to do if..., page 11.

Clean fluff filter

Do not operate the dryer without a fluff filter or with

a defective fluff filter. A clean fluff filter minimises

energy consumption.

Clean the fluff filter after each drying cycle.

1. Open the door. Remove any fluff from

the door/around the door and pull out

the fluff filter.

2. Remove the fluff from the shaft of the

fluff filter.

3. Open the fluff filter and remove the fluff

(sweep your hand over the fluff filter). If

the fluff filter is very dirty or blocked,

rinse with warm water and dry

thoroughly.

4. Close and reinsert the fluff filter.

7

6

Programmes / Fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, page 7.

Observe the care instructions on the care label.

LCottons Hard-wearing fabrics.

I Synthetics Fabrics made from synthetic

or blended fabrics.

Dryness levels to select with the LCottons and I Synthetics

programmes:

+: Cupboard Dry Plus Thick and multi-layered fabrics.

+. Cupboard Dry Single-layered laundry.

|Iron Dry Laundry suitable for ironing after drying.

ZSportswear Functional clothing made of microfibre.

ā Hygiene Cotton fabrics for drying in higher

temperatures.

1÷Mixed Load A mixed load of fabrics made

of cotton and synthetic fabrics.

Timed programm

warm

All types of fabric; time programme.

Timed programm

cold

cShirts 15’

Cotton or linen fabrics that are still damp

and easy-care fabrics.

x Super 40’ Synthetics, cotton or blended fabrics.

OüWool finish Woollen fabrics that are suitable

for use in washers.

üDelicates Lingerie made of synthetic fibres, cotton

or blended fabric.

Your new dryer

Congratulations - You have chosen a modern, high-quality Bosch

domestic appliance.

The condensation dryer is distinguished by its economical energy

consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service

will be pleased to help.

Disposal in an environmentally-responsible manner 

This appliance is labelled in accordance with European Directive 

2012/19/EU concerning used electrical and electronic appliances

(waste electrical and electronic equipment - WEEE). The guideline

determines the framework for the return and recycling of used

appliances as applicable throughout the EU.

For further information about our products, accessories,

spare parts and services, please visit: www.bosch-home.com

Intended use

Preparation

Set and adjust the

programme individually

1

2

Drying

ʋexclusively for domestic use,

ʋonly for drying fabrics which have been washed using

water.

Keep children younger than 3 years old away from

the dryer.

Do not let children make the cleaning and

maintenance work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

This appliance is intended for use up to a

maximum height of 4000 metres above sea level.

Drying

Display panel and settings

ʑ

Display panel (status indicators)

p

(Fluff filter)

Clean the fluff filter apage 4/11

or clean the heat exchanger apage 8.

Í÷

(Condensate

container)

Empty the condensate container apage 4/11.

H|]+

- Æ-§Ê

(Programme

sequence)

These indicators show the programme progress in the next steps

of the drying cycle:

H Drying;

|] Iron Dry;

+Cupboard Dry;

- Æ- Programme pause aif required;

§ÊProgramme end.

(

(Childproof lock)

You can lock the dryer to prevent the functions you have set from being

changed inadvertently. To activate/deactivate ((Childproof lock) start

the programme and then press and hold the $ (Start/Pause) button for

5 seconds until a long acoustic signal is heard. The option activated/

deactivated a((Childproof lock) indicator light on/off.

[h:min]

(Remaining time)

When a programme is selected, the anticipated drying time (remaining time)

for the recommended load is displayed. While drying, the moisture sensors

detect the actual load and correct the programme length. This is shown by

jumps in the remaining time in the display panel.

ʑ

Settings (indicators lights and buttons)

Selected option activated/deactivated aindicator light on/off.

See the separate Energy-saving mode instructions.



(Drying time)

Drying time, available only for timed programmes, can be selected

from min. 0:20 h to max. 3:00 h, in 10-minute steps.

8

+

(Fine adjust)

The dryness levels (e.g. Cupboard Dry) can be increased in three levels.

The laundry is made drier. Default = 0. Selectable values: 0, 1, 2, 3. After setting

the level of the fine adjustment for a programme, it is also retained for other

programmes, until 8

+

(Fine adjust) is changed again.

³¤- ¤

È(Finished in)

The time when the programme has to end can be set by selecting

the È(Finished in) time. The È (Finished in) time can be selected in one-hour

steps, up to a maximum of 24 hours. Select the È (Finished in)button

repeatedly until the required number of hours is displayed. Then press

the $(Start/Pause) button to activate the È÷(Finished in) option.

The programme ends after the selected number of hours.

Several minutes after activating È (Finished in) option the display switches off

to save energy. To switch it on select any button, close/open the door or turn

the programme selector.

V

(Gentle Dry)

Reduced temperature for delicate fabrics, e.g. polyacrylic, polyamide

or elastane, with a longer drying time.

4

(Wrinkle Guard

Plus)

After the programme finishes, the drum moves at regular intervals to prevent

creases. Laundry remains loose and fluffy.

The standard setting for each programme is 60 min. Automatic anti-crease

function can be extended by up to 60 min.

&ü

(Buzzer)

For switching the buzzer on and off. &ü(Buzzer) indicates program

end if it is activated. Other sounds are not influenced by this option.

Close the door

3

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋControl panel . . . . . . . . . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . .3/4

ʋDisplay panel and settings . . . . . . . . . . . 5

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋCare and cleaning . . . . . . . . . . . . . . . . . 8

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 9

ʋFrost protection / Transport . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . 10

ʋTechnical data . . . . . . . . . . . . . . . . . . . 10

ʋConsumption rates . . . . . . . . . . . . . . . . 10

ʋAfter-sales service . . . . . . . . . . . . . . . 11

ʋWhat to do if ... . . . . . . . . . . . . . . . . 11/12

ʋSafety instructions. . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged!

