ENGLISH
2
MEGA20W (95-2000)
RECHARGEABLE 20W MEGAPHONE WITH SIREN & RECORD FUNCTION
OPERATING INSTRUCTIONS
Accordance with the requirements of CE standard
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in accor-
dance with your local regulations. Batteries shall not be exposed to excessive heat such as sunshine, fi re or the like. When
the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.
IMPORTANT NOTE : Appliances containing Lithium-ion batteries
1. PRIOR to using the unit for the fi rst time, please charge fully the battery
2. Charge the battery regularly after each use. Don't wait until it is discharged!
3. DON'T allow the battery to discharge completely, otherwise it will lose 20% of its capacity or even be
totally damaged! If the voltage becomes too low, the internal circuits are not powered anymore and it will
become impossible to recharge the battery!
4. 4. If you don't use the unit for a longer period of time, it is recommended to charge it at 40% of its capacity
and check/charge it once per month.
The life time of the battery depends on the observance of these recommendations.
** BATTERIES ARE NOT COVERED BY THE WARRANTY **
We cannot be held responsible for damaged batteries further to the non-observance of these basic rules.
Charging the battery
Fig. 1 Fig. 2 Fig. 3
Open the back of the megaphone to access the battery
compartment (Fig. 1).
Unplug the battery pack from the megaphone (Fig. 2).
Remove the battery pack and plug the USB connector
into a USB socket delivering a voltage of 5V 2A (Fig. 3).
Operation
To switch on the megaphone, press the ON/OFF Button
(4) on the Back Cover. The power light (1) lights up.
Speak as close as possible into the microphone (2).
Adjust the Volume Control (8) to the desired level wit-
hout causing any howling or feedback.
OFF
SIREN
VOLUME
RECORD
PLAY
ON
1 3
4 5 6 7
2
8
Record Function
Adjust the volume control (8) to the min. before recording. Press the RECORD
button (6) and the indicator light (3) will light up. Speak your message into the
microphone. The longest recording time is about 8 secs. Press the REC button when
you've fi nished. When the memory is full, the RECORD button will pop up automa-
tically and the indicator light (3) will go off . Press the PLAY Button (7) to play the
recorded message.
Siren Function
Press the SIREN button (5) to activate the built-in siren. Press again to switch the
siren off .
SPECIFICATIONS
Power :........................................................................................................................................................................... 20W
Dims : ....................................................................................................................................................diam.155 x 245mm
Power supply: ............................................................................ Rechargeable Lithium battery (included) 3.7V 1500mAh
Weight: ...................................................................................................................................................................... 0.60Kg
Range: ........................................................................................................................................................... approx. 250m
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this product for environmentally safe
recycling.
