How to use

Charge the headphones.

Insert the supplied rechargeable battery into the left housing of

the headphones.

Observe the correct polarity when installing battery.

Connect the A/V component using its headphone jack.

Set the volume of the A/V component as high as possible, but not so high that the audio signal becomes

distorted.

Headphone

jack (Stereo

mini jack)

TV, Digital music player, etc.

Turn on the A/V component.Wear the headphones.

Before listening

To reduce the risk of hearing damage, first

lower the volume.

Tactile dot

Checking the included items

Transmitter TMR-RF810R (1) Headphones MDR-RF811R (1) AC adaptor (1) Rechargeable nickel-metal

hydride battery BP-HP550-11 (1)

Card warranty (1)

Operating Instructions (this manual) (1)

English Wireless Stereo Headphone System

WARNING

To reduce the risk of fire or electric shock, do not

expose this apparatus to rain or moisture.

To reduce the risk of fire or electric shock, do not expose

this apparatus to dripping or splashing, and do not place

objects filled with liquids, such as vases, on the apparatus.

Do not install the appliance in a confined space, such as a

bookcase or built-in cabinet.

As the main plug of AC power adaptor is used to

disconnect the AC power adaptor from the mains, connect

it to an easily accessible AC outlet. Should you notice an

abnormality in it, disconnect it from the AC outlet

immediately.

CAUTION

Risk of explosion if the battery is replaced by an incorrect

type.

Do not expose the batteries (battery pack or batteries

installed) to excessive heat such as sunshine, fire or the

like for a long time.

Do not subject the batteries to extreme low temperature

conditions that may result in overheating and thermal

runaway.

Do not dismantle, open or shred secondary cells or

batteries.

Do not expose cells or batteries to heat or fire. Avoid

storage in direct sunlight.

In the event of a cell leaking, do not allow the liquid to

come in contact with the skin or eyes. If contact has been

made, wash the affected area with copious amounts of

water and seek medical advice.

Do not use any charger other than that specifically

provided for use with the equipment.

Secondary cells and batteries need to be charged before

use. Always use the correct charger and refer to the

manufacturer’s instructions or equipment manual for

proper charging instructions.

After extended periods of storage, it may be necessary to

charge and discharge the cells or batteries several times

to obtain maximum performance.

Dispose of properly.

High volume may affect your hearing.

The nameplate of transmitter is located on the bottom

exterior.

The validity of the CE marking is restricted to only those

countries where it is legally enforced, mainly in the

countries EEA (European Economic Area) and Switzerland.

Hereby, Sony Corporation declares that this equipment is

in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is

available at the following internet address:

http://www.compliance.sony.de/

Hereby, Sony Corporation declares that this equipment is

in compliance with the UK relevant statutory

requirements. The full text of the declaration of conformity

is available at the following internet address:

https://compliance.sony.co.uk

Disposal of waste batteries and

electrical and electronic equipment

(applicable in the European Union and

other countries with separate collection

systems)

This symbol on the product, the battery or

on the packaging indicates that the product and the

battery shall not be treated as household waste. On

certain batteries this symbol might be used in

combination with a chemical symbol. The chemical

symbol for lead (Pb) is added if the battery contains more

than 0.004% lead. By ensuring that these products and

batteries are disposed of correctly, you will help to prevent

potentially negative consequences for the environment

and human health which could be caused by

inappropriate waste handling. The recycling of the

materials will help to conserve natural resources. In case

of products that for safety, performance or data integrity

reasons require a permanent connection with an

incorporated battery, this battery should be replaced by

qualified service staff only. To ensure that the battery and

the electrical and electronic equipment will be treated

properly, hand over these products at end-of-life to the

appropriate collection point for the recycling of electrical

and electronic equipment. For all other batteries, please

view the section on how to remove the battery from the

product safely. Hand the battery over to the appropriate

collection point for the recycling of waste batteries. For

more detailed information about recycling of this product

or battery, please contact your local Civic Office, your

household waste disposal service or the shop where you

purchased the product or battery.

Notice for customers: the following information is only

applicable to equipment sold in countries applying EU

directives and/or UK applying relevant statutory

requirements

This product has been manufactured by or on behalf of

Sony Corporation.

EU and UK Importer: Sony Europe B.V.

Inquiries to the EU Importer or related to product

compliance in Europe should be sent to the

manufacturer’s authorized representative, Sony Belgium,

bijkantoor van Sony Europe B.V., Da Vincilaan 7-D1, 1930

Zaventem, Belgium.

