Handleiding Sheffield PLA1494 Luchtbevochtiger

Handleiding

Auto-Off:

Humidifier Continuous spray time: about 4.5h

Humidifier Interval spray time: about 9h

Fan speed: 1: 0.2A/2800RPM about 6h

2: 0.37A/3400RPM about 3.5h

3: 0.52A/3800RPM About 2h

Humidifier+Fan+LED: speed 3 about 1.5h

IMPORTANT SAFETY INSTRUCTIONS - READ

CAREFULLY AND KEEP FOR FUTURE REFERENCE

Do not use the charging cable if damaged, inspect before use and contact

you retailer for service if damage is found.

• Be wary of any edges, uneven surfaces, sharp parts, accessories

and its packaging so as to prevent any possible injury or damage.--

• This appliance is not intended for use by persons (including

children) with reduc

ed physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised to

ensure that they do not play with the appliance.

• Do not immerse the base of the fan or its charging cord in water. Do

not use with wet hands or use in damp situations such as

bathrooms. Do not place the Fan next to an open window; Rain

splashing on the Fan could cause an electric shock hazard.

• CAUTION: To prevent damage to the appliance do not use alkaline

cleaning agents when cleaning, use a soft cloth and a mild

detergent.

• Warning - There is a risk of injury from the rotating Fan blades!

• Do not insert fingers, pencils or any other object through the grid

and into the rotating blade while the Fan is working. Wait until the

fan is at a standstill when switched off, the blades will continue

running briefly.

• Do not operate the fan in an area where gasoline is used or stocked,

painting or such flammable liquids.

• Do not modify, repair or dismantle the Fan. Doing so may result in

fire, electric shock, complete breakdown of the fan, etc. All of which,

are not covered under Manufacturer’s warranty.

Battery Warnings

• If these guidelines are not followed, batteries may experience a

shortened life span or may present a risk of damage to the device,

fire, chemical burn, electrolyte leak, and/or injury.

• Do not leave the device exposed to a heat source or in a high

temperature location, such as in the sun in an unattended vehicle.

To prevent the possibility of damage, remove the device from the

vehicle or store it out of direct sunlight, such as in the glove box.

• Do not disassemble, modify, re-manufacture, puncture or damage

the device or batteries.

• Do not remove or attempt to remove the non-user-replaceable

battery.

• Contact your local waste disposal department to dispose of the

device/batteries in accordance with applicable local laws and

regulations.

2 in 1 Humidifier and Fan

PLA1494

180

o

Rotation

Distributed By:

Prolink Asia Ltd, 25 Aerovista Place,

Wiri, Manukau

Tank

Press the Fan key once, Speed 1 will be selected, Press the key again and speed 2 is selected, Press the key again and speed 3

will be selected, Press th

e key again and unit will turn off.

Press the Spray key once, continuous mist will be selected, Press the key again and intermittent mist is selected (spray for 3

seconds and stop for 3 seconds),

Press the key again to stop.

Press and hold the spray key once, LED turns on in colour changing mode, Long press the key again to fix the colour, Long

press the key again to turn off.

To stop the unit burning the swab when it runs out of water this product is designed to turn off after 8 hours using continuous

spray and after 12 hours using intermittant spray operation.

Steps

• Pay attention when replacing the swap so as not to lose it.

• Make sure the water is filled before each use, do not use the humidifying function without water.

• Turn off when filling the water or cleaning, Do Not rinse directly under water to avoid risk of

damage or injury. To clean wipe the outside and tank with a damp cloth and towel dry.

Charging and Maintenance

• Before first use charge the fan for at least 2 hours.

• Connect the charging cable to

a suitable USB output socket (at lease 1A output), plug the Micro USB plug into the fan. LED will

show red when charging and turn off when fully charged.

• Charge the fan at least once every three months if left unattended for extended periods.

Accessories

LED Indicator

Rotate the top

cover anti

clockwise and

lift off.

Fill water bowl

with water and

replace top cover

and rotate

clockwise to lock

Plug power

supply into

micro USB

port.

Open fan up to

operate.

Unit can be turned

off by closing the

fan or by pressing

the keys.

1. Pull out the cotton

swab tube to

replace the cotton

swab.

2. Pay close attention

to the bottom spring

and do not lose

Working Current: 800mA

Rated Power: 4W
