Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction manual in order that
you fully understand all the operational features it oers.
Read all the safety instructions carefully before use and keep this instruction manual for
future reference.
Foot Warmer
Instruction Manual
L10FW24 / L10FWB25
This product is only suitable for well-insulated spaces or occasional use.
Product Overview
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
• Main Unit
• Washable Lining
• Sponge
• Instruction Manual
• Safety Warnings
• If items are missing or damaged, please contact Partmaster (UK only).
• Tel: 0344 800 3456 for assistance.
General Operation
During rst time use, an odour might come out from the unit. This odour is
completely harmless, but be sure to air the foot warmer after it has been used for
the rst time.
1. Begin by heating the foot warmer to the highest heat level. After 15 minutes, slide the
switch to 1 / 2 /3 position to set the desired heading level (1 - Low / 2 - Medium / 3 - High).
2. Put your feet (or hands) into the foot warmer.
3. The foot warmer is equipped with overheating control. Its heating function shuts o
automatically after 90 minutes. To reheat the foot warmer, set the heat level back to 0 for
about 5-10 minutes. You can then select the desired heat level once again.
4. Set the heat level to 0 position to switch o the unit.
5. Unplug the foot heater when it is not in use.
Cleaning and Storage
Ensure you unplug the unit from the mains socket and wait it to cool down
completely before cleaning.
Cleaning
• Remove the lining from the foot warmer and wash it.
• Do not wash the foot warmer with water due to the risk of electric shock.
Storage
• Allow product to cool down before storage.
• Do not place objects on top of the product during storage.
• Due to a risk of suocation, the product and its packaging must be kept out of the reach of
children.
• Always store the foot warmer in a dry place and out of the way of other heat sources.
Hints & Tips
The unit does not work when I turn it on
• Check that your heater is plugged in and the power is turned on at the mains socket.
• Make sure the Slide Switch is not set at “0” position.
• If the heater still doesn’t work, do not try to repair the heater yourself.
If the unit’s power is automatically cut o follow the steps
below:
1. Unplug your heater and allow it to cool down.
2. If there is any sign of physical damage (e.g. melting, or burning of the case), do not attempt
to use your heater. Please leave all maintenance work to qualied personnel.
3. Plug-in the heater and switch it on again. If it cuts o again, move the heater to a better
ventilated location.
Specications
Model L10FW24 / L10FWB25
Supply Voltage 220 - 240V~ 50 Hz
Power Input 100 W
Off mode power 0.23 W
The time needed to automatically reach off mode 0 min.
Dimension (W × D × H) 300 × 300 × 240 mm
Features and specications are subject to change without prior notice.
For the latest version of the Safety and Instruction Manual, please visit the ocial website below
(other websites may not contain the full and most updated version):
https://www.currys.co.uk/services/repairs-maintenance/product-service-manuals.html
1. Display
2. 0/1/2/3 Switch
• Switch to 0 position to
turn o the unit.
• Switch to 1/2/3 position
to set desired dierent
heating level (low /
medium / high).
Foot Warmer Washable Lining
The lining can be taken out for cleaning.
1
2
Control Handset
Sponge
You may keep the sponge inside
the foot warmer for enhanced
comfort experience, or simply
remove it before using.