Inquiries to the UK Importer or related to product

compliance in the UK should be sent to the manufacturer’s

authorized representative, Sony Europe B.V., The Heights,

Brooklands, Weybridge, Surrey KT13 0XW, United Kingdom.

This equipment has been tested and found to comply with

the limits set out in the EMC regulation using a connection

cable shorter than 3 meters.

(Red) (Off)

Complete when indicator

turns off.

After use

Take off the headphones, then turn off the power.

About sending RF signals

The transmitter starts sending RF signals automatically

when it detects an audio signal from the connected

component.

Notes

 If hiss is heard, move closer to the transmitter.

 You may hear some noise when you disconnect the

AC adaptor from the transmitter before turn off the

headphones.

If no signal or low signal is input

for about 4 minutes

If the transmitter does not detect an audio signal for

more than about 4 minutes, it will stop sending RF

signals, and the POWER indicator will blink for 1 minute,

and then turn off.

When the transmitter receives an audio signal again, it

starts sending the RF signals, and the POWER indicator

will light up green again.

You may not hear the beginning of the sound from the

headphones until the transmitter starts sending the RF

signals after detecting an audio signal.

RF signal transmission may stop when an extremely low

sound is input for about 4 minutes. If this happens,

raise the volume of the connected A/V component

within the range where the sound is not distorted, and

lower the volume of the headphones.

Tips for charging

Charge the headphones first

The supplied rechargeable nickel-metal hydride battery is

not charged from the first time you use them. Charge

them before use.

If the transmitter’s POWER indicator

does not light up red

Check if the switch on the left housing of the headphones

is set to OFF. If the switch is set to ON, the POWER

indicator does not light up.

You cannot charge any rechargeable battery or dry battery

other than the supplied battery.

Charging and usage time

Approx. charging time Approx. usage time

1)

1 hour

16 hours

2)

45 minutes

3)

13 hours

3)

1) at 1 kHz, 1 mW + 1 mW output

2) hours required to fully charge an empty battery

3) Time may vary, depending on the temperature or

conditions of use.

To recharge supplied battery after

use

Connect the headphones to the CHARGE plug of the

transmitter after use. The POWER indicator lights up red,

then charging starts.

When charging is complete, there is no need to remove

the headphones from the transmitter.

Remaining battery

To check the remaining battery charge of the headphones,

turn on the switch located on the left housing of the

headphone, and check the POWER indicator located on

the left housing. The battery is still serviceable when the

indicator lights up red.

Charge the headphones if the POWER indicator light dims,

flashes, or the sound becomes distorted or noisy.

Notes

 Do not connect the CHARGE plug to anything other

than these headphones.

 The transmitter automatically stops sending RF signals

while charging the battery.

 This system is designed to charge only the supplied

rechargeable battery type BP-HP550-11 for safety. Note

that other types of rechargeable battery cannot be

charged with this system.

 If dry batteries are installed, they cannot be charged.

 Do not attempt to use the supplied BP-HP550-11

rechargeable battery for other components. They are

for use with this system only.

 Charge in an environmental temperature of between

0°C and 40 °C.

Tips for volume setting

When watching videos, be careful not to raise the volume

too high in quiet scenes. You may hurt your ears when a

loud scene is played.

To set the input level

If the volume is high using the analogue input, set the ATT

(attenuator) switch to “–6 dB.”

Setting Connected components

0 dB TV, portable components and other

components with a low output level (initial

settings)

-6 dB Other components

Notes

 Be sure to lower the volume before setting the ATT

switch.

 If audio input is distorted (sometimes, noise can be

heard at the same time), set the ATT switch to “–6 dB.”

Using the headphones

with separately-sold dry

batteries

Commercially available (LR03 (size AAA)) dry batteries can

also be used to power the headphones. Install two

batteries in the same manner as described in step 1 of

“How to use.”

When dry batteries are installed, the battery charge

function is not activated.

Battery life

Battery Approx. usage time

1)

Sony alkaline battery LR03

(size AAA)

28 hours

2)

1) at 1 kHz, 1 mW + 1 mW output

2) Time may vary, depending on the temperature or

conditions of use.

Tips for better reception

Receiving performance

This system utilizes very high frequency signals in the 800

MHz band so the receiving performance may deteriorate

due to the surroundings. The following examples illustrate

conditions that may reduce the reception range or cause

interference.

 Inside a building with walls containing steel beams.

 An area with many steel file cabinets, etc.

 An area with many electrical appliances capable of

generating electromagnetic fields.

