Handleiding H2OFloss HF-2 Flosapparaat

Handleiding

- 01 - - 02 -

材质: 105g铜版纸 尺寸: 85 x 128 mm 印刷: 单黑双面印刷 折页方式: 风琴折

- 05 - - 06 -

- 07 -

- 03 -

Charging Unit Prior to First Use

This product does not come with an AC/DC charger. The unit is charge through

devices with 5V USB's power capabilities such asmobile phone, lap top, USB

power wall charger, etc.The charge indicator on the handle will flash when charging

and will stay on continuously when the unit is fully charged. A complete recharge

will take 3-5 hours.

- 04 -

cordless oral irrigator

HF-2

USB charging

cable

Tongue

scraper tip

Orthodontic

tip

Periodontal

tip

Standard

tip

Accessories

WARNING:

To reduce the risk of burns, electrocution, fire, or

injury to persons:

Do not plug this device into a voltage system that is different from

the voltage system specified on the device or charger.

improper voltage will damage product and VOID warranty.

If product is opened/disassembled for ANY reason, warranty is VOID.

Do not use this product if it has a damaged cord or plug, if it is not

working properly, if it has been dropped or damaged, or dropped

into water

, Please contact retailer for help.

Do not direct water under the tongue, into the ear, nose or other delicate

areas. This product is capable of producing pressures that may cause

serious damage in these areas.

Do not direct water into the nose or ear. The potentially deadly amoeba,

Naegleria fowleri,may be present in some tap water or unchlorinated

well water and may be fatal if directed into these areas.

If your physician advised you to receive antibiotic premedication before

dental procedures, you should consult your dentist before using this

instrument or any other oral hygiene aid.

Close supervision is necessary when this product is used by, on or

near children or invalids.

Children should be supervised to ensure that they do not play with the

appliance.

SAVE THESE INSTRUCTIONS.

Inserting and Removing Tips

Insert tip into the center of the knob at the top of the Water

Flosser handle. Press firmly until the tip clicks into place.

To remove the tip from the handle, press the tip eject

button and pull tip from the handle.

CAUTION: Do not press tip eject button while unit

is running.

Tip

Eject

Button

Lift flip top on reservoir and fill the reservoir

vwith lukewarm water.

Filling the Reservoir

Adjusting the Pressure Setting

You can adjust the pressure setting on your Water

Flosser by pressing the mode button on the handle.

Start with the lowest setting and increase to your liking.

When Finished

Turn the unit off. Empty any liquid left in the reservoir.

Tongue Cleaner Tip

Lean your head over the sink.Glide the pressure button to the lowest setting.

Start the irrigator and place the tongue cleaner at the back of your tongue and

move it forward to clean your tongue.Repeat to cover entine tongue.Set the

pressure to the lowest setting and adjust to a hinger setting for more water

pressure as it feels comfortable.

Orthodontic Tip

Use the Orthodontic Tip to simultaneously brush and rinse hard-to-reach areas

aroud braces,crowns,bridges and implants.Start on the last molar(back tooth).

Place tip at 90degree angle to the tooth at the gumline.Gentlyglide tip along

gumline,pausing briefly to lightly brush area between teethand all around

orthodontic bracket,before proceeding to the next tooth andoutside of both the

upper and lower teeth.Continue process until you havecleaned the inside.

Been over the sink and guide the jet to your teeth and gums,Glide the handle

swithch up to start the water stream. Keep your mouth slightly open to allow

the water to run into the sink.Direct the stream of water towards the gumline

at 90 degrees,so that contact is made where the tooth and gums meet.

Manoeure the flow of water from tooth to tooth remembering to pause briefly

between each tooth.

Jet Tip

TIP USAGE

Periodontal Tip

Place the periodontal tip in contact between teeth and the gumline. Lean

the soft tip against a tooth at a 45-degree angle and gently place the tip

under the gumline, into the pocket. Start the irrigator by setting it at the

lowest pressure and clean by gently following gumline , inserting the

periodontai tip in between teeth. Continue tracing along the gumline to

massage the gums and safely deliver solution into the gingival pockets

below the gumline.

