Handleiding Mabis Jumbo Display Thermometer

Handleiding

Specifications

DISPLAY: Liquid Crystal Display

DISPLAY RESOLUTION: 4 Digits (1/10TH of a degree increments)

MEASUREMENT RANGE: 89.6

o

F to 109.2

o

F

ACCURACY: ±0.2

o

F between 93.2

o

F and 107.6

o

F

SELF-TEST: All segment display test of 188.8

o

F

M

each cycle

TONE: Thermometer beeps when activated and produces a series of tone signals when the

temperature increase is less than 0.2

o

F/16 seconds

MEMORY: Displays last measured temperature

BATTERY: One, LR41 Alkaline

BATTERY LIFE: Approximately 3,000 temperatures

AUTOMATIC SHUT-OFF: After approximately 10 minutes

STORAGE TEMPERATURE: 14

o

F to 140

o

F

HUMIDITY: 10% to 80% RH

DIMENSIONS: 5-1/2” x 13/16” x 3/8”

WEIGHT: 0.5 Ounces (14.0 grams)

Specifications are subject to change without notice.

General Care

1. The thermometer should only be used under the supervision of an adult.

2. Do not walk, run or talk during temperature taking.

3

. Clean the thermometer before and after each use.

4

. Store the unit in the protective case when not in use.

5

. Do not bite the probe.

6. Do not store the unit where it will be exposed to direct sunlight, dust or humidity.

A

void extreme temperatures.

7. Dropping or subjecting your thermometer to strong shocks should be avoided.

8. Do not attempt to disassemble the unit, except to replace the battery.

9. If ERR displays and measurement is not attainable, the unit must be replaced.

NOTE: Performance of the device may be degraded if: operated outside of stated

temperature and humidity range; stored outside of stated temperature and humidity

range; thermometer undergoes mechanical shock (drop); patient temperature is

below ambient temperature.

Changing the Battery

The battery in your digital thermometer needs to be replaced when the “

t

” symbol

appears in the lower right of the display. Replace the battery with a 1.55V, LR41

alkaline or SR41 silver oxide type or equivalent.

To replace the battery,

1. Slide the battery cap away from the unit.

2. Using a non-metal pointed tool, carefully remove the

battery and insert the new battery with the positive

(+) side facing the display side of the unit.

3. Carefully slide the battery cap back into place, making sure that the cap fits

snugly to protect the battery compartment from moisture.

Note: Please properly dispose the battery away from small children and heat.

Taking an Oral Temperature

Approximate measurement time:

6

0 seconds

1

. Using the diagram on the right, place

t

he probe tip under the tongue as near

a

s possible to the heat pocket. The

d

iagram also shows the temperature

variables by not placing the tip in the

heat pocket area.

Note: Drinking hot or cold fluids,

exercising, smoking or performing other

activities may raise or lower your

temperature. Therefore, it is important to

relax for approximately 5 minutes with your

mouth closed prior to taking a reading

2. The current temperature is shown and the

o

F will continue to flash during the

reading.

3. When the peak temperature has been reached, the

o

F will stop flashing and the

thermometer will sound ten quick beeps.

4. To turn the unit off, press the ON/OFF button. The unit will automatically shut off

after approximately ten minutes.

Note: The mouth must remain closed during the measurement for the most accu-

rate reading. Opening the mouth could result in an extended measurement time

and may affect the reading.

Cleaning Instructions

Before and after each use, clean the area that extends about 2” from the tip of the

thermometer with a soft cloth and ispropyl alcohol diluted with water, or wash with

COLD soapy water.

NOTE:

1. The use of any other solution or cleaning method beyond the above mentioned

may result in reliability problems with the thermometer..

2. Do not let water or any solution penetrate the thermometer’s display window,

battery cover or back cover.

How to Take Your Temperature

1. Clean and disinfect the thermometer according the instructions provided.

2. Apply a disposable probe cover to the clean, dry thermometer.

3. Determine whether the measurement site will be oral, rectal or underarm.

Note: Measurement time may vary based on the selected site.

4. Press the ON/OFF button (the unit will beep) to activate the thermometer.

This is the LCD display test, which insures all parts of the

display are functioning properly. Continue to hold the button

down and in approximately 3 seconds the display will show the

last recorded temperature as follows.

This display shows the last temperature reading. Within

approximately 3 seconds of releasing the button or if no

reading is stored in memory, the display will read as follows.

The L with the flashing

o

F indicates the thermometer is ready

to take a temperature reading.

PROBE COVER ORDER FORM

CUT OUT AND MAIL TO:

MABIS HEALTHCARE

1931 NORMAN DRIVE SOUTH

WAUKEGAN, IL 60085

Please send packages of disposable probe covers (100

probes per package). Enclosed is $5.00 per package plus $3.00 for

shipping and handling for each order.