Inform your after-sales service!

Inspect the dryer

Sort the laundry

Remove all items from pockets,

especially cigarette lighters.

The drum must be empty prior to loading.

See programme overview on page 7.

See also separate instructions for “Woollens basket”

(depending on model).

Make sure your hands are dry.

Only grasp the plug by the plug

body.

Connect the

mains plug

End of the programme...

Interrupt the programme

1. Open the door or press the $ (Start/Pause)übutton;

the drying cycle is interrupted.

2. Add or remove laundry and close the door.

3. If required, select a new programme and additional

functions. Select the $ (Start/Pause) button.

The remaining time is updated after a few minutes.

The drum and door may be hot!

Notes on laundry ...

Labelling of fabrics

Follow the manufacturer's care instructions.

hcSuitable for tumble drying.

(cDry at normal temperature.

'cDry at low temperature a in addition, select

V(Gentle Dry).

)cDo not tumble dry.

Do not tumble dry the following fabrics:

– Non-breathable fabrics (e.g. rubber-coated).

– Delicate materials (silk, curtains made from synthetic material) a these may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. towels).

– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc.

together or use a laundry bag.

– Do not over-dry easy-care laundry a risk of creasing. Allow laundry to finish drying in

the air.

– Do not dry woollens in the dryer. They may, however, be refreshed in the dryer

apage 7, OüWool finish programme (depending on model).

– Do not iron laundry immediately after drying; fold items up and leave for a while

a residual moisture will then be distributed evenly.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not use the +:cCupboard Dry Plus programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

reduces the drying effect.

– When washing laundry that is to be tumble dried afterwards, use the correct amount of

fabric softener as specified in the manufacturer's instructions.

– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the timed

programme. Also suitable for subsequent drying.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry in the washing machine a higher spin speeds minimise

the drying time and reduce energy consumption.

– Use the maximum recommended capacity, but do not exceed it a Programme overview,

page 7.

– Make sure the room is well ventilated during drying.

– Clean the fluff filter after every drying cycle a Clean the fluff filter, page 4/11.

– Do not cover or seal the air inlet on the dryer.

Remove the laundry and switch off

the dryer

5

4

Control panel

Fluff filter

Select

$(Start/Pause)

Door

Installation a page 9.

Condensate

container

Air inlet

Programme sequence H|]+(Drying Time) Setting the drying time available only for timed programmes.

- Æ-§Ê

8

+

8

+

(Fine adjust)

Fine adjustment of dryness level.

Childproof lock (

³¤– ¤

È(Finished in) Setting the programme end.

Condensate container ÍV(Gentle Dry) Low-heat drying  reduced temperature.

Fluff filter/Heat exchanger p4(Wrinkle Guard+) Extends the anti-crease function.

&(Buzzer) Buzzer on/off.

$ (Start/Pause)

Starts, pauses and continues the programme;

activates or deactivates ((Childproof lock).

Programme selector for setting

the programme and switching the appliance

on/off. Can be turned in both directions.

Maintenance flap

Further information

can be found

on page 5

`

Observe the safety instructions on page 13.

Read these instructions and the separate

Energy-saving mode instructions

before operating the dryer.

7

Programme overview see also page 6.

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying, laundry is to be ...

cironed lightly ironed @cnot ironed cmangled

PROGRAMMES TEXTILE TYPE AND INFORMATION

*LCottons

max. 8 kg

Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.

*ISynthetics

max. 3.5 kg

Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.

| Iron Dry c÷@c

The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).

+. Cupboard Dry @

Single-layered laundry.

+: Cupboard Dry Plus @

Laundry with thick, multi-layered parts.

ZüSportswear

max. 1.5 kg

Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics

(dry jackets/trousers with removable internal lining separately).

āü Hygiene

max. 6 kg

Cotton fabrics for drying in higher temperatures to keep them more hygienic .

1÷Mixed Load

max. 3 kg

Mixed items of laundry made of cotton and synthetics (Mix).

Timed programm

warm

max. 3 kg

Suitable for pre-dried or slightly damp laundry and for drying off multi-layered, thick laundry.

Only dry wool, sports shoes and soft toys with the basket for woollens aOptional Accessories,

page 10.

In the time programme, the laundry's residual moisture is not automatically detected. If the laundry is

still too damp after the drying programme, repeat the programme and, if required, extend

the programme length.

Timed programm cold

max. 3 kg

All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short

period of time.

cShirts 15’

max. 1 kg

For optimal drying result dry a maximum of 5 business shirts together. After drying, iron clothes or hang

them out and leave for a while. The remaining moisture will be distributed evenly.

x Super 40’

max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly.

The values may differ from the those specified depending on the type of fabric, mixture of laundry to be

dried, residual moisture in the fabric and loading capacity.

OüWool finish

max. 3 kg

Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.

Remove fabrics once the programme has ended and allow to dry.

üDelicates

max. 1 kg

Lingerie made of synthetic fibres, cotton or blended fabric.

*Dryness levels can be selected individually a+:÷Cupboard Dry Plus, +.÷Cupboard Dry and |üIron Dry (depending on the model).

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing.

Recommendation: Dry separately.

9505 / 9001117718

*1117718*

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

WTB86268SN

WTB86298SN

Beoordeling

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WTB86298SN Wasdroger. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WTB86298SN Wasdroger in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasdrogers
Meer handleidingen voor Wasdrogers

Veelgestelde vragen over Bosch WTB86298SN Wasdroger

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.