 The transmitter is placed on a metal instrument.

 An area facing a roadway.

 Noise or interfering signals exist in the surroundings

due to radio transceivers in trucks, etc.

 Noise or interfering signals exist in the surroundings

owing to wireless communication systems installed

along roadways.

Effective area of the transmitter

The optimum distance is up to approximately 100 m

without the system picking up some interference.

However, the distance may vary depending on the

surroundings and environment.

 If the system picks up some noise within the above

mentioned distance, reduce the distance between the

transmitter and the headphones, or select another

channel.

 When you use the headphones inside the effective area

of the transmitter, the transmitter can be placed in any

direction from the listener.

 Even within the signal reception area, there are some

spots (dead spots) where the RF signal cannot be

received. This characteristic is inherent to RF signals,

and does not indicate malfunction. By slightly moving

the transmitter, location of the dead spot can be

changed.

Replacing the earpads

The earpads are replaceable. If the earpads become dirty

or worn out, replace them as illustrated below. The

earpads are not commercially available. You can order

replacements from the store where you purchased this

system, or at your nearest Sony dealer.

1 Remove the old earpad by pulling it out of the groove

on the housing.

2 Place the new earpad on the driver unit.

Hang the edge of the earpad on one side of the driver

unit’s groove edge, then turn the edge of earpad

around the driver unit as illustrated below.

When the earpad is securely inserted into the groove,

adjust the earpad to the vertical position.

Troubleshooting

If you run into any problems using this system, use the

following checklist. Should any problem persist, consult

your nearest Sony dealer.

No sound/Low sound

 Turn on the headphones.

 Check the connection of the transmitter and A/V

component, AC adaptor, and AC outlet.

 Check that the A/V component is turned on.

 If you connect the transmitter to the headphone jack of

an A/V component, raise the volume level on the

connected A/V component within the range where the

sound is not distorted.

 Change the radio frequency with the CHANNEL selector

on the transmitter, then change the radio frequency to

that of the transmitter with the channel switch on the

headphones.

 Charge the supplied rechargeable battery, or replace

dry batteries with new ones. If the POWER indicator is

still off after charging, take the headphones to a Sony

dealer.

Distorted or intermittent sound

(sometimes with noise)

 Use the headphones near the transmitter, or change

the position of the transmitter.

 If you connect the transmitter to an A/V component

using the headphone jack, lower the volume level on

the connected A/V component within the range where

the sound is not distorted.

 Change the radio frequency with the CHANNEL selector

on the transmitter, then change the radio frequency to

that of the transmitter with the channel switch on the

headphones.

 Charge the supplied rechargeable battery, or replace

dry batteries with new ones. If the POWER indicator is

still off after charging, take the headphones to a Sony

dealer.

Loud background noise

 If you connect the transmitter to the headphone jack of

an A/V component, raise the volume level on the

connected A/V component within the range where the

sound is not distorted.

 Charge the supplied rechargeable battery, or replace

dry batteries with new ones. If the POWER indicator is

still off after charging, take the headphones to a Sony

dealer.

 Use the headphones near the transmitter.

The sound cuts off

 The transmitter turns off if no signal or low signal is

input for 4 minutes. If you connect the transmitter to an

A/V component using the headphone jack, raise the

volume level on the connected A/V component within

the range where the sound is not distorted.

Battery cannot be charged/

POWER indicator does not light up

red

 Install the supplied rechargeable nickel-metal hydride

battery. Dry batteries and rechargeable batteries other

than the supplied cannot be charged.

 Check if the switch on the left housing of the

headphones is set to OFF. If the switch is set to ON, the

POWER indicator does not light up.

Precautions

Notes on the AC adaptor

 Insert the AC adaptor plug firmly.

 Be sure to use the supplied AC adaptor. Using AC

adaptors with different plug polarity or other

characteristics can cause product failure.

Unified

polarity plug

 Be sure to always use the supplied AC adaptor. Even AC

adaptors having the same voltage and plug polarity can

damage this product due to the current capacity or

other factors.

On power sources and placement

 When this system is not to be used for a long period of

time, disconnect the AC adaptor from the AC outlet

holding the plug, and remove the battery from the

headphones to avoid damage caused by battery

leakage and subsequent corrosion.

 Do not leave this system in a location subject to direct

sunlight, heat or moisture.

 Avoid exposure to temperature extremes, direct

sunlight, moisture, sand, dust or mechanical shock.

