Handleiding

1 2 3 4 5 6

Display panel / Buttons

Programme selector / Off

Your dryer

Congratulations – you have chosen to buy a modern, high-quality

Bosch domestic appliance.

A distinctive feature of the condensation dryer with heat pump and

automatic cleaning of the heat exchanger is its low energy

consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be

pleased to help.

Environmentally-responsible disposal



This appliance is labelled in accordance with European Directive

2012/19/EU concerning used electrical and electronic appliances

(waste electrical and electronic equipment - WEEE).

The guideline determines the framework for the return and recycling

of used appliances as applicable throughout the EU

For further information about our products, accessories, spare parts

and services, please visit: www.bosch-home.com

Intended use

Preparation

Open the door/load the laundry/

press the programme selector/

set the programme

1

2

Drying

ʋ For domestic use only.

ʋ Only to be used for drying fabrics that have been washed

with water.

This appliance is intended for use up to a maximum

height of 4000 metres above sea level.

Keep children younger than 3 years old away

from the dryer.

Do not let children make the cleaning and

maintenance work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use

by a responsible adult.

Drying

Display panel and buttons

ʑ

Display panel

Please clean lint filter Clean the fluff filters a Page 4.

Please empty

condensate container

Empty the condensate container a Page 4 and/or clean the filter in the condensate

container a Installation and maintenance instructions, Page 3.

Heat exchanger is

being rinsed

Automatic cleaning of the heat exchanger. Do not empty the condensate container while this

is displayed.

ʑ

Buttons

Æ (Drying target) Select the dryness level (e.g. Cupboard dry) or the drying time (20 mins up to 3 hrs: 30 mins,

depending on the model and programme).

 C/board dry extra: For laundry with thick, multi-layered parts.

+ C/board dry: For single-layered laundry.

|cIron dry: The condition of the laundry means it is suitable for ironing (iron clothes in

order to avoid creases).

S (Easy-Iron) After the programme finishes, the drum moves at regular intervals to prevent creases.

Automatic reduced ironing function can be set in 30 mins intervals up to 120 mins.

The standard setting for each programme is 60 mins.

 (Finished in) When a programme is selected, the anticipated drying time for the maximum load is

displayed. While drying, the moisture sensors detect the actual load and correct the

programme length. This is shown in the display by jumps in the (Finished in) time.

The (Finished in) time can be delayed in one-hour steps, up to a maximum of 24 hours.

Press the (Finished in) button repeatedly until the required number of hours is displayed

(h=hour).

' Childlock: Activate/Deactivate a start programme, press and hold the (Finished

in) button above the display panel for 5 seconds.

Õ(Options) Ï÷Spin speed; Ð÷Adjust drying level; ÷low heat

Ï÷Spin speed: The spin speed that was used for the spin in the washing machine a used

exclusively to display the anticipated drying time ((Finished in) time) more precisely.

Ð÷Adjust drying level: The drying result (e.g. Cupboard dry) can be increased in three

stages (+1 - max. +3); exception: Timer programmea default setting = 0. After one

programme has been finely adjusted, the setting is retained for the others.

÷low heat: Reduced temperature for delicate fabrics ', e.g. polyacrylic, polyamide or

elastane, with a longer drying time.

Memory 1/2 For saving individual programme settings that are used frequently. Use the programme

selector to select the required programme. Press and hold the Memory 1/2 button for 3 sec.

until the required programme has been saved.

To select the saved programme, briefly press the Memory 1/2 button. The programme that is

called from Memory 1 or 2 is displayed on the display panel.

¾ 3 sec.

(Basic settings 3 sec.)

end signal, button signal,

auto power-off and language. Press and hold buttons ¾ 3 sec.

(Basic settings 3 sec.) for 3 sec. in order to access the menu.

end signal/button signal: The signal volume level can be selected: off - low - medium - loud

- very loud.

auto power-off: Activate/deactivate by pressing the ¾ 3 sec. (Basic settings 3 sec.)

buttons. The dryer automatically switches off, depending on your selection, after 15, 30

or 60 mins. The setting is active after S (Easy-Iron) or end of programme.

language: Select the required language.

