Handleiding Conair GS40K Kledingstomer

Handleiding voor je Conair GS40K Kledingstomer nodig? Hieronder kun je de handleiding gratis bekijken en downloaden als PDF in het Nederlands en/of Engels. Dit product heeft 0 veelgestelde vragen, 0 comments en heeft 0 stemmen. Is dit niet de handleiding die je zoekt, neem dan contact met ons op.

Is je product kapot en biedt de handleiding geen oplossing meer? Dan kun je voor reparatie gratis terecht bij Repair Café.

Handleiding

GS40K

Date

3/31/20

Customer

CKTL

Model No.

GS40K

Description

Job No.

Reference No.

IB-20/063

Revision No.

Color

1C+1C(Black)

Open Size

552mm(W) X 214mm(H)

Folded Size

92mm(W) X 214mm(H)

Material

80gsm Artpaper

Prepared by

Betty Bai

Approved by

Ken Xiong/ Francesca Seo

Vendor

MILLPLAN

Supplier

CONTINENTAL CONAIR LIMITED

CHINA CREATIVE DEPARTMENT

INSTRUCTION

BOOKLET

사용설명서

SMART HANDHELD GARMENT STEAMER

콘에어 스마트 익스트림 스팀 핸디 스티머

CONAIR SMART HANDHELD

GARMENT STEAMER

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, especially when children are

present, basic safety precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE USING

KEEP AWAY FROM WATER

SAFETY PRECAUTIONS

WARNING: The polyethylene bags over the product

or its packaging may be dangerous. Keep these bags

out of the reach of babies and children.

Never use them in cribs, children’s beds, pushchairs

or playpens. The thin lm may cling to the nose and

mouth and prevent breathing. A bag is not a toy.

WARNING: Do not use this appliance near bathtubs,

showers, basins or other vessels containing water.

1. If you are using the unit in a bathroom, unplug it after you have

nished using it. Using the unit close to a source of water can,

in fact, be dangerous, even if the unit is switched off. To ensure

additional protection, have installed in your bathroom a residual

current device (RCD) with a nominal trip current no higher than 30

mA. Ask your electrical tter for advice.

2. Never immerse the unit in water or any other liquid.

3. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons in

order to avoid a hazard.

4. Do not use the unit if it has fallen or if it appears to be damaged.

5. Do not leave the unit unattended when it is plugged in or switched

on.

6. Unplug the unit immediately if you have problems when using it.

7. Do not use any accessories other than those recommended by

manufacturer.

8. Unplug the unit after each use and before lling or cleaning it.

9. This unit is not intended for use by people (including children) with

reduced physical, sensory or mental capabilities, or by persons

who lack experience or knowledge, unless they are supervised

or have been given instructions beforehand on the use of the

unit by a person responsible for their safety. Children should be

supervised to make sure they do not treat the unit like a toy.

10. Allow the unit to cool before storing.

11. To prevent damage to the cord, do not wrap it around the unit and

ensure it is stored without twisting or folding it.

12. When emitting steam, this appliance may cause burns if it is used

too close to the skin or eyes, or if it is used incorrectly. To reduce

the risk of contact with hot water emitting from the steam vents,

test appliance before use by holding it away from the body.

13. Do not steam garments while on a person.

14. Burns could occur from touching hot metal parts, hot water or

steam. Use care when you turn steam appliance upside down.

15. Do not operate steamer without correctly lling the water container.

Only use clean cold water for lling this appliance. In hard water

areas, we recommend the use of distilled water.

16. Use of an extension cord is not recommended. If an extension

cord is absolutely necessary, a 13-ampererated cord should be

used. Cord rated for less amperage may overheat. Care should

be taken to arrange the cord so that it cannot be pulled or tripped

over.

17. Never yank cord to disconnect from outlet, instead, grasp plug

and pull to disconnect.

18. Use with caution when carrying steamer as it contains hot water.

NOTE: Before using the garment steamer for the rst time, it is

recommended to operate the steamer for approximately 5 minutes,

unplug the unit and allow it to cool. Empty container and rell

before actually using.

HOUSEHOLD USE ONLY

FILLING INSTRUCTIONS

1. Make sure the unit is unplugged.

2. Stand the unit on a table and grasp with one hand.

3. With other hand, move the release switch up toward the "STEAM"

button.

4. Pull the reservoir out, away from the steamer body.

5. The rubber inlet cover is located on the top of the water reservoir.

6. Open the inlet cover and ll the reservoir with distilled water (which

can be found in grocery stores). We recommend that you use

distilled water only, as this will prevent mineral deposits in the boiler

that can reduce performance or clog the water system.

7. Close the inlet cover and return the reservoir to its place, making

sure that it snaps in place and is secure.

Rubber Inlet Cover

GET TO KNOW YOUR STEAMER

Setting & Mode button

Steam nozzles

Steam button

Water reservoir

release switch

Easy-to-fill

water reservoir

Built-in creaser clip

with garment guides

I/O button

Ready light - Blue

Steam setting indicator lights

3-in-1 Attachment

Silicone Band

Pulls fabric taut for

easier steaming.

Bristle Brush

Loosens fibers for

better steam

penetration.

