Thank you for purchasing your new product.

We recommend that you spend some time reading this instruction manual in order that

you fully understand all the operational features it oers.

Read all the safety instructions carefully before use and keep this instruction manual for

future reference.

Mini Oil-Filled Radiator

Instruction Manual

L09MOR23

This product is only suitable for well-insulated spaces or occasional use.

Product Overview

Control Panel

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

• Main Unit

• Foot × 2

Assembly

Before using the heater, the feet (supplied) must

be tted to the unit.

• If items are missing or damaged, please contact Partmaster (UK only).

• Tel: 0344 800 3456 for assistance.

Operation

Position the heater upright on the oor away from curtains, furniture or wall coverings before

plugging your heater into the mains socket.

• Turn the Thermostat Control clockwise to switch on the heater. The indicator will illuminate

when the heating element is on. Turn the Thermostat Control to MAX position for

maximum heat output. It is recommended to select the “MAX” position to get the heater to

pre-heat.

• When the room reaches the desired temperature, turn the Thermostat Control slowly anti-

clockwise until the indicator goes o and the thermostat “click o” sound is heard.

• If the room temperature falls below the set temperature, the heater and indicator will turn

on again.

• Turn the Thermostat Control anticlockwise to “MIN” position to switch o the unit

completely.

It is normal for the heater to emit some smell and fumes when it is turned on for the

rst time or when turned on after not being used for a long period of time. This smell

will disappear when the heater has been turned on for a short while.

Cleaning

Your heater should be cleaned regularly to prevent dirt and dust from building up which will

aect its performance. Ensure the air inlet and the air outlet are not blocked.

This can be done with a vacuum cleaner, using the brush attachment.

• Ensure you unplug your heater from the mains socket and wait for the heater to

cool down completely before cleaning.

• Do not use any detergents or abrasives and do not allow any water to enter the

heater.

Hints & Tips

My heater does not work when I turn it on

• Check that your heater is plugged in and the power is turned on at the mains socket.

• Check that your heater is in an upright position.

• Check if the thermostat setting is too low.

• If the heater still doesn’t work, do not try to repair the heater yourself.

If your heater’s power is automatically cut o follow the steps

below:

1. Unplug your heater and allow it to cool down.

2. Inspect your heater. Clean the air inlet and the air outlet with a vacuum cleaner if necessary.

If there is any sign of physical damage (e.g. melting, or burning of the case), do not attempt

to use your heater. Please leave all maintenance work to qualied personnel.

3. Plug-in the heater and switch it on again. If it cuts o again, move the heater to a better

ventilated location.

Safety Protective Device

Overheat Protection

The power to the heater will automatically cut o if the

temperature of the heater exceeds a certain limit. In the event

of overheating, the heater will stop operating. Switch the heater

o and allow it to completely cool. The heater will then resume

operating as normal.

Built-in Tipover Protective Switch

When you use the heater in an upright position on a rm and level surface, the built-in tipover

protective switch will be on. In the event the heater is knocked over, the heater will stop

functioning automatically.

• Do not override the tip-over protective switch as this may cause a hazard.

• Using the unit on a deep pile carpet may activate the tip-over protective switch.

OFF MAX

1. Thermostat Control

2. Indicator

1

2

The back side (with screws

secured) of the rear foot support

should face inwards to the unit.

IB-L09MOR23-230511V1
