Automatic start/stop
To save the battery the device switches itself off after
5 – 6 minutes if no impulse is received by the sensor. To
switch the device on again, press one of the buttons.
Setting the wheel sizes
Press and hold the left button and the right
button for 2 seconds (or after replacing the
battery) to switch the device to the wheel
size entry mode. Multiply the wheel diameter, d (figure
2), in mm by 3.1416 in order to establish the wheel coef-
ficient, c. Press the left button to select the position that
needs to be entered and then the right button to enter the
required number (for fast forward keep pressed down).
Press the left button again to select km/mile. (Please
note that removing the battery deletes the wheel size
information).
- Distance in mm per revolution -
Please use this table for assistance in calculating the
wheel diameter and wheel circumference.
Choice between miles and kilometres
After setting the wheel size the symbol “KM” will blink
above the wheel size entry. If you would like the com-
puter to show the speed in km/h press the left button.
If the computer should calculate in mph press the right
button first and then the left button.
Calorie counter
On the display the prompt km/h will then blink. At this
point you have to set your age. By pressing the right but-
ton you can change the value and go forward to the next
figure using the left button. In the bottom line you can
set your body weight in kg. By pressing the right button
you can change this value and go forward to the next fig-
ure using the left button.
Service indicator
After setting the wheel diameter the indicator 600 km
flashes. In the bottom left corner you will see a spanner.
This function enables you to set the number of kilome-
tres until the next service of your bike. By pressing the
right button you can choose to set a number between
200 and 800 km as a reminder to service your bike. By
pressing the left button the value is saved. On reaching
the pre-set number of kilometres a spanner appears in
the display. By pressing the left button you can switch
off the reminde
r.
BATTERY DISPOSAL:
Batteries must not be placed in household rubbish contai-
ners. You are obligated by law to return used batteries and
rechargeable batteries. They can be dropped off at our shop
or at other locations near you (e.g., other businesses or muni
-
cipal collection points). Batteries and rechargeable batteries
are marked with a crossed-out dustbin and with the chemical
symbol of the toxic substance, i.e. „Cd“ for cadmium, „Hg“ for
mercury and „Pb“ for lead.
BATTERY SAFETY
Always follow warnings and manufacturers instrtuctions for
both the batteries and the battery-operated product. Use only
1
2
3
2
Fig. 2
WHEEL SIZES
Wheel size in
inches
ETRTO
Nr.
Wheel
coefficient
16 x 1.75 47 – 305 1216
20 x 1.75 47 – 406 1623
24 x 1.75 47 – 507 1940
26 x 1.6 44 - 559 2051
26 x 1.75 x 2 47 - 559 2070
26 x 1.9 50 - 559 2089
26 x 2.00 54 - 559 2114
26 x 2.125 57 - 559 2133
26 x 1 3/8 37 - 590 2105
26 x 1 3/8 x 1 1/2 37 - 584 2086
26 x 3/4 20 - 571 1954
27 x 1 1/4 32 - 630 2199
28 x 1.5 40 - 622 2224
28 x 1.75 47 - 622 2268
28 x 1 3/8 x 1 5/8 37 - 622 2205
700 x 18C 18 - 622 2102
700 x 20C 20 - 622 2114
700 x 23C 23 - 622 2133
700 x 25C 25 - 622 2146
700 x 28C 28 - 622 2149
700 x 32C 32 - 622 2174
700 x 35C 37 - 622 2205
700 x 40C 40 - 622 2224
1a
1b
2 mm Max
2
3
SENSOR
Fault Problems
No tachometer display Incorrect magnet/sensor alignment
Delayed display of request The temperature range lies outside of
the specified minimum value (0-55⁰C)
Black screen The temperature is too high or the
display was exposed to direct sunlight
for too long
Failing screen display Empty battery or the power supply is
too weak
Incorrect set-up for distant Check the sensor and magnet reading
positions, that the battery is correctly
fitted and the fitting is in accordance
with the instructions
The display shows blurred / Remove and reinsert the battery
irregular symbols
click
1c
the correct type and size battery indicated. Check the contacts
of both the battery and the battery-operated product for cleanli
-
ness. Always insert the batteries correctly with regard to polari-
ty (-/+), matching the positive and negative symbols of both bat-
tery and product. Putting them in backwards, the product will
sometimes still operate, but may inadvertently charge the bat
-
teries resulting in venling or leaking. Remove and safely dispose
or exhausted batteries immediately. Replace all batteries in bat
-
tery-operated products at the same time and with the batteries
of the same type and manufacture. Do not short circuit batteries.
When the positive (+) and negative (-) terminals of a battery are
in contact with each other, the battery can become short circui
-
ted. For example, loose batteries in a pocket with keys or coins
can be short circuited possibly resulting in venting or explosi
-
on. Do not heat batteries. Do not crush, puncture, dismantle or
otherwise damage batteries. Do not charge non-rechargeable
batteries. Keep batteries out of reach of small children. If you
suspect that a battery has been swallowed, seek immediate me
-
dical advice. Please retain for future reference.
PACKING DISPOSAL
The packaging is made of 100% environmentally friendly ma-
terials which can be disposed of at local recycling points.
COMPUTER DISPOSAL
For disposing of the computer and radio sensor,
please obtain advice from your local authority or
town council.
Wheel size
in inches
ETRTO
Nr.
!
!
!
CHECK LOCAL
COUNCIL
RECYCLING
CENTER
COMPUTER
recyclenow.com
!
