1 2 3 4 5 6

Remove the laundry and switch off

the dryer

Programmes / Fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, Page 7.

Observe the care instructions on the care label.

Dryness level, timer programming and options can be

individually selected depending on the selected programme

and the progress of the programme.

algodón/algodão Cotton Hard-wearing fabrics

sintéticos Easy-Care Fabrics made from synthetic

or blended fabrics

mix Mixed Fabrics A mixed load of fabrics made

of cotton and synthetic fabrics

lencería/lingerie Lingerie Very delicate synthetic, cotton

or blended fabrics

secar c/cesto Wool in basket Hand or machine-washable fabrics

made of wool or containing wool

vaqueros/jeans Jeans Fabrics made from jeans/denim

 caliente/

quente

Warm time

program

All types of fabric except for wool

and silk

automático Auto Cotton, easy-care and blended

fabrics

microfibras/

micro fibras

Outdoor Weatherproof and outdoor clothing

with a membrane coating and

water-repellent fabrics

express 40 min. Super 40' Synthetics, cotton or blended

fabrics

Your dryer

Congratulations! - You have chosen a modern, high-quality

domestic appliance from Siemens.

One distinctive feature of the condensation dryer with heat pump

and automatic cleaning of the heat exchanger is its low energy

consumption.

Every dryer which leaves our factory is carefully checked to

ensure that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will

be pleased to help.

Environmentally-responsible disposal 

This appliance is labelled in accordance with European Directive

2012/19/EU concerning used electrical and electronic appliances

(waste electrical and electronic equipment - WEEE). The guideline

determines the framework for the return and recycling of used

appliances as applicable throughout the EU.

For further information about our products, accessories,

spare parts and services, please visit: www.siemens-home.com.

Intended use

Preparation

Open the door/load the laundry /

press the programme selector /

set the programme

1

2

Drying

ʋFor domestic use only.

ʋOnly to be used for drying, refreshing or unwrinkling

fabrics that have been washed with water.

Keep children younger than 3 years old away from the

dryer.

Do not let children make the cleaning and maintenance

work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old and

older, by persons with reduced physical, sensory or

mental abilities and by persons with insufficient

experience or knowledge if they are supervised or have

been instructed in its use by a responsible adult.

This appliance is intended for use up to a maximum

height of 4000 metres above sea level.

Drying

Display panel and buttons

ʑ

Display panel

Please clean lint filter Clean the fluff filters a Page 4.

Please empty

condensate

container

Empty the condensate container a Page 4 and/or clean the filter in the condensate container

a Installation and maintenance instructions, Page 3.

Refresher-container

is empty, please

re-fill.

Fill the refresher tank with distilled water for steam programmes a Page 8.

Heat exchanger is

being rinsed

Automatic cleaning of the heat exchanger. Do not empty the condensate container while this is

displayed.

ʑ

Buttons

ajuste secar

(Drying target)

Select the dryness level (e.g. C/board Dry) or the drying time (20 mins up to 3 hrs 30 mins.,

depending on the model and programme).

 C/board Dry Extra: For laundry with thick, multi-layered parts.

+C/board Dry: For single-layered laundry.

ÔüIron dry: The condition of the laundry means it is suitable for ironing (iron clothes in order to

avoid creases).

menos

â

(Less Ironing)

After the programme finishes, the drum moves at regular intervals to prevent creases.

The automatic anti-crease function can be set in 30-minute segments up to 120 minutes.

The standard setting for each programme is 60 minutes.

terminado en/em

(Finished in)

When a programme is selected, the anticipated drying time for the maximum load is displayed.

While drying, the moisture sensors detect the actual load and correct the programme length.

This is shown in the display by jumps in the terminado en/em (Finished in) time.

The terminado en/em (Finished in) time can be delayed in one-hour steps, up to a maximum of

24 hours. Press the terminado en/em (Finished in) button repeatedly until the required number of

hours is displayed (h=hour).

sChildlock: Activate/Deactivate a Start programme, press and hold the terminado en/em

(Finished in) button above the display panel for 5 seconds.

Ûmenu ÖüSpin Speed; ×üAdjust drying level; Õülow heat; üAmount of steam

Ö]Spin Speed: The spin speed that was used for spinning in the washing machine a used

exclusively to display the anticipated drying time (terminado en/em (Finished in) time) more

accurately.

×cAdjust drying level: The drying result (e.g. C/board Dry) can be increased in three stages

(+1 - max. +3); exception: timer programmes. Default = 0. After one programme has been finely

adjusted, the setting is retained for the others.

Õlow heat : Reduced temperature for delicate fabrics ', e.g. polyacrylic, polyamide or elastane,

with a longer drying time.

