Handleiding Crivit IAN 94592 Stappenteller

Handleiding

GB/IE GB/IE GB/IE GB/IE GB/IE

GB/IE GB/IE GB/IE GB/IE GB/IE GB/IE

STEP Mode:

The number of the measured steps of the current

day, as well as the trip time, are displayed.

Note: This device is equipped with 10-step-filter to

enhance the step count accuracy. This requires at

least 10 steps for the sensor to gather user’s trip

behavior for speed and distance calculation.

Hence the initial display of the step count will be

above 10.

Press the SET button

3

repeatedly to browse

through Trip time / Trip distance / Calories

used/ Fat burnt in STEP mode.

Trip time

The activity time of the pedometer for the current

day is displayed.

Trip distance

The distance covered on the current day (in km).

Note: Ensure when entering that you take addi-

tional weight into consideration such as clothing or

a backpack.

- Set your height.

- Set your step length.

Confirm your setting by pressing the SET button.

Selecting the mode

Press the MODE button

2

repeatedly to

browse through the different modes (TIME,

STEP and 7-day storage modes).

The pedometer is equipped with the

following modes:

Time Mode

The LC-Display

1

indicates the current time and

the day of the week.

Setting the mode

You must enter your personal data before you use

the pedometer for the first time. You can change

the following values successively:

Press the MODE button

2

repeatedly to

browse through the different modes.

Press the SET button

3

to set the desired value.

- Set the distance unit (km / mile).

Note: Changing the distance unit (km / mile) will

also change the unit for weight (kg / lb) and height

(cm / inch) and step length accordingly.

- Set the time format (12 / 24 hr).

- Set the hour (HR).

- Set the minutes (MIN).

- Set the seconds (SEC).

- Set the day of the week.

- Set your weight.

should remove it immediately in order to prevent

damage to the device!

Avoid contact with the skin, eyes and mucous

membranes. Any part of the body coming into

contact with battery acid should be rinsed off

with a large amount of water and / or a doctor

should be contacted if necessary!

Use only the recommended battery type.

Before Initial Use

Remove the protective film from the LC display

1

before you use the device for the first time.

Then place a battery type CR2032 (3 V ,

lithium) in the battery compartment

5

(see Ill. B).

Note: The device will now perform a brief display

check. All displays will be shown for approx.1sec-

ond. The device then switches into the set-up mode.

Your pedometer is now ready to be configured.

CAUTION! EXPLOSION HAZ-

ARD! The batteries may never be

recharged!

When inserting the battery ensure the correct po-

larity! This is indicated in the battery compart

ment.

Clean the battery and device contact before you

insert the battery with a dry cloth if necessary.

Remove the dead battery immediately from the

device. There is an increased risk of leaks!

Batteries may not be disposed of with normal

domestic waste!

Every consumer is legally obliged to dispose

of batteries in the proper manner!

Keep the battery out of reach of children, do not

throw the battery into fire, do not short-circuit

or take the battery apart.

If you do not observe these instructions, the

battery could be discharged beyond the cut-off

voltage. This will then pose a risk of leaking. If

the battery has leaked inside your device, you

Please note that the guarantee does not cover

damage caused by incorrect handling, non-

compliance with the operating instructions or

interference with the device by unauthorised in-

dividuals.

Never disassemble the device. Improper repairs

may result in considerable danger for the user.

Always have repairs performed by a professional.

Keep the device dry. Never immerse the device

in water or other liquids.

Safety instructions

for batteries

WARNING! RISK OF FATAL INJURIES!

Batteries could be swallowed, which may be

life-threatening. If a battery has been swallowed,

seek medical help immediately.

Remove the battery from the device if it is not

going to be used for a prolonged period.

General Safety

Instructions

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall

not be made by children without supervision.

Do not use the device if damaged. Damaged

devices represent a danger of death from elec-

tric shock!

Do expose the device to

– extreme temperatures,

– to direct sunlight,

– humidity / rain.

Otherwise it may be damaged.

Scope of delivery

1 Pedometer

1 Battery CR2032 (3 V

, Lithium)

1 Set of operating instructions

Safety

WARNING! Please read all the safety infor-

mation and instructions. Failure to observe the

safety information and instructions can result in

electric shock, fire and / or serious injury.

PLEASE KEEP ALL SAFETY INSTRUCTIONS

AND INSTRUCTIONS FOR USE FOR FUTURE

REFERENCE!

Technical Data

Measuring method: sensor

Step display: 0–99999 steps

Distance display: 0–9999 km

Calorie display: 0–99999 kcal

Adjustable user weight: 30–219 kg (can be

set to 1 kg accuracy)

Default: 50 kg

Body height: 100–249 cm

Default: 150 cm

Adjustable step length: 25–249 cm

Default: 62 cm

Time unit: 12 / 24 hr

Battery: 1 battery CR2032

(3 V

, Lithium)

Permissable temperature range: 0–50 °C

6

Anti-shock ring

7

Belt clip

Display:

8

Week display

9

Calorie display

10

km / m per hour

11

Grams symbol (fat burn)

12

Pedometer on / off

13

Day display

14

PM symbol (afternoon in 12hr format)

15

Display for low battery warning

16

Number of steps

NOTE: The LC display

1

of the device cannot be

switched off. However, the power consumption re-

quired to operate the LCD is very low and compa-

rable to that of a wristwatch.

Pedometer

Intended use

This pedometer records the number of steps you

have taken, the distance covered, the required time

and the calorie consumption. The device is not suit-

able for the recording of medical data.

Parts description

Device:

1

LC display

2

MODE button

3

SET button

4

Battery compartment cover

5

Battery compartment

A

CR2032

3V

B

1

4

2

3

4

5

7

E

ME M ORY

D

7

12

16

14

9

10

11

8

15

13

C

6

PEDOMETER

Operation and Safety Notes

IAN 94592

PEDOMETER
