Caution for AC Mains Lead

4

RQT5802

(For United Kingdom)

(“EB” area code model only)

For your safety, please read the following text

carefully.

This appliance is supplied with a moulded three pin

mains plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure

that the replacement fuse has a rating of 5-ampere

and that it is approved by ASTA or BSI to BS 1362.

Check for the ASTA mark or the BSI mark on

the body of the fuse.

If the plug contains a removable fuse cover you must

ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used

until a replacement cover is obtained.

A replacement fuse cover can be purchased from your

local dealer.

CAUTION!

IF THE FITTED MOULDED PLUG IS UNSUITABLE

FOR THE SOCKET OUTLET IN YOUR HOME

THEN THE FUSE SHOULD BE REMOVED AND

THE PLUG CUT OFF AND DISPOSED OF

SAFELY.

THERE IS A DANGER OF SEVERE ELECTRICAL

SHOCK IF THE CUT OFF PLUG IS INSERTED

INTO ANY 13-AMPERE SOCKET.

If a new plug is to be fitted please observe the wiring

code as stated below.

If in any doubt please consult a qualified electrician.

IMPORTANT

The wires in this mains lead are coloured in

accordance with the following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the

coloured markings identifying the terminals in your

plug, proceed as follows:

The wire which is coloured Blue must be connected to

the terminal which is marked with the letter N or

coloured Black or Blue.

The wire which is coloured Brown must be connected

to the terminal which is marked with the letter L or

coloured Brown or Red.

WARNING: DO NOT CONNECT EITHER WIRE TO

THE EARTH TERMINAL WHICH IS MARKED WITH

THE LETTER E, BY THE EARTH SYMBOL OR

COLOURED GREEN OR GREEN/YELLOW.

THIS PLUG IS NOT WATERPROOF–KEEP DRY.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of

AC mains plug (figures A and B). Confirm the AC

mains plug fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

Figure A

Figure B

Fuse cover

2. Replace the fuse and close or attach the fuse

cover.

Figure A

Fuse

(5 ampere)

Figure B

Fuse

(5 ampere)
