You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:

• Visiting our website - docs.whirlpool.eu

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product’s identi cation plate.

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.whirlpool.eu/register

EN

Quick guide

Before using the appliance carefully read the Safety Instructions.

xxxxxxxxxxxx

xxxx

Before using the appliance carefully read the Safety Instructions.

xxxxxxxxxxxx

xxxx

PROGRAMS

Eco cotton kg Max*

Standard cotton programme, suitable to dry normally wet cotton

laundry. Most ecient programme in terms of energy consumption

for drying cotton laundry. The values on the Energy Label are based on

this programme.

Mixed kg 4

This programme is ideal for drying cotton and synthetic fabrics

together.

Bed linen Kg Max*

This programme is intended for drying cotton sheets.

Shirts kg 3

This is a programme for Shirts made from cotton or cotton

blend/synthetics.

Sport kg 4

For drying sports garments made of synthetics or cotton.

Duvet

Programme intended to dry bulky garments, as single duvet.

Jeans kg 3

For drying cotton jeans-wear and garments made of robust

cotton, like denim, such as trousers and jackets.

Easy ironing

This cycle allows to extend the bres of garments thus making

ironing and folding easier. Do not use in case of garments that are

still wet. Suitable for small loads of cotton textiles or cotton blends.

Refresh

A short programme suitable for refreshing bres and garments by

means of fresh air. Do not use with garments that are still wet. It can be

used on with any load size but is more eective with small loads. The

cycle duration is about 20 minutes.

FIRST TIME USE

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dryer is xed correctly,

either to the dryer’s water tank, or to your domestic sewage

system.

The dryer should be installed in environment in a room

temperature range of 20°to 23°C for optimum performance. But

will function if the room is between 14 and 30°C. Before you use

your dryer ensure that it has been in a upright position for at

least 6 hours.

DAILY USE

Doing this will keep your machine working at its BEST!

Remember to empty your water tank after each drying cycle.

Remember to clean your lters after each drying cycle. (Refer

to section Care & Maintanence).

1. Open the door and load garments. Always refer to instructions

on clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter.

2. Close the door.

3. Press the button On/O.

4. Select the programme according to the laundry type.

5. Select the options, if necessary.

6. To start the cycle, press the Start/Pause button.

7. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry

8. Turn the machine o by pressing the button On/O, open the

door and pull clothing out. If the machine is not switched o

manually, after about a quarter of an hour from the cycle end, the

appliance turns o automatically to save energy.

If this last stage is not carried out immediately, some machines

and/or some programmes/options are equipped with Crease Care

system. For some hours, after the end of drying, the drum rotates

at regular intervals to prevent the formation of creases. In case of

power failure, it is necessary to press the button Start/Pause to

restart the cycle.

OPENING OF THE DOOR DURING THE CYCLE

During operation, it is possible to open the door. After having

closed it, press the button Start/Pause again to restart the dryer.

*MAX LOAD 9 Kg (Dry load)

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

CONTROL PANEL

1 ON/OFF button (Reset if long pressed)

2 Programme selection Knob

3 Start/Pause

Options Buttons*

4 Cycle end

5 High heat

6 Anti tangle (Mute if long pressed)

7 Dryness level

8 Start lelay

9 Timed drying

10 Rapid (Key lock if long pressed)

11 Gentle

12 Fresh care+

*Note: some models may have the wording in full instead of the icons

INDICATORS

Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry

Cycle phase: Drying - Cool down - End of cycle

Empty water tank - Clean door lter - Clean bottom lter

Refer to troubleshooting section: Failure: Call after sales service

DEMO

Demo mode.

1

3

2

12

10

11

78 9

3“

3“

h

6

5

4

1

3

2

12

10

11

78 9

3“

3“

h

6

5

4
