Installing Camera

Make sure the mounting surface is strong enough to hold at least

three times of the device weight.

Step1 Drill screw holes on the mounting surface as the positioning

map shows, and then put in the expansion bolts.

Step2 Attach the camera pedestal to the mounting surface with the

self-tapping screws.

Step3 Power up the camera, and then adjust the lens to the ideal

angle.

Step 5

Step 4

Connect your smart phone to your Wi-Fi network, and make sure your

smartphone is connected to Wi-Fi network with 2.4 GHz band, and then

do the following operations to finish adding camera.

Wait for booting to be finished, and then the camera indicator flashes

with green light.

Note:

If the Wi-Fi network has changed or the indicator status goes

wrong, reset the camera, and then do step 5 to add it again.

If you have more than one camera, do step 5 to add them one

by one.

Mounting Surface

Expansion Bolt

Self-tapping Screw

Camera

Positionting Map

This quick start guide is for reference only. Minor difference might

be found in user interface.

All the design and software here are subject to change without

prior written notice.

All trademarks and registered trademarks mentioned are the

properties of their respective owners.

Please visit our website or contact your local service engineer for

more information.

If there is any uncertainty or controversy, please refer to our final

explanation.

About the Guide

-

-

-

-

-

Q: Cannot connect the camera to Internet with Imou App?

Q: The camera failed to boot up, or cannot operate normally?

FAQ

Make sure the camera and your smartphone are connected

to the Internet successfully. If still cannot work, please press

and hold the reset button for 10s to reset the camera, then try

again.

Press and hold the reset button for 10s to reset the camera

and try again.

If still cannot work, please connect the camera to Wi-Fi

network on web page, then add your camera to Imou

account.

Connect the camera to the PC with Ethernet cable,

and set the PC IP to be the same network segment of

camera which is 192.168.1.108 by default, then login to

the web configuration page.

Select Setting > Network > Wi-Fi > Wi-Fi, you will see all

Wi-Fi signal around listed. Double-click your Wi-Fi

name, enter the Wi-Fi password, and then click

Connection.

After camera is connected to Internet, unplug the

Ethernet cable, and then follow the instruction of part

“Operate with Imou App” to try again.

-

-

a)

b)

c)

Q: Can I continue recording when the SD Card is full?

Q: Camera is offline?

Please check the LED indicator status:

If the green light is solid on, check whether your Wi-Fi router

is successfully connected to Internet. If Internet is OK, please

reboot your camera, or reset the camera to factory default

and configure again.

If the red light flashes slowly or solid on, reset the camera to

factory default and configure again.

If still cannot work, we suggest you contacting the aftersales

service.

When the storage is full, the camera will overwrite the oldest

existing records. We suggest you storing your important

recordings regularly.

-

-