Make sure to throw out the water inside the tank,and run the appliance for 2 to 3

seconds to drain the water after usage.Otherwise bacteria could collect in the

remaining water.Do not submerge the unit in water or any other liquid.Wipe the

exterior when necessary with a soft cloth and mild non-abrasive cleanser.Reservoir

may be washed with soapy water.Wash the dirt off from inside using a brush or

similar, and wipe off with a cloth Dry the reservoir when not using for a long period.

Battery Care and Disposal

Maintenance

Warranty

The unit contains a Lithium battery.At the end of the battery life, please recycle

the unit at your nearest recycle center per local or state requirements. The battery

is not replaceable.

H2ofloss will repair or replace(at our option) your unit free of charge for 12

months from the date of purchase if the appliance is defective in workmanship

or materials.This guarantee does not cover:damage due to improper use,normal

wear or use as defects that have a negligible effect on the value or operation of

the appliance.The guarantee becomes void if repairs are undertaken by

unauthorized persons and if original h2ofloss parts are not used.To obtain

service within the guarantee period,hand in or send the complete appliance

with your purchase receipt to an authorized h2ofloss distributor/customer

service center in your country.Purchaser is responsible for all postage and

freight charges and any other expenses incidental to claiming against this

Warranty.

Note:Excessive heat will cause machine to stop when

in use,Switch off machine, cool for 2hours and re-start

Manufacturer:Shenzhen Baofengtong Electrical Manufacturing Co.,Ltd

contact Email:support@h2ofloss.com

®

Made in China

Printed in China

http://www.h2ofloss.com

1. Nozzle tip

2. Tip rotation dial

3. Power button

4. Mode selection button

5. Mode indicator lights

6. Charging indicator light

8. Charging port

10. Water tank cap

11.Water tank

Thanks for your purchase of h2ofloss water flosser.. Please read this user manual carefully and

keep it in a safe place for future reference. If you need any help, please contact us.

Material

Working Power

Charging time

Reservoir capacity

InputModel

HF-2

Battery capacity

Water pressure

Waterproof level

Operating method

5V 1A

2500mAh

20-140psi

IPX7

Pulsating water

ABS、PC

5W

3-5hours

300ML

Fittings

IMPORTANT SAFEGUARDS

When using electrical products, especially when children are present,basic

safety precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING.

DANGER:

To reduce the risk of electrocution:

Do not handle charger with wet hands.

Do not place charger in or drop charger into water or other liquid.

Check the charger cord for damage before the first use and during the life of

the product.

Use this product only as indicated in these instructions or as

recommended by your dental professional.

Only use tips and accessories that are recommended by H2ofloss,.

Do not drop or insert any foreign object into any opening on the product.

Keep charging unit and cord away from heated surfaces.

Do not use this product outdoors or operate where aerosol (spray)

products are being used or where oxygen is being administered.

Do not use iodine, saline (salt solution), or water insoluble concentrated

essential oils in this product. Use of these can reduce performance and

will shorten the life of the product. Use of these products may void

warranty.

Fill reservoir with water or other dental professional recommended

solution only.

Remove any oral jewelry prior to use of this product.

Do not use if you have an open wound on your tongue or in your mouth.

Troubleshooting

Overheating protection is activated

(Continuous use 5 tanks of

water with highest pressure)

Restart the device in 2 hour

Problem

Reservoir leaksSeal ring is abnormalRemove the seal ring and reinstall

Low water

pressure

Lasts only

few minutes

with full charge

Motor makes

sound but no

water coming out

Motor doesn't

make sound

Product stopped

working suddenly

Nozzle head blocksReplace with new tips

Low Battery (Keep the device

idle for more than 3 month)）

Activate the battery by

recharging it for 16 hours

Suction valve dislocation

Keep device on, fill water to the

hole where nozzle head goes into

Low batteryRecharge the device

Nozzle head blocks

Dead battery

Defective Charging cord

Try with new charging cable

adapter brokenTry with new adapter

Contact retailers

Replace with new nozzle heads

CauseCorrective action

If your problem still hasn't been fixed by above troubleshooting, please kindly contact with the

retailers for help.

Please add

water in this

place!

It may occur below situation when first time use this

machine or left it unused for a long time:The nozzle

head won’t spray water immediately after turning on

the machine.In this case, please follow below

instructions to make it work:

Add proper amount of water into the place where tips

are inserted in.

Insert the tip in and press power button to turn on the device.
