1. For additional connection information, refer to the

owner’s manual(s) for any component(s) connected

to the XR50 Loudspeaker.

2. The design of XR50 Loudspeaker took into ac-

count the acoustic characteristics of the Front Panel

Your decision to own this McIntosh XR50 Loudspeak-

er System ranks you at the very top among discrimi-

nating music listeners.. You now have “The Best.” The

McIntosh dedication to “Quality,” is assurance that

you will receive many years of listening enjoyment

from this unit.

Please take a short time to read the information in

this manual. We want you to be as familiar as pos-

sible with all the features and functions of your new

McIntosh.

Safety Instructions .................................................... 2

Thank You and Please Take a Moment ..................... 3

Technical Assistance and Customer Service ............ 3

Table of Contents and General Information .............3

Connector/Cable Information ................................... 3

Introduction ...............................................................4

Performance Features ............................................... 5

Dimensions ............................................................6-7

Unpacking the Loudspeaker .....................................8

Installation .............................................................8-9

How to Connect ................................................. 10-11

Photos ................................................................. 12-13

Specifications .......................................................... 14

Packing Instruction ................................................. 15

Table of Contents

Thank You

Please Take A Moment

Technical Assistance

If at any time you have questions about your McIntosh

product, contact your McIntosh Dealer who is familiar

with your McIntosh equipment and any other brands

that may be part of your system. If you or your Dealer

wish additional help concerning a suspected problem,

you can receive technical assistance for all McIntosh

products at:

McIntosh Laboratory, Inc.

2 Chambers Street

Binghamton, New York 13903

Phone: 607-723-3512

Fax: 607-724-0549

Customer Service

If it is determined that your McIntosh product is in

need of repair, you can return it to your Dealer. You

can also return it to the McIntosh Laboratory Service

Department. For assistance on factory repair return

procedure, contact the McIntosh Service Department

at:

McIntosh Laboratory, Inc.

2 Chambers Street

Binghamton, New York 13903

Phone: 607-723-3515

Fax: 607-723-1917

The serial number, purchase date and McIntosh Dealer

name are important to you for possible insurance

claim or future service. The spaces below have been

provided for you to record that information:

Serial Number: _______________________________

Purchase Date: _______________________________

Dealer Name: ________________________________

Copyright 2011 © by McIntosh Laboratory, Inc.

General Information

Power Control Connectors

The XR50 Power Control Jacks (IN/OUT) receive and

pass on an ON/OFF signal from +5 to +12 volts. An

additional connection passes on Meter Illumination

Control for compatible Power

Amplifiers. The 1/8 inch stereo

mini phone plug connects to a

McIntosh Preamplifier or A/V

Control Center Power Control

Output.

Connector/Cable Information

Power

Control

Ground

Meter

Illumination

Control

Pass Thru

Grille and it should be attached to the Loudspeaker

for the best sonic performance.

3. If there is an obvious lack of high, mid or low

frequencies after extended periods of overdrive,

the Protection Device(s) may have activated. These

devices will automatically reset when the volume

level is greatly reduced until the output of the af-

fected Loudspeaker Driver(s) returns to

normal.

4. When discarding the unit, comply with

local rules or regulations. Batteries should

never be thrown away or incinerated but

disposed of in accordance with the local

regulations concerning battery disposal.

5. For additional information on the XR50

and other McIntosh Products please visit the McIn-

tosh Web Site at www.mcintoshlabs.com.