Please ship to:

NAME:

ADDRESS:

CITY: STATE: ZIP:

PHONE:

CUT OUT AND MAIL TO:

MABIS HEALTHCARE

1

931 NORMAN DRIVE SOUTH

WAUKEGAN, IL 60085

THERMOMETER WARRANTY REGISTRATION

(MUST BE COMPLETED WITHIN 10 DAYS OF PURCHASE)

N

AME:

ADDRESS:

CITY: STATE: ZIP:

PURCHASED FROM:

CITY: STATE: ZIP:

DATE PURCHASED:

MODEL PURCHASED:

q 15-720-000

USER INFORMATION (OPTIONAL)

q MALE q FEMALE AGE:

AGE OF YOUNGEST FAMILY MEMBER

q UNDER 6 MONTHSq 6 MONTHS - 1 YEAR

q 1 - 3 YEARS q 3 - 5 YEARS q OLDER

PROBE TIP DIGITAL DISPLAY WINDOW

ON/OFF BUTTON

BATTERY COVER

F

F

H

EAT

POCKET

HEAT

POCKET

9

8.4

o

F

3

6.9

o

C

9

8.4

o

F

3

6.9

o

C

98.8

o

F

37.1

o

C

9

8.8

o

F

3

7.1

o

C

9

7.9

o

F

3

6.6

o

C

97.7

o

F

36.4

o

C

97.9

o

F

36.6

o

C

9

8.1

o

F

3

6.7

o

C

#91-1905-720 07/06

©2006 M

ABIS

Healthcare

NOTE: This order form is for shipments within the United States and Canada.

LIMITED ONE YEAR WARRANTY

This MABIS Digital Thermometer is guaranteed to be free of manufacturing defects

for a period of one year from the date of purchase under normal use. This warranty

applies to the original registered purchaser only. All repairs on your MABIS Digital

Thermometer should be sent prepaid to: MABIS Healthcare, Attn: Repair

Department, 1931 Norman Drive South, Waukegan, IL 60085. MABIS Healthcare

shall incur no liability under this warranty for any damage from any cause other than

inherent manufacturing defects. ALL IMPLIED WARRANTIES, INCLUDING

MERCHANT

ABILITY AND FITNES

S ARE LIMITED TO THE DURA

TION OF THIS

WARRANTY. THIS WARRANTY DOES NOT INCLUDE ANY LIABILITY

FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES. Some states do not allow limitation on how long

an implied warranty lasts or do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitations or exclusions may not apply to

you. This warranty gives you specific legal rights and you may also have other rights

which vary from state to state.

Deluxe “Jumbo Display”

Digital Thermometer

with Beeper and Memory

Thank you for purchasing a MABIS Digital Thermometer. Please read the following

i

nstructions to achieve the most accurate temperatures and safe operation. With

p

roper care and use, your thermometer will provide you with years of reliable

readings.

What is a “Normal” Temperature?

Although the generally accepted “normal” temperature reading is 98.6

o

F, tempera-

ture readings can vary from 97

o

F to 99

o

F and still may be considered “normal”.

Variations in temperature can be attributed to activities such as exercise, smoking,

eating and drinking. Even time of day may influence your temperature. For exam-

ple, your temperature is lower in the morning than in the afternoon. Other varia-

tions may be due to the location of the temperature reading. While the oral temper-

ature follows the guidelines previously described, a rectal temperature is generally

1.0

o

F higher. Conversely, an axillary (under the arm) temperature will be 1.0

o

F

lower.

Features of your MABIS Digital Thermometer

Taking an Axillary Temperature (under the arm)

Approximate measurement time: 5 minutes or longer

1. Wipe the underarm with a dry towel.

2. Place the probe tip under the arm so the tip is touching the skin with the ther-

mometer perpendicular to the body.

3. Position the arm across the chest so the probe tip is well covered by the arm.

This also insures the probe is not affected by the room’s air.

4. When the peak temperature has been reached, the

o

F will stop flashing and the

thermometer will sound ten quick beeps.

5. To turn the unit off, press the ON/OFF button. The unit will automatically shut off

after approximately ten minutes.

Note: Axillary temperatures are generally 1.0

o

F lower than oral readings.

Taking a Rectal Temperature

Approximate measurement time: 60 seconds

Note:

Rectal temperatures are an appropriate and reliable method for infants and

small children. Otherwise, this method should only be used when it is impossible or

impractical to take an oral or axillary temperature.

1. After applying the disposable probe cover, apply a water-soluble lubricant to

the tip.

2. Gently insert the probe a MAXIMUM of 1/2” into the rectum.

3. When the peak temperature has been reached, the

o

F will stop flashing and the

thermometer will sound ten quick beeps.

4. To turn the unit off, press the ON/OFF button. The unit will automatically power

down after approximately ten minutes.

Note: Rectal temperatures are generally 1.0

o

F higher than oral readings.

Using Disposable Probe Covers

It is recommended to use the enclosed disposable probe covers to prevent cross

contamination. Additional probe covers can be purchased from your MABIS Dealer

or with the order form provided.

#91-1905-720 07/06