Close the door

3

Contents Page

ʋ Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ʋ Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ʋ Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋ Display panel and buttons . . . . . . . . . . . . . . . . 5

ʋ Notes on laundry . . . . . . . . . . . . . . . . . . . . . . . 6

ʋ Overview of programmes . . . . . . . . . . . . . . . . 7

ʋ Important Information . . . . . . . . . . . . . . . . . . . 8

ʋ Consumption rates . . . . . . . . . . . . . . . . . . . . . . 9

ʋ Normal noises . . . . . . . . . . . . . . . . . . . . . . . . 10

ʋ What to do if ... / After-sales service. . . . . 11/12

ʋ Safety instructions . . . . . . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged.

Inform your after-sales service.

Inspect the

dryer

Sort the laundry

Remove all items from pockets.

Check for cigarette lighters.

The drum must be empty prior to loading.

See programme overview on page 7.

See also separate instructions for “basket for woollens”

(depending on the model).

Make sure your hands are dry.

Hold the plug only.

Connect the

mains plug

Empty the condensate container

Condensation will form in the appliance as it dries the

laundry. If there is no drain hose connected to the appliance,

the condensation water from the appliance will run into the

condensation container. In this case, you will need to empty

the condensation container each time the dryer finishes

drying the laundry, and also if it becomes full before drying

is complete.

1. Remove the container, holding it level.

2. Pour out the condensation. Push the container back in

until it clicks into place.

You must also observe the a Installation and maintenance

instructions, Page 3.

Clean the fluff filters

The fluff filter consists of two parts.

Clean the inner and outer fluff filter after

every drying cycle.

1. Open the door. Remove fluff from the

door/door area.

2. Pull out the inner

and outer fluff filter

and open them out.

3. Remove any fluff,

rinse both fluff filters

under running water

and dry thoroughly.

4. Fold the fluff filters

closed, put them

back together and reinsert into the appliance.

7

6

End of the programme ...

Interrupt the programme

1 Open the door or press the $(Start/Pause) button;

the drying cycle is cancelled.

2 Add or remove laundry and close the door.

3 If required, select a new programme and additional

functions. Press the

$(Start/Pause) button.

The  (Finished in) time is updated after a few minutes.

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

hcSuitable for tumble drying

(cDry at normal temperature.

'cDry at low temperature.

)cDo not tumble dry.

Do not tumble-dry the following fabrics:

– Non-breathable fabrics (e.g. rubber-coated).

– Delicate materials (silk, curtains made from synthetic material) a these may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. towels).

– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc.

together or use a laundry bag.

– Do not over-dry easy-care laundry a Risk of creasing. Allow laundry to finish drying

in the air.

– Do not iron laundry immediately after drying; fold items up and leave for a while

a residual moisture will then be distributed evenly.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

a Do not use the

÷C/board dry extra programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

reduces the drying effect.

– When washing laundry that is to be tumble-dried afterwards, use the correct amount of

fabric softener as specified in the manufacturer's instructions.

– With a small load, use the Timed programme.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry in the washing machine a the higher the spin speed, the

shorter the drying time will be, thus less energy is consumed. Also spin easy-care laundry.

– Use the maximum recommended capacity, but do not exceed ita Programme overview,

Page 7.

– Make sure the room is well ventilated during drying.

– Clean the fluff filters after every drying cycle aCleaning the fluff filters, Page 4.

– Keep the supply of cool air unobstructed a Do not cover or block the air inlet.

Remove the laundry and switch off

the dryer

5

4

Select the

$ (Start/Pause)

button

Further information can be found on Page 5

Condensate

container with filter

Fascia panel

Two-part fluff

filter

Air inlet

Door

Observe the safety instructions on Page 13.

You must read this instruction manual and the Installation

and maintenance instructions before using the dryer.

To install the condensation drain, follow the Condensation

drain instructions (provided separately).

Installation aInstallation and maintenance instructions, Page 1

Clean fluff filters reduce energy consumption.

Depending on the selected programme, it may not be possible to select individual options.

The dryer is switched on and off by pressing

the  button in the centre of the programme selector.

Select the programme by turning the outer ring on the programme

selector (the selector can be turned in both directions).

The selected programme is displayed.

Memory 1 Saves or calls

individual settings

Memory 2

}

¾ 3 sec.

