Ver. 201106
Please read the entire instruction manual before using the product
and save it for future reference. We reserve the right for any errors
in text or images and any necessary changes made to technical
data. If you have any questions regarding technical problems
please contact Customer Services.
• Never use the clipper if the mains lead, charger or
clipper is damaged.
• Never place the charger where it might be knocked
into the wash basin/bath.
• Never place the charger close to sources of high
temperature such as cookers or fireplaces.
• This clipper is designed for use with 230 V mains electricity.
• Always disconnect the charger from wall socket when it is not in use.
• This clipper must not be used by anyone (including children)
suffering from physical or mental impairment. This clipper should
not be used by anyone that has not read the instruction manual
unless they have been instructed in its use by someone who will
take responsibility for their safety.
• Never let children play with the clipper.
• The charger must not come into contact with water or other liquid.
• The charger must not be used outdoors.
• Never handle the charger with wet or moist hands.
• Only use the supplied charger.
• Store the clipper in a dry, frost-free location.
• This clipper is designed exclusively for private use.
• The hair clipper must not be modified or used for any
other purpose than that for which it has been designed.
• The clipper must only be repaired by a qualified technician
with good knowledge of the product.
• Before disposing of this clipper, remove the battery
and take it to recycling centre.
• Only use the supplied accessories.
• Hair clipper
• Charger
• Scissors
• 6 comb attachments: 4-6, 10-12, 16-18, 22-24 and 28-30 mm
plus a thinning comb.
• Instruction manual
• Oil
• Comb
0.8, 1.5, 2.2 and 2.8 mm can be set using the length
adjuster (2) on the clipper.
B. Cutting length 4 – 30 mm
For cutting longer hair you will need to use one of the comb
attachments. There are 6 comb attachments: 4 - 6, 10 - 12, 16 - 18,
22 - 24 and 28 - 30 mm plus a comb for thinning out hair.
1. Select the correct comb attachment.
2. Push the comb attachment onto the cutter head from below
so that it clicks into the notches on the side of the cutter head.
3. Detach the comb by pushing it downwards.
6. Care and maintenance
1. Cutter head with ceramic blades
2. Cutting length adjuster for
0.8, 1.5, 2.2 and 2.8 mm
3. On/off switch 1 – 0
4. Charging indicator lamp
The clipper must be charged before initial use or if it has not been used
for an extended period. A fully charged battery will last up to 40 minutes.
1. Make sure that the clipper is switched off (on/off switch set to 0)
and then insert it into the charging station. The clipper will not
charge if the on/off switch is set to 1.
3. The charging indicator (4) on the clipper will light when
charging is in progress.
3. Charge the clipper for about 8 hours. Do not leave the clipper
connected to the charger all the time.
You can also use the clipper without going through the entire
charging process:
1. First connect the charger lead to the clipper.
2. Make sure the on/off switch is set to 0 (off) and then
plug the charger into a power point.
3. Leave the on/off switch set to 0 for 2 minutes before
setting it to 1 and starting to cut your hair (leave the
charger lead connected to the clipper whilst cutting).
4. Remember to recharge the battery after use.
5. Do not use the clipper for more than 1 hour with the charging
cable connected. The life of the batteries will be shortened if
the clipper is used too often with the charging cable connected.
Make a habit of charging the batteries and using the clipper
without the charging cable connected.
Only use the clipper on dry hair. It may be advisable to start with
a longer attachment comb and then switch to a shorter one for
the best results. The clipper can be set to various cutting lengths
from 0.8 mm up to 30 mm.
1. Make sure the clipper is switched off
before cleaning it.
2. Remove the cutter head by pressing out
the top portion with your thumb as shown.
The blade will then detach from the clipper.
3. Brush off any hair residue from the cutter
head and the chamber beneath it using
the cleaning brush provided.
4. Lubricate the outer and inner blades with
a drop of blade oil after cleaning them.
5. Reattach the cutter head securely.
6. Turn on the clipper and run it for a little
while to distribute the oil over the blades.
7. Wipe off any excess oil with a dry cloth.
Do not attempt to sharpen the blades yourself.
7. Disposal
Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product, please
contact your local authority.
Charger Input: 230 V AC~, 50/60 Hz
Output: 4.5 V DC, 1000 mA
Charging time 12 hours
Operating time 40 minutes