üAmount of steam: Only for steam programmes. Fine adjustment of the steam can be selected:

normal, ÷ strong, ø very strong. Standard setting: normal.

ecoPerfect ¢To save energy during a prolonged drying time.

speedPerfect iFor drying in a shorter time at a higher level of energy consumption.

memoria 1/2

(Memory 1/2)

For saving individual programme settings that are used frequently. Use the programme selector to

select the required programme. Press and hold the memoria 1/2 (Memory 1/2) button for

3 seconds until the required programme has been saved. To select the saved programme, briefly

press the memoria 1/2 (Memory 1/2) button. The programme that is called from memoria 1/2

(Memory 1/2) is displayed on the display panel.

ajustes base 3s

(Basic settings 3 sec.)

end signal, button signal, auto power-off

and Language. Press and simultaneously hold both

ajustes base 3s (Basic settings 3 sec.) buttons for 3 seconds, in order to access the menu.

end signal, button signal: The signal volume level can be selected: off - quiet - medium - loud -

very loud.

auto power-off: Activate/deactivate by pressing the ajustes base 3s (Basic settings 3 sec.)

buttons. The dryer automatically switches off, depending on your selection, after 15, 30

or 60 minutes. The setting is active after menos â(Less Ironing) or end of programme.

Language: Select the required language.

Close the door

3

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋControl panel . . . . . . . . . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . .3/4

ʋDisplay panel and buttons . . . . . . . . . . . 5

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . 5

ʋSteam programmes . . . . . . . . . . . . . . .8/9

ʋImportant information /

consumption rates . . . . . . . . . . . . . . . . 10

ʋNormal noises . . . . . . . . . . . . . . . . . . . 11

ʋWhat to do if ... / After-sales service. . . 12

ʋSafety instructions . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged.

Inform your after-sales service.

Inspect the dryer

Sort the laundry

Remove all items from pockets.

Check for cigarette lighters.

The drum must be empty prior to loading.

See programme overview on page 7.

See also separate instructions for “basket for woollens”

(depending on the model)

Make sure your hands are dry.

Hold the plug only.

Connect the mains

plug

Empty the condensate container

If the condensation drain is installed, it is not necessary to

empty the condensate container a separate Instructions

for condensation drain.

Empty the container after each drying cycle, and not during

the cycle.

1. Remove the container, holding it level.

2. Pour out the condensed water. Push the container back

in until it clicks into place.

You must also observe the a Installation and maintenance

instructions, Page 3.

Clean the fluff filters

The fluff filter consists of two parts.

Clean the inner and outer fluff filter

after every drying cycle.

1. Open the door. Remove fluff from the

door/door area.

2. Pull out the inner

and outer fluff filter

and open them out.

3. Remove any fluff,

rinse both fluff filters

under running water

and dry thoroughly.

4. Fold the fluff filters

closed, put them

back together and reinsert them into the appliance.

7

6

End of the programme ...

Interrupt the programme

1. Open the door or select the initio/pausa+carga

Øü(Start/Pause) button, the drying cycle is interrupted.

2. Add or remove laundry and close the door.

3. If required, select a new programme and additional

functions. Select the initio/pausa+carga

Øü(Start/Pause) button. The terminado en/em

(Finished in) time is updated after a few minutes.

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care instructions.

hcSuitable for tumble drying

(cDry at normal temperature.

'cDry at low temperature.

)cDo not tumble dry.

Do not tumble-dry the following fabrics:

– Non-breathable fabrics (e.g. rubber-coated).

– Delicate materials (silk, curtains made from synthetic material) a these may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry

(e.g. towels).

– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc.

together or use a laundry bag.

– Do not over-dry easy-care laundry a Risk of creasing. Allow laundry to finish drying in

the air.

– Do not iron laundry immediately after drying; fold items up and leave for a while

a residual moisture will then be distributed evenly.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.

aDo not use the  C/board Dry Extra programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

reduces the drying effect.

– When washing laundry that is to be tumble-dried afterwards, use the correct amount of

fabric softener as specified in the manufacturer's instructions.

– With a small load, use the time programme.

Tips for unwrinkle/refresh

– Use your dryer to unwrinkle and refresh fabrics.

– Unwrinkling cycle to reduce creasing.

– Refresh cycle to reduce odours in fabrics.

Do not use unwrinkle/refresh for the following fabrics:

– Wool, leather, fabrics with metal, wooden or plastic parts.

– Waxed and oiled jackets.

– Sort the laundry by colour and use the unwrinkle/refresh cycles separately to prevent

discolouration.

– For best results, take each item out of the machine separately, as soon as the programme

comes to an end, and hang on a clothes hanger to finish drying. If necessary, pull into

shape.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry in the washing machine a the higher the spin speed,

the shorter the drying time will be, thus less energy is consumed. Also spin easy-care

laundry.

– Use the maximum recommended capacity, but do not exceed it a Programme overview

page 7.

– Make sure the room is well ventilated during drying.

– Clean the fluff filters after every drying cycle aCleaning the fluff filters, Page 4.

– Keep the supply of cool air unobstructed a Do not cover or block the air inlet.

Take care when opening the door.

Hot steam may escape.