Delicate Fabric

Spacer

Helps protect

delicate fabric and

trims.

OPERATING INSTRUCTIONS

1. Fill water reservoir with distilled water.

2. Plug the unit into the electrical outlet.

3. Press I/0 button , located on the back of the steamer, to turn the

unit on. The blue READY light will illuminate and begin blinking.

Allow 40 seconds for the unit to warm up. The appliance is ready

to use when the READY light stops blinking and remains solid.

4. Pointing the steam jets away from you. To activate SMART

TOUCH SENSOR hold the MODE button for 2 seconds until

lights are ashing. Once lights are ashing, the SMART TOUCH

SENSOR has been activated.

5. Your steamer has steam settings - adjustable

whether at SMART TOUCH mode or

MANUAL mode. Short press the setting

button until you reach desired setting. One

red light indicated the minimum steam rate

for use on delicate fabrics, while 5 red lights

indicate highest steam rate for use on thick

fabrics and heavily wrinkled articles.

6. Pick up steamer and begin steaming.

7. Once steamer is placed down and your

hand releases, the SMART TOUCH SENSOR goes into auto

pause. To restart the steamer again, simply pick up steamer and

begin steaming.

8. Press "STEAM" button to release the ow of steam.

9. To stop the ow of steam, depress the "STEAM" button.

10. When rst using the device, test on an old cloth, as there may be

sediment left from the manufacturing process or transportation.

USING CREASER

This garment steamer has a built-in creaser on

the top of the unit. To use, slide garment under

the clip and align edge with the pattern as

marked on the creaser. Press the Steam button

and steam will issue from the port on the top of

the unit. Slide the steamer along the edge of the

garment to create a sharp crease. NOTE: Steam

will continue to emit from the steam nozzle on

the front of the unit during creaser use.

USING 3-IN-1 ATTACHMENT

With the garment steamer off and cool, snap the silicone band

attachment (Fig. 1) over the steam head, ensuring it is rmly afxed.

At this point the silicone band can be used or you can choose to

afx either the bristle brush (Fig. 2) or delicate fabric spacer (Fig. 3)

inserts into the channel on the top of the silicone band attachment

as desired. NOTE: Only one function of the 3-In-1 attachment can

be used at a time.

CAUTION: USE EXTREME CARE WHEN CHANGING THE

ATTACHMENTS AFTER THE UNIT HAS BEEN IN USE, AS THE

STEAM HEAD WILL CONTINUE TO BE HOT.

Fig. 3

Fig. 2

Fig. 1

STEAMING TIPS

NOTE: First, test unit on an inconspicuous area of the item to be

steamed using the lowest Steam setting to ensure fabric can tolerate

the effects of steam. If there is no evidence of damage, you can

proceed to use the steamer on that item.

1. To prepare your fabric for steaming, brush it with the brush

attachment. This will loosen the bers and allow better steam

penetration.

2. Hang your garment or fabric. NOTE: Avoid using metal clothes

hangers, if possible.

CAUTION: If hanging garment on a door while steaming, be

careful not to damage the door with steam.

3. When steaming, always keep the motion and pass the steam jets

just above the fabric where the wrinkles are. It may take a few

passes to remove the wrinkles completely. CAUTION: If hanging

garment on a door while steaming, be careful not to damage the

door with steam.

4. For heavier fabrics or severely wrinkled fabrics, you may position

the steamer head directly on the fabric for a few seconds to

remove wrinkles. Be cautious when working with delicate fabrics.

5. After use, turn unit OFF by depressing the "STEAM" button. Then

press the I/O button to the OFF position. With dry hands, unplug

your garment steamer from the outlet. Empty any remaining

water from the tank to avoid leakage. BE SURE TO PRESS THE

“I/O” button to THE “OFF” position PRIOR TO UNPLUGGING

THE UNIT.

CLEANING/STORING/MAINTENANCE

• After use – wait for it to cool down before cleaning and then

remove any water left in water tank.

• Allow the water tank to dry thoroughly.

• Keep this garment steamer out of reach of babies and children.

• Do not wrap the power cord around the unit and ensure it is

stored without twisting or folding it.

• For the best performance, limescale should be removed from

time to time.

Note: Minerals in water will vary in different areas. To insure

continued operation of the steamer, use only puried/distilled water,

never store without cleaning and removing excess water from the

reservoir and water container.

ONE YEAR LIMITED WARRANTY

This Conair Appliance is guaranteed for consumer use for one

year. This guarantee is no longer valid in case of alteration or

repair by any unauthorized persons and only covers defects

under normal use from the date of purchase. If your product

does not perform satisfactorily because of defects in materials

or manufacture, it will be repaired or replaced under Consumer

Dispute Settlement Regulation of Fair Trade Commission.

THE DATE CODE MENTIONED

WWYYXXX was mentioned on unit as manufactured date so you

can see W as week and Y as year for your reference.

CONAIR KOREA CUSTOMER SERVICE:

Conair Korea Trading Limited

#1304~1306 Seoul Soop Dream Tower, 66 Seongsui-ro,

Seongdong-gu, Seoul, Korea

Customer Center: 1899-0209

A/S Center: www.llelec.co.kr

GS40K

IB-20/063

Folding method:

12 pages (6 x 2)