Specifications

Transmitter (TMR-RF810R)

Modulation FM stereo

Operating frequency

863.0 MHz – 865.0 MHz

Maximum output power

< 4 mW

Channel Ch1, Ch2

Power source DC 12 V: supplied AC adaptor

Audio input Stereo mini plug

Dimensions Approx. 108mm × 128mm × 108mm

(w/h/d)

Mass Approx. 137 g

Rated power consumption

3 W

Headphones (MDR-RF811R)

Frequency response

20Hz – 20,000Hz

Power source Supplied rechargeable nickel-metal

hydride battery BP-HP550-11 or

commercially available (size AAA)

dry-cell batteries

Mass Approx. 270 g (including the supplied

rechargeable nickel-metal hydride

battery)

Rated power consumption

2 W

Design and specifications are subject to change without

notice.

To AC outlet

Connect the AC

adaptor.

Insert the plug firmly.

Press and turn the lid counterclockwise.

Match the  terminals on

the battery to the  marks

in the comportment.

Press and turn the lid clockwise.

7

Adjust the volume.

Tactile dot

If you cannot receive a clear audio signal

First change the radio frequency with the CHANNEL selector switch

on the transmitter, then change the radio frequency to that of the

transmitter with the channel switch on the headphones.

The unit is not waterproof. If water or foreign objects enter

the unit, it may result in fire or electric shock. If water or a

foreign object enters the unit, stop use immediately and

consult your nearest Sony dealer. In particular, be careful

in the following cases.

 When using the unit around a sink, etc.

Be careful that the unit does not fall into a sink or

container filled with water.

 When using the unit in the rain or snow, or in humid

locations

 When using the unit while you are sweaty

If you touch the unit with wet hands, or put the unit in

the pocket of a damp article of clothing, the unit may

get wet.

Note on static electricity

Static electricity accumulated in the body may cause mild

tingling in your ears. To reduce the effect, wear clothes

made from natural materials, which suppress the

generation of static electricity.

For details on the effect of contact to the human body

from the mobile phone or other wireless devices

connected to the unit, refer to the instruction manual of

the wireless device.

This product (including accessories) has magnet(s) which

may interfere with pacemakers, programmable shunt

valves for hydrocephalus treatment, or other medical

devices. Do not place this product close to persons who

use such medical devices. Consult your doctor before

using this product if you use any such medical device.

Features

Thank you for purchasing the Sony MDR-RF811RK Wireless

Stereo Headphone System. Before operating the unit,

please read this manual thoroughly and retain it for future

reference.

Some features are:

 Wireless system that allows you to listen to a

programme free from the restriction of a cord.

 High fidelity sound reproduction.

 13 hours of continuous use with supplied rechargeable

battery.

 Easy connection with TV and HiFi Audio system

equipment.

 Up to 100 metres reception range.

 Volume control function on the headphones.

Wireless Stereo

Headphone System

Operating Instructions

4-529-909-16(1)

MDR-RF811RK

©2014 Sony Corporation Printed in China

Meer over deze handleiding

We begrijpen dat het prettig is om een papieren handleiding te hebben voor je Sony MDR-RF811RK Koptelefoon. Je kunt de handleiding bij ons altijd downloaden en daarna zelf printen. Indien je graag een originele handleiding wilt hebben, raden we je aan contact op te nemen met Sony. Zij kunnen wellicht nog voorzien in een originele handleiding. Zoek je de handleiding van Sony MDR-RF811RK Koptelefoon in een andere taal? Kies op de homepage je taal naar keuze en zoek daarna op het modelnummer om te zien of we deze beschikbaar hebben.

Specificaties

Alle handleidingen voor Sony Koptelefoons
Meer handleidingen voor Koptelefoons

Beoordeling

Veelgestelde vragen over Sony MDR-RF811RK Koptelefoon

Ons supportteam zoekt dagelijks naar nuttige productinformatie en antwoorden op veelgestelde vragen. Als er onverhoopt toch een onjuistheid tussen onze veelgestelde vragen staat, laat het ons dan weten via het contactformulier.

Gerelateerde producten

Handleiding

Sony MDR-D777LP Koptelefoon

Handleiding

Sony CUHYA-0080 PlayStation Koptelefoon

Handleiding

Sony MDR-270LP Koptelefoon

Handleiding

Sony WH-RF400 Koptelefoon

Handleiding

Sony XBA-300AP Koptelefoon

Handleiding

Sony MDR-AS20J Koptelefoon

Handleiding

Sony WI-SP500 Koptelefoon

Handleiding

Sony MDR-ZX600AP Koptelefoon

Gerelateerde categorieën
