IS-10438LED-US

We’re here to help 866-558-5706

Hrs: M-F 9am to 5pm EST

REV 06-JUL-2021

For warranty informaon please visit: kichler.com/warranty

1) Find the appropriate threaded holes on mounng strap

that align with hole distance in canopy. Thread mounng

screws into threaded holes starng from the outlet box

side.

2) Aach mounng strap to outlet box using the mounng

strap screws. Mounng strap can be adjusted to suit

posion of xture.

3) Grounding instrucons: (See Illus. A or B)

a) On xtures where mounng strap is provided with a

hole and two raised dimples, wrap ground wire from

outlet box around green ground screw, and thread

into hole.

b) On xtures where a cupped washer is provided, put

ground wire from outlet box under cupped washer

and green ground screw and thread screw into hole

in mounng strap.

If xture is provided with ground wire, connect

xture ground wire to outlet box ground wire with

wire connector aer following the above steps. Never

connect ground wire to black or white power supply

wires.

GREEN GROUND

SCREW

CUPPED

WASHER

OUTLET BOX

GROUND

FIXTURE

GROUND

DIMPLES

WIRE CONNECTOR

OUTLET BOX

GROUND

GREEN GROUND

SCREW

FIXTURE

GROUND

a

b

4) Make wire connecons. Reference chart below for

correct connecons and wire accordingly.

Connect Black or Red

Supply Wire to:

Connect White Supply

Wire to:

Black White

*Parallel cord

(round & smooth)

*Parallel cord

(square & ridged)

Clear, Brown, Gold or

Black without Tracer

Clear, Brown, Gold or Black

with Tracer

Insulated wire (other

than green) with copper

conductor

Insulated wire (other

than green) with silver

conductor

*Note: When parallel wire (SPT

1 & SPT 2) are used. The neutral

wire is square shaped or ridged

and the other wire will be round

in shape or smooth (See illus.) Neutral Wire

5) Carefully push wire connecons back into outlet box

making sure all connecons remain secure.

6) Push xture to wall, carefully passing mounng screws

through holes in canopy.

NOTE: Make sure all wires are inside canopy, and do not

get pinched between wall and canopy of xture.

7) Place the lock washers onto the mounng screws and

screw lock-up knobs onto mounng screws. Tighten

knobs to secure xture to wall.

Fixture DiagramCauons

CAUTION – RISK OF SHOCK –

Disconnect Power at the main circuit breaker panel or main

fusebox before starng and during the installaon.

WARNING:

This xture is intended for installaon in accordance with the

Naonal Electrical Code (NEC) and all local code specicaons.

If you are not familiar with code requirements, installaon by a

cered electrician is recommended.

DIMMING:

This LED xture is compable with most standard incandescent

dimmers, LED dimmers, and electronic low voltage dimmers.

For opmal performance, an electronic low voltage dimmer should

be used.

See kichler.com/dimming for a list of compable dimmers.

CLEANING:

• Always be certain that electric current is turned o before

cleaning.

• Only a so damp cloth should be used. Harsh cleaning

products may damage the nish.

Installaon Instrucons

WIRE

CONNECTORS

OUTLET BOX

LOCK-UP KNOBS

CANOPY

DIFFUSER

SHADE MOUNTING SCREWS

SHADE

MOUNTING SCREWS

STRAP MOUNTING SCREWS

MOUNTING STRAP

LOCKWASHERS

This device complies with part 15 of the FCC Rules. Operaon is subject to

the following two condions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received, including

interference that may cause undesired operaon.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protecon against harmful

interference in a residenal installaon. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instrucons, may cause harmful interference to radio

communicaons. However, there is no guarantee that interference will

not occur in a parcular installaon. If this equipment does cause harmful

interference to radio or television recepon, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separaon between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Informaon:

Installaon Instrucons (connued):

8) Lower shade down over xture. Align holes of the shade

with holes on diuser.

9) Thread shade mounng screws down into holes on shade

and into holes in diuser. Tighten screws to secure shade

in place (DO NOT OVER TIGHTEN).