5

4

Steam programmes

ücasual Casual refresh Casual wear made of cotton or

artificial fibres

trajes

fatos

Business refresh Suits, jackets and trousers

Ìsintéticos Easy-care non-iron Easy-care fabrics

Ìüalgodón

algodão

Cottons non-iron Hard-wearing fabrics made from

cotton

Further information a Page 5.

Fascia panel

Two-part fluff filter

Air inlet

Select the

initio/pausa +carga Ø

(Start/Pause) button

Condensate

container with filter

Door

Programme selector / Off Display panel / Buttons

Installation aInstallation and maintenance instructions, Page 1

The dryer is switched on and off by pressing the  button in the centre

of the programme selector.

Select the programme by turning the outer ring on the programme

selector (the selector can be turned in both directions). The selected

programme is displayed.

Change the functions in the display using the buttons ?>

ajuste secar (Drying target)

 C/board Dry Extra, +C/board Dry, ÔüIron Dry

menos â(Less Ironing) Reduced ironing function can be set up to 120 mins

terminado en/em

(Finished in)

Time delay/sChildlock

Ûmenu Ö]Spin Speed, ×cAdjust drying level, Õlow heat,  Amount of steam

ajustes base 3s

(Basic settings 3 sec.)

end signal, button signal, auto power-off and Language

Clean fluff filters reduce energy consumption.

Depending on the selected programme, it may not be possible to select individual options.

ecoPerfect ¢Energy-saving programme

sequence

speedPerfect iAccelerated programme

sequence

memoria 1 (Memory 1)

Save or call individual settings

memoria 2 (Memory 2)

initio/pausa+carga Øü

(Start/Pause)

Start or pause the programme

}

7

9505 / 9000964701

*964701*

BSH Hausgeräte GmbH

Carl-Wery Straße 34

81739 München/GERMANY

WT48Y740EE

Overview of Programmes a Refer to the table of consumption rates on Page 10 and the notes on Page 6.

a Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying

aDryness levels can be individually selected a C/board Dry Extra, +cC/board Dry and Ô

cIron dry (depending on the model and programme).

Degree of dryness can be finely adjusted (depending on the programme). Multi-layered fabrics require a longer drying time than single-layered items of clothing.

Recommendation: Dry separately.

Programmes Max.

Type of fabric

Options and notes

algodón/algodão (Cotton) 8 kg/

5 kg*

Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen

sintéticos (Easy-care) 3.5 kg Fabrics made from synthetic or blended fabrics

mix (Mixed fabrics) 3.5 kg Mixed fabrics made of cotton and synthetics

lencería/lingerie (Lingerie) 2 kg Very delicate synthetic, cotton or blended fabrics

secar c/cesto

(Wool in basket)

1 kg

Hand or machine-washable fabrics made of wool or containing wool Use with separate basket only a see the Basket for woollens description.

vaqueros/jeans (Jeans) 6 kg Fabrics made from jeans/denim

ücaliente/quente

(Warm time program)

All types of fabric except for wool and silk For pre-dried, multi-layered fabrics or small, individual items of laundry.

Also for subsequent drying.

automático (Auto) Cotton, easy-care and blended fabrics Automatic detection of residual moisture and drying of fabrics.

microfibras/micro fibras

(Outdoor)

2 kg

Weatherproof and outdoor clothing with a membrane coating

and water-repellent fabrics

Particularly gentle.

express 40 min. (Super 40' ) 2 kg Synthetics, light cotton or blended fabrics Easy-to-dry textiles.

Steam programmes

ücasual (Casual refresh) 1.5 kg Casual wear made of cotton or artificial fibres For refreshing fabrics only. Observe the care labels.

ütrajes/fatos

(Business refresh)

1.5 kg

Suits, jackets and trousers

Ìüsintéticos

(Easy-care non-iron)

1.5 kg

Easy-care fabrics Only for unwrinklng of fabrics.

Best results can be expected if "Non-iron" appears on the manufacturer's

label; remove the items as soon as the programme ends.

Ìüalgodón/algodão

(Cottons non-iron)

2.5 kg

Hard-wearing fabrics made from cotton

*Reduced loading when the option speedPerfect iis selected

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Siemens WT48Y740EE Wasdroger. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Siemens. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Siemens WT48Y740EE Wasdroger in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Siemens Wasdrogers
Meer handleidingen voor Wasdrogers

Veelgestelde vragen over Siemens WT48Y740EE Wasdroger

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Beoordeling

Gerelateerde producten

Handleiding

Siemens WT45H20AFG Wasdroger

Handleiding

Siemens WT45H20MNL Wasdroger

Handleiding

Siemens WQ45G200G Wasdroger

Handleiding

Siemens WQ46H2CLNL Wasdroger

Handleiding

Siemens WT43H200NL Wasdroger

Handleiding

Siemens WP31G209NL Wasdroger

Handleiding

Siemens WT45W469GR Wasdroger

Handleiding

Siemens WQ46H2DXG Wasdroger

Gerelateerde categorieën
