Ver. 20230831

Wireless Doorbell

Art.no 36-8974 Model 98233EU

Please read theentire instruction manual before use and

then save it for future reference. Wereserve theright for any

errors in text or images and any necessary changes made

to technicaldata. Intheevent of technical problems or other

queries, please contact our Customer Services.

Safety

• Never subject theproduct to high temperatures, damp or

dusty environments, heavy vibrations or impacts.

• Theindoor unit must not be exposed to rain or moisture.

• Never try to repair theproduct, dismantle or modify it in

anyway.

Buttons and functions

3. Plug thedoorbell into a230 V wall socket. Thedoorbell

will sound twice and theLED indicator (4) starts to flash

which indicates that thedoorbell is ready to be paired with

thetransmitter.

4. Within 30 seconds, press thetransmitter that you want

to connect thedoorbellto. Thedoorbell will sound

when thepairing has been successful. If you wish to

pair additional transmitters: Cutoff thepower supply to

thedoorbell, then repeat steps 3–4.

Selecting thering signal

Assembly

Informaon

• Avoid placing theunits next to metal objects such as metal

window frames as this may cause interference with reception.

• Test thedoorbell’s functionality/location before final mounting.

1. Doorbell/receiver

2. Button to select thevolume

3. Button to select the ring signal

4. LED indicator

5. Transmitter

6. Push Button Ring Signal

Installation

Handyp: One transmitter is included but you may connect

anadditional 7 transmitters (sold separately).

Battery/pairing theunits

1. Open thetransmitter carefully

by pressing thelatch with

ascrewdriver.

2. Remove theplastic tab from thebattery holder to activate

thebattery in theremote control.

Press [ ] repeatedly to select the ring signal. Youcan choose

between atotal of 16different melodies and sounds:

1. Dingdong

2. Für Elise

3. Westminster Chimes

4. Hey Jude

5. Swan Lake

6. Red River Valley

7. My heart will goon

8. Turkish March

9. Menuet

10. Hymn to Joy

11. William Tell Overture

12. Romance oflove

13. Memory

14. TheLittle Mermaid

15. Canon

16. Do re mi

Selecting thevolume

Press [ ] repeatedly to select the volume. Choose between

Hig, Medium, Low and Mute.

Remove thepaired transmitter

Informaon

If you follow thefollowing steps, it will remove all thepaired

transmitters from thedoorbell’s memory.

1. Dismantle one of thetransmitters.

2. Remove thepower supply to thedoorbell by disconnecting

it from thewall socket. Waitafew seconds and then plug it

in again so that thedoorbell is in pairingmode. Thedoorbell

will soundtwice.

3. While thedoorbell is in pairing mode, press thebutton

inside thetransmitter. Thedoorbell will sound to confirm that

all thetransmitters have been removed from thedoorbell’s

memory.

Care and maintenance

Clean theproduct using adampcloth. Useonly mild cleaning

agents, never solvents or corrosive chemicals.

Troubleshooting

No sound when

thepush button is

pressed.

• Check that thebatteries are inserted

correctly and that they are notflat.

• Excessive distance between

thetransmitter and thedoorbell.

1. Screw on or glue (with double-sided

adhesive tape) the backplate of

the transmitter to thewall.

2. Fit the transmitter onto the backplate,

making sure that thegasket is inplace.

Pressthe latch on the transmitter until

it clicks intoplace.

Responsible disposal

This symbol indicates that this product should not

be disposed of with general householdwaste.

Thisapplies throughout theentire EU. Inorder to

prevent any harm to theenvironment or health

hazards caused by incorrect waste disposal,

theproduct must be handed in for recycling so that

thematerial can be disposed of in aresponsible

manner. Whenrecycling theproduct, take it to your local

collection facility or contact theplace of purchase. Theywill

ensure that theproduct is disposed of in anenvironmentally

sound manner.

Specifications

Doorbell (receiver)

Rated voltage 230 V AC

Power consumpon ≤ 0.5 W

Range Up to 100 m (clear line of sight)

Noise level 78 dB (at adistance of 1 m)

Signals 16 different melodies and sounds

Size 70×70×67mm

Push button (transmitter)

Transmission frequency 433.92 MHz

Baery CR2032 lithium (3 V)

Size 35×17×85 mm
