English

GREAT BRITAIN • customer service

tel: 020 8247 9300 e-mail [email protected] internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ

1 2

3

4

5

6

Ver. 20170904

FM Radio/Speaker

Art.no 18-8494-2 Model 922127 UK Black

18-8494-3 922127 UK White

38-7354-1, -2, -3 922127 Pink/Black/White

Please read theentire instruction manual before using theproduct and

then save it for future reference. We reserve theright for any errors in

text or images and any necessary changes made to technical data.

In theevent of technical problems or other queries, please contact our

Customer Services.

Safety

• This product should only be repaired by aqualified service technician.

• Theproduct should not be taken apart or modified.

• Do not cover theproduct. Adequate ventilation, with aclearance

of at least 15 cm between theproduct and surrounding surfaces is

necessary to prevent overheating.

• Theproduct should not be taken apart or modified. Certain

unshielded components inside thecasing carry dangerous

voltages. Contact with these can lead to fire or electric shock.

• This product is intended for indoor use only.

• Never subject theproduct to high temperature, dust, heavy

vibration, impacts, humidity or moisture.

• Do not place theproduct where there is arisk of it falling into water

or other liquid. Do not place any objects which contain liquid onto

theproduct such as vases, drinks, etc.

• Thepower switch does not completely disconnect theproduct

from themains. To completely isolate thedevice from themains,

unplug its mains lead from thewall socket.

• Themains lead should be checked regularly. Never use theproduct

if themains lead or plug is damaged.

• Never lay themains lead over hot surfaces or pull it round sharp

edges or corners.

• Protect your hearing. Listening on high volume for prolonged

periods can lead to permanent hearing loss.

Buttons and functions

Battery operation

1. Remove thebattery cover by sliding it in thedirection of thearrow.

2. Insert 3×AA/LR6 batteries while observing thecorrect polarity by

referring to themarkings inside thebattery compartment.

3. Refit thebattery cover.

4. Remove thebatteries if you do not intend to operate theradio from

thebatteries for anextended period.

Note: Theradio will automatically switch over to battery operation

when unplugged from themains, if functioning batteries are present.

Theradio will also automatically switch from battery operation over to

mains operation when plugged into themains.

Connecting anexternal device

Note: Any current playback will be interrupted whenever a3.5 mm

audio plug is inserted and will resume whenever this plug is removed.

1. Connect a3.5 mm audio cable (sold separately) to theaudio input

socket (5) and to your device (smartphone, MP3 player, etc.).

2. Turn on theradio by turning thevolume control knob clockwise.

3. Start playback on thedevice.

4. Set thedesired volume levels both on theexternal device and

theradio.

Care and maintenance

• Clean theradio by wiping it with adamp cloth. Use only mild

cleaning agents, never solvents or corrosive chemicals.

• Whenever theradio is not to be used for anextended period,

thebatteries should be removed and it should be stored in adry,

dust-free environment, out of children’s reach.

Responsible disposal

1. [ TUNING ] Station tuning knob

2. [ VOLUME ] Volume knob

3. FM aerial

4. Power lead socket

5. 3.5mm aux input socket

6. Battery compartment

Operating instructions

Note: Theradio will automatically switch over to battery operation

when unplugged from themains, if functioning batteries are present.

Theradio will also automatically switch from battery operation over to

mains operation when plugged into themains.

Mains operation

1. Plug theradio into awall socket.

2. Fully extend theFM aerial.

3. Turn on theradio by turning thevolume control knob clockwise.

Note: It takes about 3 seconds for the sound to come on once

the radio is switched on.

4. Select thedesired radio station by turning thetuning knob.

5. Adjust theaerial or move theradio if thereception is poor.

6. Turn off theradio by turning thevolume knob completely clockwise.

This symbol indicates that this product should not be

disposed of with general household waste. This applies

throughout theentire EU. In order to prevent any harm to

theenvironment or health hazards caused by incorrect

waste disposal, theproduct must be handed in for

recycling so that thematerial can be disposed of in

aresponsible manner. When recycling your product, take

it to your local collection facility or contact theplace of

purchase. They will ensure that theproduct is disposed

of in anenvironmentally sound manner.

Specifications

Power supply 220−240 V AC, 50/60 Hz

Batteries 3×AA/LR6

Power 1.5 W

Frequency range 88–108 MHz

Size 18×8.5×11 cm