(Basic settings 3 sec.)

end signal, button signal,

auto power-off and language

Change the functions in the display using the buttons ? >

Æü

(Drying target)

 C/board dry extra, +cC/board dry, |cIron dry

S (Easy-Iron) Reduced ironing function can be set up to 120 minutes

 (Finished in) Time delay/'Childlock

Õ (Options) Ï÷Spin speed, Ð÷Adjust drying level, ÷low heat

Programmes / Fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, Page 7.

Observe the care information on the care label.

Dryness level, timer programming and options can be

individually selected depending on the selected programme

and the progress of the programme.

LCottons Hard-wearing fabrics

I Easy-Care Fabrics made from synthetic or blended fabrics

1 Mix A mixed load of fabrics made of cotton or synthetic

fabrics

 Delicate Lingerie made of synthetic fibres, cotton or

blended fabric.

/ Wool finish Woollen fabrics that are suitable for use in

washers.

 Time program

cold 30 min

All types of fabric; time programme

 Time program

warm 30 min

 Time program

warm 60 min

 Shirts Shirts and blouses made of cotton and blended

fabrics

W Down Fabrics with down filling

Z Sport Functional clothing made of microfibre

A Super Quick 40’ Synthetic fibres, light cotton or mixed fabrics

 Blankets Large quilted fabrics containing synthetic fibres

Ø Towels Terry-towelling laundry e.g. towels and bathrobes

}

7

Overview of Programmes a Refer to the table of consumption rates on Page 9 and the notes on Page 6.

a Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying

aDryness levels can be individually selected a  C/board dry extra, +cC/board dry and |cIron dry (depending on the model and programme). Degree of dryness can be

finely adjusted (depending on the programme). Multi-layered fabrics require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

Programmes Max.

Type of Fabric

Options and Notes

LCottons 9 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen

I Easy-Care 3.5 kg Fabrics made from synthetic or blended fabrics

1 Mix 3.5 kg A mixed load of fabrics made of cotton and synthetic fabrics

 Delicate 2 kg Lingerie made of synthetic fibres, cotton or blended fabric.

/ Wool finish 0,5 kg Hand or machine-washable fabrics made of wool or containing wool.

Woollen fabrics suitable for washing machines. Fabrics become

fluffier but not dry. Remove fabrics once the programme has ended

and allow to dry.

 Time program

cold 30 min

All types of fabric; time programme

For freshening up or airing of items of laundry that have been worn

for a short period of time.

 Time program

warm 30 min

Suitable for pre-dried or slightly damp laundry and for drying off

multi-layered, thick laundry.

Only dry wool, sports shoes and soft toys with the basket for woollens

aOptional Accessories, Installation and maintenance instructions,

Page 4.

In the time programme, the laundry's residual moisture is not

automatically detected. If the laundry is still too damp after the drying

programme, repeat the programme.

 Time program

warm 60 min

 Shirts 1.5 kg Shirts and blouses made of cotton and blended fabrics. Creasing is reduced. Not completely dried.

W Down 1.5 kg Fabrics with down filling. Dry non-quilted fabrics separately.

Z Sport 2 kg Functional clothing made of microfibre.

A Super Quick 40’ 2 kg Synthetic fibres, light cotton or mixed fabrics. Easy-to-dry textiles.

 Blankets 2 kg Large quilted fabrics containing synthetic fibres. No down filling.

Ø Towels 3.5 kg Terry-towelling laundry e.g. towels and bathrobes.

9704 / 9001303732

*1303732*

Robert Bosch Hausgeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

WTY87859SN

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Bosch WTY87859SN Wasdroger. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Bosch. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Bosch WTY87859SN Wasdroger in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Bosch Wasdrogers
Meer handleidingen voor Wasdrogers

Veelgestelde vragen over Bosch WTY87859SN Wasdroger

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Beoordeling

Gerelateerde producten

Handleiding

Bosch WQG24500G Wasdroger

Handleiding

Bosch WTN83205NL Wasdroger

Handleiding

Bosch WTH84001GB Wasdroger

Handleiding

Bosch WQG2450XES Wasdroger

Handleiding

Bosch WTX8HKM9SN Wasdroger

Handleiding

Bosch WQG245R2G Wasdroger

Handleiding

Bosch WTW86590EE Wasdroger

Handleiding

Bosch WTH85223GB Wasdroger

Gerelateerde categorieën
